(888) 312-8812 Login SignupNGK SPARK PLUGS TR55IX NGK Iridium IX Spark Plug
Tap to view 3 more
No Stock Available
We cannot fulfill orders for this part at this time. Please check back later or request a stock notification to receive an email.
We may have similar parts for sale. Search Alternatives >
NGK SPARK PLUGS TR55IX Part Description
Manufacturer
Product Description
NGK Iridium IX Spark Plug
Features & Benefits
- SINGLE IRIDIUM TIP: Fine wire 0.6 millimeter iridium tip center electrode ensures high durability and a consistently stable spark
- IRIDIUM ALLOY CENTER ELECTRODE: Iridium's density (6x that of platinum) and extremely high melting point is perfect for modern high efficiency engines
- TAPERED CUT GROUND ELECTRODE: Reduced quenching design produces outstanding ignitability, improved acceleration, fuel efficiency and durability
- SOLID COPPER CORE: 98% pure copper core offers superior heat dissipation, conductivity and ultra wide heat ranges
- TRIVALENT METAL PLATING: Delivers superior anti-corrosion and anti-seizing properties, ensuring ease of installation and removal
- RECOMMENDED USAGE: Modified or high performance applications, or as an upgrade to OE nickel alloy spark plugs
NGK SPARK PLUGS TR55IX Specifications
Product Attributes
| Insulator Material | Ceramic |
| Resistor Type | Yes |
| Skirt Length | 0.0 IN |
| Ground Electrode Tip Material | Nickel |
| Skirt | No |
| Center Electrode Insulator Tip Projection | 0.16 IN |
| Center Electrode Design | Fine Wire |
| Center Electrode Projection | Mid Projection |
| Short Style Spark Plug | No |
| Service Number | TR55IX |
| Part Number | TR55IX |
| Stock Number | 7164 |
| Resistance | 5000.0 82 |
| Ground Electrode Tip Design | Taper Cut |
| Ground Configuration | J-Gap |
| Ground Electrode Core Material | Nickel |
| Washer(s) Included | No |
| Grade Type | Performance |
| Electrical Terminal Type | Non-Removable Nut |
| Center Electrode Core Material | Copper |
| Center Electrode Tip Material | Iridium |
| Pre-Gap Size | .060 IN |
| Ground Electrode Quantity | 1 |
| Hex Size | 5/8" (16mm) |
| Insulator Height | 2.07 IN |
| Manufacturer Heat Range | 5 |
| Seat Type | Tapered |
| Reach | 0.689 IN |
| Thread Diameter | 0.551 IN |
| Thread Size | M14 - 1.25 |
| Metallurgy | Single Iridium |
| Thread Type Standard | Metric |
| Pre-Gap Size | 1.5 MM |
| Insulator Height | 52.5 MM |
| Reach | 17.5 MM |
| 6648 | 0.0 MM |
| Center Electrode Insulator Tip Projection | 4.0 MM |
Additional Information
| Harmonized Tariff Code (HTS) | 8511100000 |
| Warranty Time UOM | MO |
| Warranty Time | 2 |
| Country of Origin (Primary) | US |
| UPC | 00087295171646 |
| VMRS Code | 033003005 |
| UNSPSC | 26101732 |
NGK SPARK PLUGS TR55IX Cross References
| Brand | Part Number |
|---|---|
| ACDelco | 1835464T, 241-932, 241-919, 1835406T, 1835342T, 241-936, 14, 16, 241-947, R44LTS6K, 41-913, 25332828, R45LTS6K, 1835788T, 41-902, 12561466, 15, 12563707, 41-929, 41-932, 41-936, 1835414T, 241-902, 12565753, 41-919, 41-931, 41-947, 41-942, 41-943, 241-908, 241-913, 1835430T, 41-974, 41-952, 12, 92108895, 1835826T, 25332827 |
| Autolite | XP104, XP103, XP105, XP5243, XP5243DP2, XP605DP2, XP606DP2, XP605, XP606, XP5245, XP5245DP2 |
| Beck/Arnley | 1765288 |
| Bosch | HR8KII33Y, 9653, HR8KII33V, 9601, 4459, 6241, 9655, 4458, 4041, HR9KII33Y, HR9DPY |
| CHAMPION | 9808, 7401 |
| Champion Spark Plug | RS14PYP6, 7013, 9404-2, 9404, 9402-2 |
| DENSO Auto Parts | IT16TT, TJ16R15, 4713 |
| E3 SPARK PLUGS | E353 |
| General Motors | 25332827, 25332828 |
| Motorcraft | AWSF42EE, SP432, AWSF32F |
| N/A | TR55IX |
| NGK | 7164 |
| Nissan | BY485-TR55X |
| Omnicraft | QSP10 |
NGK SPARK PLUGS TR55IX Fits Vehicles
- Ford Explorer Sport (2001-2003)
- GMC Sierra 3500 Classic (2007)
- Chevrolet Silverado 3500 Classic (2007)
- Chevrolet Silverado 2500 HD Classic (2007)
- Chevrolet Silverado 1500 Classic (2007)
- GMC Sierra 2500 HD Classic (2007)
- GMC Sierra 1500 Classic (2007)
- Saturn Relay (2005-2006)
- Chevrolet C3500HD (1996-2002)
- GMC C3500HD (1996-2002)
- Ford F-53 Motorhome Chassis (1999-2004)
- Ford Focus (2011)
- Ford Transit Connect (2010-2013)
- GMC C7500 Topkick (1999-2009)
- Chevrolet C6500 Kodiak (1999-2009)
- GMC C6500 Topkick (1999-2009)
- Chevrolet C7500 Kodiak (1999-2009)
- GMC C5500 Topkick (2003-2009)
- Chevrolet C5500 Kodiak (2003-2009)
- GMC C4500 Topkick (2003-2009)
- Chevrolet C4500 Kodiak (2003-2009)
- Ford E-550 Super Duty (2003)
- Cadillac XLR (2007-2009)
- Cadillac SRX (2007-2009)
- Cadillac STS (2007-2010)
- Buick Allure (2005-2009)
- Buick Lucerne (2006-2011)
- Mazda 5 (2006-2007)
- Lincoln Zephyr (2006)
- Mercury Milan (2006-2009)
- Ford Fusion (2006-2009)
- Cadillac DTS (2006-2011)
- Pontiac Torrent (2006-2009)
- Ford Explorer Sport Trac (2001-2005)
- Mercury Montego (2005-2007)
- Ford Freestyle (2005-2007)
- Ford Five Hundred (2005-2007)
- Mercury Mariner (2005-2008)
- Pontiac G6 (2005-2006)
- Chevrolet Uplander (2005-2006)
- Buick LaCrosse (2005-2009)
- Buick Terraza (2005-2006)
- Chevrolet Equinox (2005-2009)
- Ford E-350 Super Duty (1999-2019)
- Ford F-150 Heritage (2004)
- Mercury Monterey (2004-2005)
- Ford Freestar (2004-2005)
- Mazda B4000 (1994-1996)
- Mazda MPV (2002-2006)
- Mazda Navajo (1991-1994)
- Mazda 6 (2003-2005)
- Mazda Tribute (2001-2006, 2008)
- Aston Martin DB7 (2002-2003)
- Ford E-550 Econoline Super Duty (2002)
- Ford E-450 Econoline Super Duty (1999-2002)
- Mercury Topaz (1989-1994)
- Mercury Sable (1996-2005)
- Mercury Mystique (1995-2000)
- Mercury Mountaineer (1997-2005)
- Mercury Marauder (2003-2004)
- Mercury Grand Marquis (1992-2010)
- Mercury Cougar (1994-1997, 1999-2002)
- Lincoln Town Car (1991-2011)
- Lincoln Navigator (1998-2004)
- Lincoln Mark VIII (1993-1998)
- Lincoln LS (2000-2005)
- Lincoln Continental (1995-2002)
- Lincoln Blackwood (2002)
- Lincoln Aviator (2003-2005)
- Ford Windstar (1996-2003)
- Ford Thunderbird (1994-1997)
- Ford Tempo (1989-1994)
- Ford Taurus (1996-2005)
- Ford Ranger (1990-1996, 2008, 2010-2011)
- Ford Mustang (1993-2004)
- Ford Fiesta (1978-1979)
- Ford F-550 Super Duty (1999-2004)
- Ford F-450 Super Duty (1999-2004)
- Ford F-350 Super Duty (1999-2004)
- Ford F-250 Super Duty (1999-2004)
- Ford F-250 (1997-1999)
- Ford F-150 (1997-2010)
- Ford Explorer (1991-2005)
- Ford Expedition (1997-2004)
- Ford Excursion (2000-2005)
- Ford Escape (2001-2008)
- Ford E-350 Econoline Club Wagon (1997-2002)
- Ford E-350 Club Wagon (2003-2005)
- Ford E-350 Econoline (1997-1998)
- Ford E-250 (2003-2014)
- Ford E-250 Econoline (1997-2002)
- Ford E-150 Econoline Club Wagon (1997-2002)
- Ford E-150 Club Wagon (2003-2005)
- Ford E-150 (2003-2014)
- Ford E-150 Econoline (1997-2002)
- Ford Econoline Super Duty (1997-1999)
- Ford E-450 Super Duty (2003-2019)
- Ford Crown Victoria (1992-2011)
- Ford Contour (1995-2000)
- Ford Aerostar (1990-1997)
- Pontiac Trans Sport (1992-1999)
- Pontiac Sunfire (1995-2002)
- Pontiac Montana (1999-2006)
- Pontiac Grand Prix (1991-2008)
- Pontiac Grand Am (1992-2005)
- Pontiac Firebird (1993-2002)
- Pontiac Bonneville (1988-2005)
- Pontiac Aztek (2001-2005)
- Oldsmobile Toronado (1988-1992)
- Oldsmobile Regency (1997-1998)
- Oldsmobile Silhouette (1992-2004)
- Oldsmobile LSS (1996-1999)
- Oldsmobile Intrigue (1998-2002)
- Oldsmobile 88 (1992-1999)
- Oldsmobile Delta 88 (1988-1991)
- Oldsmobile Cutlass Supreme (1993-1997)
- Oldsmobile Cutlass Cruiser (1989-1994)
- Oldsmobile Cutlass Calais (1989-1991)
- Oldsmobile Cutlass (1997-1999)
- Oldsmobile Cutlass Ciera (1989-1996)
- Oldsmobile Bravada (1996-2001)
- Oldsmobile Aurora (1995-1999, 2001-2003)
- Oldsmobile Alero (1999-2004)
- Oldsmobile 98 (1988-1996)
- Oldsmobile Achieva (1992-1998)
- GMC Yukon XL 2500 (2001-2006)
- GMC Yukon (1996-2000)
- GMC Sierra 3500 (2001-2006)
- GMC Sierra 2500 HD (2001-2006)
- GMC Sierra 1500 (1999-2013)
- GMC Safari (1996-2005)
- GMC Sonoma (1996-2004)
- GMC Jimmy (1996-2005)
- GMC P3500 (1996-1999)
- GMC K3500 (1996-2000)
- GMC K2500 Suburban (1996-1999)
- GMC K2500 (1996-2000)
- GMC K1500 Suburban (1996-1999)
- GMC K1500 (1996-1999)
- GMC G3500 (1996)
- GMC Savana 3500 (1996-2002)
- GMC Savana 2500 (1996-2006)
- GMC Savana 1500 (1996-2014)
- GMC C3500 (1996-2000)
- GMC C2500 Suburban (1996-1999)
- GMC C2500 (1996-2000)
- GMC C1500 Suburban (1996-1999)
- GMC C1500 (1996-1999)
- Chevrolet Venture (1997-2005)
- Chevrolet Tahoe (1996-2000)
- Chevrolet Suburban 2500 (2001-2006)
- Chevrolet Silverado 3500 (2001-2006)
- Chevrolet Silverado 2500 HD (2001-2006)
- Chevrolet Silverado 1500 (1999-2013)
- Chevrolet S10 (1996-2004)
- Chevrolet Blazer (1996-2005)
- Chevrolet P30 (1996-1999)
- Chevrolet Monte Carlo (1995-2005)
- Chevrolet Malibu (1997-2006)
- Chevrolet Lumina APV (1992-1996)
- Chevrolet Lumina (1995-2001)
- Chevrolet K3500 (1996-2000)
- Chevrolet K2500 Suburban (1996-1999)
- Chevrolet K2500 (1992-1993, 1996-2000)
- Chevrolet K1500 Suburban (1996-1999)
- Chevrolet K1500 (1996-1999)
- Chevrolet Impala (1994-1996, 2000-2005)
- Chevrolet G30 (1995-1996)
- Chevrolet Express 3500 (1996-2002)
- Chevrolet Express 2500 (1996-2006)
- Chevrolet Express 1500 (1996-2014)
- Chevrolet Corvette (1992-1996)
- Chevrolet Corsica (1994-1996)
- Chevrolet Cavalier (1995-2002)
- Chevrolet Caprice (1994-1996)
- Chevrolet Camaro (1993-2002)
- Chevrolet C3500 (1996-2000)
- Chevrolet C2500 Suburban (1996-1999)
- Chevrolet C2500 (1992-1993, 1996-2000)
- Chevrolet C1500 Suburban (1996-1999)
- Chevrolet C1500 (1996-1999)
- Chevrolet Beretta (1994-1996)
- Chevrolet Avalanche 2500 (2002-2006)
- Chevrolet Astro (1996-2005)
- Cadillac Seville (1982-2004)
- Cadillac 60 Special (1993)
- Cadillac Fleetwood (1982-1992, 1994-1996)
- Cadillac Escalade (1999-2000)
- Cadillac Eldorado (1982-2002)
- Cadillac DeVille (1982-2005)
- Cadillac Commercial Chassis (1985-1996)
- Cadillac Allante (1987-1993)
- Buick Skylark (1989-1998)
- Buick Commercial Chassis (1994-1996)
- Buick Roadmaster (1994-1996)
- Buick Riviera (1988-1993, 1995-1999)
- Buick Rendezvous (2002-2007)
- Buick Regal (1990-2004)
- Buick Reatta (1988-1991)
- Buick Park Avenue (1991-2005)
- Buick LeSabre (1988-2005)
- Buick Electra (1988-1990)
- Buick Century (1989-2005)
- Isuzu Hombre (1997-2000)
