NGK SPARK PLUGS DR7EA Part Description
Manufacturer
Product Description
NGK Standard Spark Plug
Features & Benefits
- ACTUAL OE or EQUIVALENT DESIGN: OEM quality construction nickel alloy center electrode provides consistent performance
- RECOMMENDED USAGE: Best for vehicles with OE nickel alloy plugs, not recommended on vehicles with factory precious metal plugs
- NGK's OE CERAMIC TECHNOLOGY: High grade alumina silicate ceramic creates a stronger insulator for optimal dielectric performance
- SOLID COPPER CORE: 98% pure copper core offers superior heat dissipation, conductivity and ultra wide heat ranges
- COLD-ROLLED THREADS: Prevents cross-threading and damage to cylinder heads
- TRIVALENT METAL PLATING: Delivers superior anti-corrosion and anti-seizing properties, ensuring ease of installation and removal
NGK SPARK PLUGS DR7EA Specifications
Product Attributes
| Part Number | DR7EA |
| Stock Number | 7839 |
| Short Style Spark Plug | No |
| Service Number | DR7EA |
| Resistance | 5000.0 82 |
| Ground Electrode Tip Design | Standard |
| Ground Configuration | J-Gap |
| Ground Electrode Core Material | Nickel |
| Washer(s) Included | Yes |
| Grade Type | Standard Replacement |
| Electrical Terminal Type | Stud |
| Center Electrode Core Material | Copper |
| Center Electrode Tip Material | Nickel |
| Pre-Gap Size | .028 IN |
| Ground Electrode Quantity | 1 |
| Hex Size | 18mm |
| Insulator Height | 1.97 IN |
| Manufacturer Heat Range | 7 |
| Seat Type | Flat |
| Reach | 0.750 IN |
| Thread Diameter | 0.472 IN |
| Insulator Material | Ceramic |
| Resistor Type | Yes |
| Skirt Length | 0.0 IN |
| Ground Electrode Tip Material | Nickel |
| Skirt | No |
| Center Electrode Insulator Tip Projection | 0.06 IN |
| Center Electrode Design | Standard |
| Washer Type | Crush |
| Center Electrode Projection | Non-Projected |
| Metallurgy | Copper |
| Thread Type Standard | Metric |
| Pre-Gap Size | 0.7 MM |
| Insulator Height | 50.0 MM |
| Reach | 19.0 MM |
| 6648 | 0.0 MM |
| Thread Size | M12 - 1.25 |
| Center Electrode Insulator Tip Projection | 1.6 MM |
Additional Information
| Harmonized Tariff Code (HTS) | 8511100000 |
| Warranty Time UOM | MO |
| Warranty Time | 2 |
| Country of Origin (Primary) | JP |
| UPC | 00087295178393 |
| VMRS Code | 033003005 |
| UNSPSC | 26101732 |
NGK SPARK PLUGS DR7EA Cross References
| Brand | Part Number |
|---|---|
| AUTOLITE | 4163 |
| Arctic Cat | 0217-713 |
| Bosch | 7409 |
| CHAMPION | 810 |
| Champion Spark Plug | RAX96C |
| E3 SPARK PLUGS | E336 |
| Honda | 98069-5771P |
| Kawasaki | 92070-1165 |
| MOOG | 810 |
| N/A | X22ESR-U, 09482-00220, 98069-57719, 90793-20076, 94701-20076, 4091, 92070-1113, DR7EA |
| NGK | 7839 |
| SYM | 98069-5771P-00 |
| Suzuki | 09482-00398 |
| Yamaha | 94701-00345, 94703-00345 |
| Yanmar | 182001-26760 |
NGK SPARK PLUGS DR7EA Fits Vehicles
- Suzuki C50T Boulevard (2021-2023)
- Suzuki C50 Boulevard (2021-2023)
- Yamaha YFM450 Kodiak 450 EPS SE (2019-2020)
- Yamaha YFM450 Kodiak 450 EPS (2018-2020)
- Yamaha YFM450 Kodiak 450 (2018-2020)
- Suzuki M50 Boulevard (2013, 2015-2019)
- Yamaha YFM250R Raptor (2011)
- Yamaha YFM250 Raptor SE Custom (2008)
- Yamaha YFM250 Raptor (2008-2013)
- Yamaha XT250 (2008-2019)
- Yamaha YFM250 Raptor SE (2008)
- Yamaha YFM250 Big Bear (2007-2009)
- Yamaha YFM250 Bruin (2005-2006)
- Arctic Cat 300 4x4 MRP (2004)
- Suzuki LT-F250 Ozark (2002-2009, 2012-2014)
- Arctic Cat 250 4x4 (2001-2005)
- Yamaha YFB250FW Timberwolf 4x4 (2000)
- Yamaha YFM250 Bear Tracker (1999-2004)
- Suzuki LT-F250F QuadRunner 4x4 (1999-2002)
- Arctic Cat 250 2x4 (1999-2005)
- Arctic Cat 300 2x4 (1998-2003)
- Arctic Cat 300 4x4 (1998-2005)
- BMW K1100LT Special Edition (1997)
- BMW K1100LT High Line (1997)
- BMW K1100RS SE (1996)
- BMW K1100RS (1993-1996)
- BMW K1100LT (1993-1998)
- BMW K100RS FL (1991-1992)
- BMW K100RS FL ABS (1991-1992)
- BMW M3 (1988-1991)
- BMW M6 (1987-1988)
- BMW M5 (1988)
