NGK SPARK PLUGS BR9ECS Part Description
Manufacturer
Product Description
NGK Standard Spark Plug
Features & Benefits
- ACTUAL OE or EQUIVALENT DESIGN: OEM quality construction nickel alloy center electrode provides consistent performance
- RECOMMENDED USAGE: Best for vehicles with OE nickel alloy plugs, not recommended on vehicles with factory precious metal plugs
- NGK's OE CERAMIC TECHNOLOGY: High grade alumina silicate ceramic creates a stronger insulator for optimal dielectric performance
- SOLID COPPER CORE: 98% pure copper core offers superior heat dissipation, conductivity and ultra wide heat ranges
- COLD-ROLLED THREADS: Prevents cross-threading and damage to cylinder heads
- TRIVALENT METAL PLATING: Delivers superior anti-corrosion and anti-seizing properties, ensuring ease of installation and removal
NGK SPARK PLUGS BR9ECS Specifications
Product Attributes
| Stock Number | 4677 |
| Part Number | BR9ECS |
| Short Style Spark Plug | No |
| Service Number | BR9ECS |
| Resistance | 5000.0 82 |
| Ground Electrode Tip Design | Low Angle |
| Ground Configuration | Slant |
| Ground Electrode Core Material | Nickel |
| Washer(s) Included | Yes |
| Grade Type | Standard Replacement |
| Electrical Terminal Type | Non-Removable Nut |
| Center Electrode Core Material | Copper |
| Center Electrode Tip Material | Nickel |
| Pre-Gap Size | .032 IN |
| Ground Electrode Quantity | 1 |
| Hex Size | 13/16" |
| Insulator Height | 2.15 IN |
| Manufacturer Heat Range | 9 |
| Seat Type | Flat |
| Reach | 0.750 IN |
| Thread Diameter | 0.551 IN |
| Insulator Material | Ceramic |
| Resistor Type | Yes |
| Skirt Length | 0.0 IN |
| Ground Electrode Tip Material | Nickel |
| Skirt | No |
| Center Electrode Insulator Tip Projection | 0.01 IN |
| Center Electrode Design | Standard |
| Washer Type | Crush |
| Center Electrode Projection | Non-Projected |
| Metallurgy | Copper |
| Thread Type Standard | Metric |
| Pre-Gap Size | 0.8 MM |
| Insulator Height | 54.5 MM |
| Reach | 19.0 MM |
| 6648 | 0.0 MM |
| Thread Size | M14 - 1.25 |
| Center Electrode Insulator Tip Projection | 0.3 MM |
Additional Information
| Harmonized Tariff Code (HTS) | 8511100000 |
| Warranty Time UOM | MO |
| Warranty Time | 2 |
| Country of Origin (Primary) | JP |
| UPC | 00087295146774 |
| VMRS Code | 033003005 |
| UNSPSC | 26101732 |
NGK SPARK PLUGS BR9ECS Cross References
| Brand | Part Number |
|---|---|
| ACDelco | S40XLG |
| AUTOLITE | 4062 |
| DENSO Auto Parts | W27ES-C, 4173 |
| E3 SPARK PLUGS | E331 |
| Honda | 98079-59819 |
| N/A | BR9ECS |
| NGK | 4677 |
| Yamaha | 94702-00383, 94709-00383 |
NGK SPARK PLUGS BR9ECS Fits Vehicles
- Ski-Doo GSX 600 Sport SDI (2004)
- Ski-Doo Summit 800 R 50th Anniversary (2009)
- Ski-Doo Renegade Sport 600 Carb (2015-2020)
- Ski-Doo MX Z Sport 600 ACE (2014)
- Ski-Doo MX Z Sport 600 Carb (2014-2020)
- Ski-Doo GTX 800 Limited (2006-2007)
- Ski-Doo Summit Sport 600 Carb (2012-2020)
- Ski-Doo Summit Sport Power TEK 800R (2012-2016)
- Ski-Doo Renegade SP 800R Power TEK (2011)
- Ski-Doo Renegade Backcountry 800R Power TEK (2011)
- Ski-Doo MX Z X-RS 800R (2010)
- Ski-Doo Renegade Adrenaline 800R Power TEK (2011)
- Ski-Doo MX Z TNT 800R Power TEC (2011)
- Ski-Doo MX Z TNT 600 Carb (2012)
- Ski-Doo Grand Touring Sport 600 Carb (2012-2014)
- Ski-Doo Summit SP (2011)
- Ski-Doo Summit Everest 800R Power TEK 163 (2011)
- Ski-Doo Summit Everest 800R Power TEK 146 (2011)
- Ski-Doo Summit Everest 800R Power TEK 154 (2011)
- Ski-Doo Renegade 800 X (2010)
- Ski-Doo Renegade 800 Backcountry (2010)
- Ski-Doo Renegade 800 Backcountry X (2010)
- Ski-Doo Renegade 800 Adrenaline (2010)
- Ski-Doo Summit 800 Everest 163 (2009-2010)
- Ski-Doo Summit 800 Hill Climb (2009-2010)
- Ski-Doo Summit 800 X 154 (2008-2010)
- Ski-Doo Summit 800 Everest 146 (2008-2010)
- Ski-Doo Summit 800 X 163 (2008-2010)
- Ski-Doo Summit 800 X 146 (2008-2010)
- Ski-Doo Summit 800 Everest 154 (2008-2010)
- Ski-Doo MX Z 800R Renegade X (2008)
- Ski-Doo MX Z 800 R X (2008-2010)
- Ski-Doo MX Z 800R Renegade (2008)
- Ski-Doo MX Z 800 R Adrenaline (2008-2010)
- Ski-Doo Summit 800 XRS 159 (2007)
- Ski-Doo Summit 800 XRS 151 (2007)
- Ski-Doo Summit 800 R Everest (2007-2008)
- Ski-Doo MX Z 600 Adrenaline (2007-2008)
- Ski-Doo MX Z 500 X (2007)
- Ski-Doo GTX 500SS Sport (2007)
- Ski-Doo MX Z 800 X-RS (2007, 2010)
- Ski-Doo MX Z 800 Blizzard (2007)
- Ski-Doo GSX 800 Limited (2007-2008)
- Ski-Doo GSX 500SS Sport (2007)
- Ski-Doo Skandic 600 WT (2006-2009)
- Ski-Doo Summit 800 X 159 (2006-2007)
- Ski-Doo Summit 800 X 144 (2006-2007)
- Ski-Doo Summit 800 Adrenaline 144 (2006-2007)
- Ski-Doo Summit 800 X 151 (2006-2007)
- Ski-Doo MX Z 500 Adrenaline (2005-2007)
- Ski-Doo MX Z 500 Trail (2005-2006)
- Ski-Doo MX Z 440 X (2005, 2007)
- Ski-Doo Mach Z 1000 (2005)
- Ski-Doo Summit 800 Adrenaline 151 (2005-2007)
- Ski-Doo MX Z 800 X (2005-2007, 2010)
- Ski-Doo MX Z 800 Renegade (2005-2009)
- Ski-Doo MX Z 800 Renegade X (2005-2009)
- Ski-Doo MX Z 800 Adrenaline (2005-2007)
- Ski-Doo GTX 600 Limited (2005)
- Ski-Doo GSX 600 Limited (2005)
- Ski-Doo Expedition TUV 600 (2005)
- Yamaha SX700S (2000)
- Yamaha VX500SX VMAX 500 SX (1999)
- Yamaha VX700DX VMAX 700 Deluxe (1999)
- Yamaha VX700 VMAX 700 (1999)
- Yamaha VX500ER (1999)
- Yamaha SRX700S (1999-2002)
- Yamaha SRX600 (1999)
- Yamaha SRX700 (1999-2002)
- Yamaha MM600 Mountain Max 600 (1999)
- Yamaha VX700XTCP VMAX 700 XTCP (1998)
- Yamaha VX700XTC VMAX 700 XTC (1998)
- Yamaha VX600SX VMAX 600 SX (1998-1999)
- Yamaha VT600 Venture 600 (1998-1999)
- Yamaha VX700XTCD VMAX 700 XTC Deluxe (1998)
- Yamaha VX700XT VMAX 700 XT (1998)
- Yamaha VX600SXS VMAX 600 SXS (1998)
- Yamaha VX500XTCD VMAX 500 XTC Deluxe (1998)
- Yamaha VX500XTR VMAX 500 XTR (1998)
- Yamaha VX500XT VMAX 500 XT (1997-1998)
- Yamaha VX500XTC VMAX 500 XTC (1997-1998)
- Yamaha VX500E VAMX 500 LE (1996)
- Yamaha VX500 VMAX 500 (1996-1999)
- Yamaha VX500XTW VMX 500 XT Proaction Plus (1996)
- Yamaha VX500DX VMAX 500 DX (1996)
