NGK SPARK PLUGS TR5GP Part Description
Manufacturer
Product Description
NGK G-Power Platinum Spark Plug
Features & Benefits
- SINGLE PLATINUM TIP: Fine wire 0.6 millimeter platinum tip center electrode ensures improved durability and a consistently stable spark
- PLATINUM ALLOY: G-Power platinum provides exceptional value with increased performance and longer service intervals than factory nickel plugs
- TRAPEZOIDAL CUT GROUND ELECTRODE: Reduces quenching design produces improved ignitability and performance
- SOLID COPPER CORE: 98% pure copper core offers superior heat dissipation, conductivity and ultra wide heat ranges
- COLD-ROLLED THREADS: Prevents cross-threading and damage to cylinder heads
- RECOMMENDED USAGE: Lower cost alternative to double precious metal spark plugs or as an upgrade to OE nickel alloy spark plugs
NGK SPARK PLUGS TR5GP Specifications
Product Attributes
| Short Style Spark Plug | No |
| Service Number | TR5GP |
| Stock Number | 3186 |
| Part Number | TR5GP |
| Resistance | 5000.0 82 |
| Ground Electrode Tip Design | Trapezoid |
| Ground Configuration | J-Gap |
| Ground Electrode Core Material | Nickel |
| Washer(s) Included | No |
| Grade Type | Standard Replacement |
| Electrical Terminal Type | Non-Removable Nut |
| Center Electrode Core Material | Copper |
| Center Electrode Tip Material | Platinum |
| Pre-Gap Size | .040 IN |
| Ground Electrode Quantity | 1 |
| Hex Size | 5/8" (16mm) |
| Insulator Height | 2.07 IN |
| Manufacturer Heat Range | 5 |
| Seat Type | Tapered |
| Reach | 0.689 IN |
| Thread Diameter | 0.551 IN |
| Insulator Material | Ceramic |
| Resistor Type | Yes |
| Skirt Length | 0.0 IN |
| Ground Electrode Tip Material | Nickel |
| Skirt | No |
| Center Electrode Insulator Tip Projection | 0.16 IN |
| Center Electrode Design | Fine Wire |
| Center Electrode Projection | Mid Projection |
| Thread Size | M14 - 1.25 |
| Metallurgy | Single Platinum |
| Thread Type Standard | Metric |
| Pre-Gap Size | 1.0 MM |
| Insulator Height | 52.5 MM |
| Reach | 17.5 MM |
| 6648 | 0.0 MM |
| Center Electrode Insulator Tip Projection | 4.0 MM |
Additional Information
| Harmonized Tariff Code (HTS) | 8511100000 |
| Warranty Time UOM | MO |
| Warranty Time | 2 |
| Country of Origin (Primary) | US |
| UPC | 00087295131862 |
| VMRS Code | 033003005 |
| UNSPSC | 26101732 |
NGK SPARK PLUGS TR5GP Cross References
| Brand | Part Number |
|---|---|
| ACDelco | 19250962, 19250963, 3, 6, 8, 25164644, 25164641, 19250967, 19145290 |
| Autolite | AP5245, APP105DP2, APP5144, APP765, APP764, AP103, AP104, AP105, AP105DP2, AP104DP2, AP106, AP5164 |
| Bosch | HGR9LDP0, HR8DPP30X, HGR7DQP, 4457, 4205, 6723, 6704, 4309, HGR8DQP, 4005, 6709, HR8LPP30U, HGR9DQP, HR8DPX |
| Champion Spark Plug | 3013, 7963, 7983-2, 3026, 3013-2, 7983 |
| DENSO Auto Parts | 4713, 4511, IT16TT, PT16TT |
| E3 SPARK PLUGS | E353 |
| Motorcraft | SP432, AGSF32FM |
| N/A | TR5GP, 3015, RS14PMC4 |
| NGK | 3186 |
NGK SPARK PLUGS TR5GP Fits Vehicles
- Volvo 780 (1987-1990)
- Volvo 760 (1983-1990)
- Volvo 262 (1976, 1978-1981)
- Volvo 265 (1976-1981)
- Volvo 264 (1976-1982)
- Chevrolet Suburban 3500 HD (2016-2018)
- Chevrolet Silverado 1500 HD Classic (2007)
- GMC Sierra 1500 HD Classic (2007)
- GMC Sierra 3500 Classic (2007)
- GMC Sierra 2500 HD Classic (2007)
- GMC Sierra 1500 Classic (2007)
- Chevrolet Silverado 3500 Classic (2007)
- Chevrolet Silverado 2500 HD Classic (2007)
- Chevrolet Silverado 1500 Classic (2007)
- Cadillac Escalade EXT (2002-2013)
- Cadillac Escalade ESV (2003-2014)
- Chevrolet Trailblazer EXT (2003-2006)
- GMC Envoy XL (2003-2006)
- GMC Envoy XUV (2004-2005)
- Chevrolet SS (2014-2017)
- Workhorse P32 (2001-2002)
- GMC Savana 4500 (2009-2020)
- Chevrolet Express 4500 (2009-2020)
- Chevrolet Caprice (2011-2017)
- Ford Fusion (2010-2012)
- Mercury Milan (2010-2011)
- Hummer H3T (2009-2010)
- Ford E-150 (2009-2014)
- Mazda Tribute (2009-2011)
- Mercury Mariner (2009-2011)
- Ford Escape (2009-2012)
- GMC Canyon (2009-2012)
- Chevrolet Colorado (2009-2012)
- Buick Allure (2008-2009)
- Hummer H3 (2008-2010)
- Pontiac G8 (2008-2009)
- GMC Sierra 3500 HD (2007-2019)
- Buick LaCrosse (2008-2009)
- Chevrolet Silverado 3500 HD (2007-2019)
- Chevrolet Avalanche (2007-2013)
- Chevrolet Trailblazer (2006-2009)
- Chevrolet Impala (2006-2009)
- Hummer H2 (2003-2009)
- Saab 9-7x (2005-2009)
- Pontiac Grand Prix (2005-2008)
- GMC Envoy (2005-2009)
- Cadillac STS (2005-2006)
- Ford E-350 Super Duty (1999-2004)
- Ford F-150 Heritage (2004)
- Pontiac GTO (2004-2006)
- Chevrolet SSR (2003-2006)
- Cadillac SRX (2004-2006)
- Cadillac CTS (2004-2007)
- Buick Rainier (2004-2007)
- Aston Martin DB7 (2004)
- Mazda MPV (2000-2001)
- Mazda B3000 (1994-1999, 2001-2008)
- Mazda B2500 (1998-2001)
- Mazda B2300 (1994-1997, 2001-2010)
- Jaguar XJ12 (1981-1988)
- Audi V8 Quattro (1990-1991)
- Mazda 6 (2003-2008)
- Mercedes-Benz 300TE (1988-1993)
- Mercedes-Benz 300SEL (1988-1991)
- Mercedes-Benz 300SE (1988-1991)
- Mercedes-Benz 300E (1986-1993)
- Mercedes-Benz 300CE (1988-1989)
- Mercedes-Benz 260E (1987-1989)
- Mercedes-Benz 190E (1984-1993)
- Merkur XR4Ti (1985-1989)
- Ford E-450 Econoline Super Duty (2000-2002)
- Merkur Scorpio (1988-1989)
- Mercury Zephyr (1978-1982)
- Mercury Topaz (1984-1988, 1992-1994)
- Mercury Sable (1986-2005)
- Mercury Marquis (1983-1984)
- Mercury Lynx (1982, 1984-1985)
- Mercury LN7 (1982-1983)
- Mercury Cougar (1981-1982, 1984-1986)
- Mercury Capri (1976-1977, 1979-1984)
- Mercury Bobcat (1975-1980)
- Ford Windstar (1995-2000)
- Ford Thunderbird (1983-1988)
- Ford Tempo (1984-1989, 1992-1994)
- Ford Taurus (1986-2007)
- Ford Ranger (1983-2009)
- Ford Probe (1990-1992)
- Ford Pinto (1974-1980)
- Ford Mustang II (1974-1978)
- Ford Mustang (1979-1986, 1991-1993, 2000)
- Ford LTD (1983-1985)
- Ford Granada (1981-1982)
- Ford Fiesta (1980)
- Ford Fairmont (1978-1982)
- Ford F-250 (1997-1999)
- Ford F-150 (1993-1995, 1998, 2000-2003)
- Ford F-100 (1983)
- Ford Escort (1982-1985)
- Ford EXP (1982-1985)
- Ford E-350 Econoline Club Wagon (1997-2002)
- Ford E-350 Club Wagon (2003-2004)
- Ford E-350 Econoline (1997-1998)
- Ford E-250 (2003-2004, 2009-2014)
- Ford E-250 Econoline (1997-2002)
- Ford Econoline Super Duty (1999)
- Ford E-450 Super Duty (2003-2004)
- Ford Courier (1977-1982)
- Ford Bronco II (1984-1990)
- Ford Aerostar (1986-1997)
- Pontiac Sunfire (1998-2002)
- Pontiac Grand Am (1985-1987)
- Pontiac Firebird (1998-2002)
- Pontiac Bonneville (1987-1988)
- Oldsmobile Toronado (1986-1987)
- Oldsmobile Delta 88 (1986-1988)
- Oldsmobile Cutlass Supreme (1991-1995)
- Oldsmobile Cutlass Cruiser (1987-1988)
- Oldsmobile Cutlass Ciera (1986-1988)
- Oldsmobile Cutlass Calais (1988)
- Oldsmobile Calais (1985-1987)
- Oldsmobile 98 (1986-1987)
- GMC Yukon XL 2500 (2000-2013)
- GMC Yukon XL 1500 (2000-2014)
- GMC Yukon (2000-2014)
- GMC Sierra 3500 (2001-2006)
- GMC Sierra 2500 HD (2001-2019)
- GMC Sierra 2500 (1999-2004)
- GMC Sierra 1500 HD (2001-2003, 2005-2006)
- GMC Sierra 1500 (1999-2013)
- GMC Savana 3500 (2003-2020)
- GMC Savana 2500 (2003-2020)
- GMC Savana 1500 (2003-2014)
- GMC Sonoma (1998-2003)
- Chevrolet Vega (1975-1976)
- Chevrolet Tahoe (2000-2014)
- Chevrolet Suburban 2500 (2000-2013)
- Chevrolet Suburban 1500 (2000-2014)
- Chevrolet Silverado 3500 (2001-2006)
- Chevrolet Silverado 2500 HD (2001-2019)
- Chevrolet Silverado 2500 (1999-2004)
- Chevrolet Silverado 1500 HD (2001-2003, 2005-2006)
- Chevrolet Silverado 1500 (1999-2013)
- Chevrolet S10 (1998-2003)
- Chevrolet Monte Carlo (1995, 2006-2007)
- Chevrolet Lumina (1991-1994)
- Chevrolet Express 3500 (2003-2020)
- Chevrolet Express 2500 (2003-2020)
- Chevrolet Express 1500 (2003-2014)
- Chevrolet Corvette (1993-2013)
- Chevrolet Cavalier (1998-2002)
- Chevrolet Camaro (1998-2002, 2010-2015)
- Chevrolet Avalanche 1500 (2002-2006)
- Cadillac XLR (2004-2006)
- Cadillac Escalade (2002-2014)
- Buick Somerset (1986-1987)
- Buick Somerset Regal (1985)
- Buick Skylark (1986-1988)
- Buick Riviera (1986-1987)
- Buick LeSabre (1986-1988)
- Buick Electra (1986-1987)
- Buick Century (1986-1988)
- Eagle Premier (1988-1992)
- Eagle Medallion (1988-1989)
- Dodge Monaco (1990-1992)
- Isuzu Hombre (1998-2000)
- Isuzu Ascender (2003-2006)
- DeLorean DMC 12 (1981-1983)
- Panoz Esperante (2001-2005)
- Panoz AIV Roadster (1999-2000)
- Peugeot 505 (1987-1991)
- Peugeot 604 (1977-1981)
- Renault R18i (1984-1986)
- Renault Fuego (1984-1985)
- Jaguar XJS (1977, 1979-1988)
