NGK SPARK PLUGS DPR8EIX9 Part Description
Manufacturer
Product Description
NGK Iridium IX Spark Plug
Features & Benefits
- SINGLE IRIDIUM TIP: Fine wire 0.6 millimeter iridium tip center electrode ensures high durability and a consistently stable spark
- IRIDIUM ALLOY CENTER ELECTRODE: Iridium's density (6x that of platinum) and extremely high melting point is perfect for modern high efficiency engines
- TAPERED CUT GROUND ELECTRODE: Reduced quenching design produces outstanding ignitability, improved acceleration, fuel efficiency and durability
- SOLID COPPER CORE: 98% pure copper core offers superior heat dissipation, conductivity and ultra wide heat ranges
- TRIVALENT METAL PLATING: Delivers superior anti-corrosion and anti-seizing properties, ensuring ease of installation and removal
- RECOMMENDED USAGE: Modified or high performance applications, or as an upgrade to OE nickel alloy spark plugs
NGK SPARK PLUGS DPR8EIX9 Specifications
Product Attributes
| Stock Number | 2202 |
| Part Number | DPR8EIX-9 |
| Short Style Spark Plug | No |
| Service Number | DPR8EIX-9 |
| Resistance | 5000.0 82 |
| Ground Electrode Tip Design | Taper Cut |
| Ground Configuration | J-Gap |
| Ground Electrode Core Material | Nickel |
| Washer(s) Included | Yes |
| Grade Type | Performance |
| Electrical Terminal Type | Removable Nut |
| Center Electrode Core Material | Copper |
| Center Electrode Tip Material | Iridium |
| Pre-Gap Size | .036 IN |
| Ground Electrode Quantity | 1 |
| Hex Size | 18mm |
| Insulator Height | 2.05 IN |
| Manufacturer Heat Range | 8 |
| Seat Type | Flat |
| Reach | 0.750 IN |
| Thread Diameter | 0.472 IN |
| Insulator Material | Ceramic |
| Resistor Type | Yes |
| Skirt Length | 0.0 IN |
| Ground Electrode Tip Material | Nickel |
| Skirt | No |
| Center Electrode Insulator Tip Projection | 0.12 IN |
| Center Electrode Design | Fine Wire |
| Washer Type | Crush |
| Center Electrode Projection | Mid Projection |
| Thread Size | M12 - 1.25 |
| Thread Type Standard | Metric |
| Metallurgy | Single Iridium |
| Pre-Gap Size | 0.9 MM |
| Insulator Height | 52.0 MM |
| Reach | 19.0 MM |
| 6648 | 0.0 MM |
| Center Electrode Insulator Tip Projection | 3.0 MM |
Additional Information
| Warranty Time UOM | MO |
| Warranty Time | 2 |
| Country of Origin (Primary) | JP |
| Harmonized Tariff Code (HTS) | 8511100000 |
| UPC | 00087295122020 |
| VMRS Code | 033003005 |
| UNSPSC | 26101732 |
NGK SPARK PLUGS DPR8EIX9 Cross References
| Brand | Part Number |
|---|---|
| AUTOLITE | XS4163 |
| CHAMPION | 9701 |
| DENSO Auto Parts | 4094, 5376, X24EPR-ZU9, 2202, 4097, IX24B, X24EP-ZU9 |
| Daihatsu | 999-06910-X9-016 |
| E3 SPARK PLUGS | E336 |
| Honda | 98069-58912, 98069-58916-HE, 98069-5891F |
| N/A | DPR8EIX-9 |
| NGK | 2202 |
| Suzuki | 99000-69835-PR8 |
| Yamaha | 90793-20119, 90793-20154, 90793-2B119 |
NGK SPARK PLUGS DPR8EIX9 Fits Vehicles
- Triumph Bonneville T100 Chrome Edition (2022)
- Kawasaki KLR650S ABS (2023-2024)
- Kawasaki KLR650S (2023-2024)
- Kawasaki KLR650 Traveler ABS (2022-2023)
- Triumph Bonneville T100 Gold Line (2022)
- Kawasaki KLR650 Adventure ABS (2022-2024)
- Honda TRX250X (2021-2024)
- Honda TRX250TM FourTrax Recon (2021-2024)
- Honda TRX250TE FourTrax Recon ES (2021-2024)
- Kawasaki KLR650 Traveler (2022)
- Kawasaki KLR650 Adventure (2022-2023)
- Kawasaki KLR650 ABS (2022-2024)
- Honda TRX250TM (2020)
- Honda TRX250X SE (2016)
- Triumph America LT (2015-2016)
- Triumph Thruxton Ace SE (2015)
- Triumph Bonneville T100 Black (2015-2020, 2022)
- Kawasaki KLR650 Camo (2016-2018)
- Triumph Bonneville T214 SE (2015)
- Yamaha XV19CS Raider S (2015)
- Yamaha XV19C Raider Bullet Cowl (2015)
- Yamaha XV19C Raider (2015-2017)
- Kawasaki KLR650 New Edition (2014)
- Yamaha YXR66F Rhino 660 Sport Edition (2007)
- Yamaha YXR66F Rhino 660 Exploring Edition (2006-2007)
- Yamaha YXR66F Rhino 660 Ducks Unlimited (2007)
- Yamaha YXR66F Rhino 660 Special Edition (2006-2007)
- Yamaha XVZ1300CTS Royal Star Tour Deluxe S (2008-2009)
- Triumph Bonneville T100 110th Anniversary LE (2012)
- Yamaha XV19C Raider SCL (2012-2014)
- Triumph Bonneville Steve McQueen SE (2012)
- Triumph Thruxton SE (2011)
- Triumph Bonneville T100 Jet Black (2011)
- Yamaha XVZ1300TFS Royal Star Venture S (2009-2013)
- Yamaha XV1900CT Stratoliner Deluxe (2010-2012, 2014)
- Triumph Bonneville SE (2009-2013)
- Honda CRF230M (2009)
- Yamaha XV19CXC Raider S (2008-2014)
- Yamaha XV19CX Raider (2008-2014)
- Honda CRF230L (2008-2009)
- Yamaha XVZ1300CTM Royal Star Midnight Tour Deluxe (2006-2007)
- Yamaha XV1900CTM Stratoliner Midnight (2006-2008)
- Yamaha XV1900CTS Stratoliner S (2006-2010, 2013-2014)
- Yamaha XV1900S Roadliner S (2006-2010, 2012-2014)
- Yamaha XV1900CT Stratoliner (2006-2007, 2009)
- Yamaha XV1900M Roadliner Midnight (2006-2009)
- Yamaha XV1900 Roadliner (2006-2007)
- Triumph Scrambler (2006-2017)
- Triumph Bonneville T100 (2006-2015, 2017-2018, 2020-2022)
- Suzuki S50 Boulevard (2006-2009)
- Yamaha XVZ1300CT Royal Star Tour Deluxe (2005-2009)
- Suzuki S83 Boulevard (2005-2008)
- Triumph Thruxton (2005-2016)
- Triumph Rocket III (2005-2010)
- Suzuki S40 Boulevard (2005-2009, 2011-2019)
- Triumph Speedmaster (2005-2016)
- Yamaha YXR66F Rhino 660 (2004-2007)
- Suzuki GS500F (2004-2009)
- Kawasaki KVF360 Prairie 4x4 (2003-2012)
- Kawasaki KVF360 Prairie 2x4 (2003-2009)
- Honda CRF230F (2003-2009)
- Yamaha YFM660F Grizzly 4x4 (2002-2008)
- Yamaha XVZ1300TFM Royal Star Midnight Venture (2002-2007)
- Triumph America (2002-2003, 2007-2016)
- Yamaha YFM660R Raptor (2001-2005)
- Triumph Bonneville (2001-2003, 2005-2006, 2014-2015)
- KTM 660 Rally (2001-2002)
- Honda VT750DC Shadow Spirit (2001-2003, 2005-2007)
- Yamaha XVZ1300TF Royal Star Venture (2000, 2002-2009)
- Triumph Sprint ST (1999-2001)
- Triumph Sprint RS (1999-2001)
- Triumph Daytona 955i (1999-2001)
- Triumph Legend TT (1999-2001)
- Kawasaki KVF400 Prairie 2x4 (1999-2002)
- Honda VT600CD Shadow VLX Deluxe (1999-2000, 2006-2007)
- Yamaha YFM600FW Grizzly 4x4 (1998-2001)
- Triumph Thunderbird Sport (1998-2004)
- Triumph Sprint Sport (1998)
- Triumph Speed Triple (1998-2001)
- Triumph Sprint Executive (1998)
- Triumph Speed Triple T509 (1997-2000)
- Triumph Daytona T595 (1997)
- Suzuki VZ800 Marauder (1997-2004)
- Kawasaki KVF400 Prairie 4x4 (1997-2002)
- Kawasaki KLR650 (1997-2018, 2022-2024)
- Triumph Adventurer (1996-2001)
- Kawasaki KLX650R (1996)
- Triumph Trident (1995-1998)
- Triumph Thunderbird (1995-2001, 2010-2013)
- Triumph Tiger (1995-2006)
- Triumph Daytona 900 Super III (1994-1997)
- Triumph Daytona 900 (1994-1996)
- Yamaha GTS1000A (1993-1994)
- Triumph Daytona 1200 (1993-1997)
- Triumph Sprint (1993-1998)
- Kawasaki KLX650 (1993-1996)
- Kawasaki KLF400 Bayou 4x4 (1993-1999)
- Honda XR650L (1993-2009, 2013-2016, 2021-2024)
- Suzuki VS800GL Intruder (1992-2004)
- Honda CB750 Nighthawk (1991-2003)
- Suzuki VX800 (1990-1993)
- Kawasaki VN1500B Vulcan 88 SE (1990)
- Kawasaki VN1500A Vulcan 88 (1990)
- Kawasaki KL650B Tengai (1990)
- Honda CBR600F (1990)
- Suzuki GS500 (1989-2002)
- Honda XL600V Transalp (1989-1990)
- Honda GB500 (1989-1990)
- Suzuki VS750GL Intruder (1988-1991)
- Honda VTR250 Interceptor (1988)
- Honda VF750C Magna (1988)
- Honda TRX300 FourTrax (1988-2000)
- Honda NT650 Hawk GT (1988-1991)
- Honda TRX300FW FourTrax 4x4 (1988, 1990-2000)
- Honda VT600C Shadow VLX (1988-2007)
- Honda NX650 (1988-1989)
- Yamaha FZR750R (1987-1988)
- Yamaha FZR1000 (1987-1995)
- Yamaha FZ700 (1987)
- Suzuki VS1400GL Intruder (1987-1988, 1991-2004)
- Kawasaki KSF250 Mojave (1987-2003)
- Yamaha XVZ1300 Venture Royale (1986-1993)
- Yamaha SRX600 (1986)
- Yamaha FZX700 Fazer (1986-1987)
- Yamaha TT600 (1986)
- Yamaha FJ1200 (1986-1993)
- Kawasaki ZG1200 Voyager XII (1986-2003)
- Honda GL1200SEI Gold Wing Aspencade (1986)
- Honda CMX450C Rebel (1986-1987)
- Yamaha VMX1200 V-Max (1985-1986, 1988-2007)
- Yamaha FZ750 (1985-1988)
- Suzuki VS700 Intruder (1985-1987)
- Honda XR600R (1985-2000)
- Kawasaki KL600 (1985-1986)
- Honda GL1200L Gold Wing Limited (1985)
- Yamaha XT600 (1984-1995)
- Yamaha FJ1100 (1984-1985)
- Honda VF700C Magna (1984-1987)
- Honda GL1200I Gold Wing Interstate (1984-1987)
- Honda VF500F Interceptor (1984-1985)
- Honda VF1000F Interceptor (1984)
- Honda GL1200A Gold Wing Aspencade (1984-1987)
- Honda CB700SC Nighthawk S (1984-1986)
- Honda XL350R (1984-1985)
- Honda VT700C Shadow (1984-1985)
- Honda VF700S Sabre (1984-1985)
- Honda VF500C V30 Magna (1984-1985)
- Honda GL1200 Gold Wing (1984)
- Honda VF700F Interceptor (1984-1985)
- Honda VF1100S V65 Sabre (1984-1985)
- Yamaha XVZ1200 Venture (1983-1984)
- Yamaha XVZ1200D Venture Royale (1983-1985)
- Yamaha XC180 Riva 180 (1983-1985)
- Yamaha XC180Z Riva (1983-1984)
- Honda XR350R (1983-1985)
- Honda XR500R (1983-1984)
- Honda VT500FT Ascot (1983-1984)
- Honda XL600R (1983-1987)
- Honda VT500C Shadow (1983-1986)
- Honda VF1100C V65 Magna (1983-1986)
- Honda VT750C Shadow (1983)
- Honda VF750F V45 Interceptor (1983-1984)
- Honda GL650 Silver Wing (1983)
- Honda CX650C Custom (1983)
- Honda CM450E (1983)
- Honda CM450A Hondamatic (1983)
- Honda CB550SC Nighthawk (1983)
- Honda GL650I Silver Wing Interstate (1983)
- Honda CX650T Turbo (1983)
- Honda CB450SC Nighthawk (1983-1986)
- Honda CB650SC Nighthawk (1983-1985)
- Honda VF750C V45 Magna (1982-1983)
- Honda GL1100A Gold Wing Aspencade (1982-1983)
- Honda GL1100 Gold Wing (1982-1983)
- Honda CX500TC Turbo (1982)
- Honda VF750S V45 Sabre (1982-1983)
- Honda GL1100I Gold Wing Interstate (1982-1983)
