NGK SPARK PLUGS BR8ET Part Description
Manufacturer
Product Description
NGK Standard Spark Plug
Features & Benefits
- ACTUAL OE or EQUIVALENT DESIGN: OEM quality construction nickel alloy center electrode provides consistent performance
- RECOMMENDED USAGE: Best for vehicles with OE nickel alloy plugs, not recommended on vehicles with factory precious metal plugs
- NGK's OE CERAMIC TECHNOLOGY: High grade alumina silicate ceramic creates a stronger insulator for optimal dielectric performance
- SOLID COPPER CORE: 98% pure copper core offers superior heat dissipation, conductivity and ultra wide heat ranges
- COLD-ROLLED THREADS: Prevents cross-threading and damage to cylinder heads
- TRIVALENT METAL PLATING: Delivers superior anti-corrosion and anti-seizing properties, ensuring ease of installation and removal
NGK SPARK PLUGS BR8ET Specifications
Product Attributes
| Stock Number | 6612 |
| Part Number | BR8ET |
| Short Style Spark Plug | No |
| Service Number | BR8ET |
| Resistance | 5000.0 82 |
| Ground Electrode Tip Design | Standard |
| Ground Configuration | Multi-Ground Electrode |
| Ground Electrode Core Material | Nickel |
| Washer(s) Included | Yes |
| Grade Type | Standard Replacement |
| Electrical Terminal Type | Non-Removable Nut |
| Center Electrode Core Material | Copper |
| Center Electrode Tip Material | Nickel |
| Pre-Gap Size | .041 IN |
| Ground Electrode Quantity | 3 |
| Hex Size | 13/16" |
| Insulator Height | 2.13 IN |
| Manufacturer Heat Range | 8 |
| Seat Type | Flat |
| Reach | 0.768 IN |
| Thread Diameter | 0.551 IN |
| Insulator Material | Ceramic |
| Resistor Type | Yes |
| Skirt Length | 0.0 IN |
| Ground Electrode Tip Material | Nickel |
| Skirt | No |
| Center Electrode Insulator Tip Projection | 0.10 IN |
| Center Electrode Design | Standard |
| Washer Type | Crush |
| Center Electrode Projection | Mid Projection |
| Metallurgy | Copper |
| Thread Type Standard | Metric |
| Pre-Gap Size | 1.05 MM |
| Insulator Height | 54.0 MM |
| Reach | 19.5 MM |
| 6648 | 0.0 MM |
| Thread Size | M14 - 1.25 |
| Center Electrode Insulator Tip Projection | 2.6 MM |
Additional Information
| Harmonized Tariff Code (HTS) | 8511100000 |
| Warranty Time UOM | MO |
| Warranty Time | 2 |
| Country of Origin (Primary) | JP |
| UPC | 00087295166123 |
| VMRS Code | 033003005 |
| UNSPSC | 26101732 |
NGK SPARK PLUGS BR8ET Cross References
| Brand | Part Number |
|---|---|
| AUTOLITE | 2526 |
| Beck/Arnley | 1765124, 1765221 |
| Bosch | WR3CTC |
| CHAMPION | 818 |
| DENSO Auto Parts | 3102, W25EA, W25EBR, 3100, 3103, W25EB |
| Mazda | 0000-18-3649, 0867-18-600, 2359-18-600, 3649-18-600, 3744-18-600 |
| Motorcraft | AGR16C |
| N/A | BR8ET |
| NGK | 6612 |
NGK SPARK PLUGS BR8ET Fits Vehicles
- Mazda RX-7 (1980)
