NGK SPARK PLUGS PTR5A13 Part Description
Manufacturer
Product Description
NGK Laser Platinum Spark Plug
Features & Benefits
- ACTUAL OE or EQUIVALENT DESIGN: OEM quality construction fine wire platinum alloy center electrode provides consistent performance
- PLATINUM ALLOY CENTER ELECTRODE: Longer wearing and higher temperature resistance compared to traditional nickel spark plugs
- PLATINUM TIP GROUND ELECTRODE: Unless OE specified, platinum protection at the ground electrode provides excellent ignitability and service life
- SOLID COPPER CORE: 98% pure copper core offers superior heat dissipation, conductivity and ultra wide heat ranges
- TRIVALENT METAL PLATING: Delivers superior anti-corrosion and anti-seizing properties, ensuring ease of installation and removal
- RECOMMENDED USAGE: Best for vehicles with OE fine wire platinum alloy plugs
NGK SPARK PLUGS PTR5A13 Specifications
Product Attributes
| Short Style Spark Plug | No |
| Stock Number | 2467 |
| Part Number | PTR5A-13 |
| Service Number | PTR5A-13 |
| Resistance | 5000.0 82 |
| Ground Electrode Tip Design | Standard |
| Ground Configuration | J-Gap |
| Ground Electrode Core Material | Nickel |
| Washer(s) Included | No |
| Grade Type | Performance |
| Electrical Terminal Type | Non-Removable Nut |
| Center Electrode Core Material | Copper |
| Center Electrode Tip Material | Platinum |
| Pre-Gap Size | .052 IN |
| Ground Electrode Quantity | 1 |
| Hex Size | 5/8" (16mm) |
| Insulator Height | 2.07 IN |
| Manufacturer Heat Range | 5 |
| Seat Type | Tapered |
| Reach | 0.984 IN |
| Thread Diameter | 0.551 IN |
| Insulator Material | Ceramic |
| Resistor Type | Yes |
| Skirt Length | 0.0 IN |
| Ground Electrode Tip Material | Platinum |
| Skirt | No |
| Center Electrode Insulator Tip Projection | 0.14 IN |
| Center Electrode Design | Fine Wire |
| Center Electrode Projection | Mid Projection |
| Thread Size | M14 - 1.25 |
| Metallurgy | Double Platinum |
| Thread Type Standard | Metric |
| Pre-Gap Size | 1.3 MM |
| Insulator Height | 52.5 MM |
| Reach | 25.0 MM |
| 6648 | 0.0 MM |
| Center Electrode Insulator Tip Projection | 3.5 MM |
Additional Information
| Harmonized Tariff Code (HTS) | 8511100000 |
| Warranty Time UOM | MO |
| Warranty Time | 2 |
| Country of Origin (Primary) | JP |
| UPC | 00087295124673 |
| VMRS Code | 033003005 |
| UNSPSC | 26101732 |
NGK SPARK PLUGS PTR5A13 Cross References
| Brand | Part Number |
|---|---|
| ACDelco | 41-834, 41-955, 41-965, 41-814, 41-981, 41-990, 12597464 |
| AUTOLITE | APP605 |
| Autolite | APP5364, APP5344, APP5364DP2 |
| Beck/Arnley | 1765304 |
| Bosch | HGR8MQP, HGR8MDP, HR7MPP, 7412, HR7MPP22V, 4315, 8107, HGR8MQP0, HR7MPP33X, 8114, HR8MPP33X |
| CHAMPION | 7437 |
| Champion Spark Plug | RE7PYP6, 7981-2, 7981, 7437, 7437-2 |
| DENSO Auto Parts | PT16VR13, 4513, 5068, PTV16TT, ITV16TT, 4718 |
| E3 SPARK PLUGS | E374 |
| MOOG | 7437 |
| Magneti Marelli | 61850023304, 8LDCR |
| Motorcraft | SP411, AYFS22FM, AYFS22PP, AYFS22PP1, AYRF22P, AYRF22PP, AZFS22FE, AZFS32FE, AZFS22PP, SP469, SP478, SP487, SP524, AYFS092FE1, AYFS22C, AYFS22FPM1 |
| N/A | PTR5A-13 |
| NGK | 2467 |
| Torch | QH5RTPP-13 |
NGK SPARK PLUGS PTR5A13 Fits Vehicles
- Mazda CX-9 (2007-2015)
- Chevrolet Trailblazer EXT (2002-2005)
- GMC Envoy XL (2002-2005)
- GMC Envoy XUV (2004-2005)
- Ford Transit Connect (2014-2017)
- Ford C-Max (2013-2017)
- Mazda 3 Sport (2009-2010, 2012-2013)
- Mazda CX-7 (2010-2012)
- Lincoln MKT (2010-2012)
- Hummer H3T (2009)
- Mercury Mariner (2009-2011)
- Ford Flex (2009-2012)
- Lincoln MKS (2009-2012)
- Mazda 5 (2008-2010, 2012-2015)
- Ford Taurus X (2008-2009)
- Mercury Sable (2008-2009)
- Ford Taurus (2008-2012)
- Ford Edge (2007-2011)
- Lincoln MKZ (2007-2017)
- Lincoln MKX (2007-2010)
- Hummer H3 (2007-2009)
- Saab 9-7x (2006-2009)
- Mazda 6 (2006-2013)
- Mazda 3 (2006-2013)
- Mercury Milan (2006-2011)
- Ford Fusion (2006-2018)
- Isuzu i-350 (2006)
- Chevrolet Colorado (2004-2006, 2008-2009)
- GMC Canyon (2004-2006, 2008-2009)
- Buick Rainier (2004-2005)
- Mazda Tribute (2001-2004, 2009-2011)
- Mercury Mystique (1995-2000)
- Mercury Cougar (1999-2002)
- Ford Focus (2000-2004)
- Ford Escort (1998-2003)
- Ford Escape (2001-2004, 2009-2017)
- Ford Contour (1995-2000)
- Oldsmobile Bravada (2003-2004)
- GMC Envoy (2003-2005, 2008-2009)
- Chevrolet Trailblazer (2003-2005, 2008-2009)
- Chevrolet Cavalier (2003-2004)
- Isuzu Ascender (2003-2005)
