(888) 312-8812 Login SignupNGK SPARK PLUGS BR6ES NGK Standard Spark Plug
Tap to view 4 more
No Stock Available
We cannot fulfill orders for this part at this time. Please check back later or request a stock notification to receive an email.
We may have similar parts for sale. Search Alternatives >
NGK SPARK PLUGS BR6ES Part Description
Manufacturer
Product Description
NGK Standard Spark Plug
Features & Benefits
- ACTUAL OE or EQUIVALENT DESIGN: OEM quality construction nickel alloy center electrode provides consistent performance
- RECOMMENDED USAGE: Best for vehicles with OE nickel alloy plugs, not recommended on vehicles with factory precious metal plugs
- NGK's OE CERAMIC TECHNOLOGY: High grade alumina silicate ceramic creates a stronger insulator for optimal dielectric performance
- SOLID COPPER CORE: 98% pure copper core offers superior heat dissipation, conductivity and ultra wide heat ranges
- COLD-ROLLED THREADS: Prevents cross-threading and damage to cylinder heads
- TRIVALENT METAL PLATING: Delivers superior anti-corrosion and anti-seizing properties, ensuring ease of installation and removal
NGK SPARK PLUGS BR6ES Specifications
Product Attributes
| Part Number | BR6ES |
| Stock Number | 4922 |
| Short Style Spark Plug | No |
| Service Number | BR6ES |
| Resistance | 5000.0 82 |
| Ground Electrode Tip Design | Standard |
| Ground Configuration | J-Gap |
| Ground Electrode Core Material | Nickel |
| Washer(s) Included | Yes |
| Grade Type | Standard Replacement |
| Electrical Terminal Type | Removable Nut |
| Center Electrode Core Material | Copper |
| Center Electrode Tip Material | Nickel |
| Pre-Gap Size | .036 IN |
| Ground Electrode Quantity | 1 |
| Hex Size | 13/16" |
| Insulator Height | 2.13 IN |
| Manufacturer Heat Range | 6 |
| Seat Type | Flat |
| Reach | 0.750 IN |
| Thread Diameter | 0.551 IN |
| Insulator Material | Ceramic |
| Resistor Type | Yes |
| Skirt Length | 0.0 IN |
| Ground Electrode Tip Material | Nickel |
| Skirt | No |
| Center Electrode Insulator Tip Projection | 0.04 IN |
| Center Electrode Design | Standard |
| Washer Type | Crush |
| Center Electrode Projection | Non-Projected |
| Metallurgy | Copper |
| Thread Type Standard | Metric |
| Pre-Gap Size | 0.9 MM |
| Insulator Height | 54.0 MM |
| Reach | 19.0 MM |
| 6648 | 0.0 MM |
| Thread Size | M14 - 1.25 |
| Center Electrode Insulator Tip Projection | 1.0 MM |
Additional Information
| Harmonized Tariff Code (HTS) | 8511100000 |
| Warranty Time UOM | MO |
| Warranty Time | 2 |
| Country of Origin (Primary) | JP |
| UPC | 00087295149225 |
| VMRS Code | 033003005 |
| UNSPSC | 26101732 |
NGK SPARK PLUGS BR6ES Cross References
NGK SPARK PLUGS BR6ES Fits Vehicles
- Austin Healey 100-6 (1956-1960)
- Polaris 120 INDY (2014-2019)
- Triumph Bonneville 750 T140E America (1979)
- Triumph Bonneville 750 T140E Final Edition (1981)
- Triumph Bonneville 750 T140ES (1979)
- Triumph Bonneville 750 T140D (1979, 1981)
- Polaris 120 Pro-R (2012-2013)
- Beta TR35 (1989-1991)
- Beta TR32 125 (1984-1985)
- Beta TR34 260 (1986-1990)
- Beta TR34 125 (1990, 1996-1998)
- Beta TR240 125 (1983-1984)
- Morris Minor (1970-1971)
- Nissan 411 (1967)
- Nissan 1600 (1966-1970)
- Polaris 120 Assault (2011)
- Polaris 120 Dragon (2007-2010)
- Polaris 120 Pro X (2004-2006)
- Polaris 120 XC SP (2001-2003)
- Polaris 120 XCR (2000)
- Kawasaki KZ750N Spectre (1983)
- Kawasaki KZ750F LTD Shaft (1983)
- Kawasaki KZ750K LTD Belt (1983)
- Kawasaki KZ750L (1983)
- Kawasaki KZ750H LTD (1983)
- Kawasaki KZ750M CSR (1982)
- Kawasaki KZ750G LTD II (1980)
- Suzuki TS400 (1976-1977)
- Kawasaki KZ750B/E (1976-1979)
- Yamaha SM292 (1973-1974)
- Suzuki GT750 Le Mans (1972-1974)
- Volkswagen Transporter (1973, 1985-1991)
- Renault R17 (1972, 1974)
- Renault R16 (1969-1972)
- Renault R15 (1972-1974)
- Renault R12 (1971-1974)
- Nissan 620 Pickup (1972-1974)
- Nissan 610 (1973)
- Nissan 521 Pickup (1969-1972)
- Nissan 510 (1968-1973)
- MG ZB (1957-1958)
- MG MGA (1956-1958, 1960-1962)
- GMC Suburban (1966)
- GMC PB15 Series (1966)
- GMC PB25 Series (1966)
- GMC P35/P3500 Van (1967-1969)
- GMC P25/P2500 Van (1967-1969)
- GMC P15/P1500 Van (1967)
- GMC K35/K3500 Pickup (1968-1969)
- GMC K25/K2500 Suburban (1967-1969)
- GMC K25/K2500 Pickup (1967)
- GMC K15/K1500 Suburban (1967-1968)
- GMC K15/K1500 Pickup (1967)
- GMC C35/C3500 Pickup (1967-1969)
- GMC C25/C2500 Suburban (1967-1969)
- GMC C25/C2500 Pickup (1967-1969)
- GMC C15/C1500 Suburban (1967-1969)
- GMC C15/C1500 Pickup (1967-1969)
- Chevrolet Suburban (1961, 1963-1966)
- Chevrolet P30 Van (1968-1969)
- Chevrolet P30 Series (1961-1962, 1964-1967)
- Chevrolet P20 Van (1968-1969)
- Chevrolet P20 Series (1961, 1964-1967)
- Chevrolet P10 Series (1967)
- Chevrolet K30 Pickup (1968-1969)
- Chevrolet K20 Suburban (1968-1969)
- Chevrolet K20 Pickup (1961, 1964-1967)
- Chevrolet K10 Pickup (1964-1966)
- Chevrolet Corvette (1965)
- Chevrolet C30 Pickup (1961, 1963-1969)
- Chevrolet C20 Suburban (1968-1969)
- Chevrolet C20 Pickup (1961, 1963-1969)
- Chevrolet C10 Suburban (1968-1969)
- Chevrolet C10 Pickup (1963-1969)
- Volkswagen Vanagon (1983-1991)
- Nissan 280Z (1975-1976)
- Honda Civic (1975-1979)
- Honda Accord (1976-1978)
- Porsche 914 (1970-1976)
