NGK SPARK PLUGS GR45GP Part Description
Manufacturer
Product Description
NGK G-Power Platinum Spark Plug
Features & Benefits
- SINGLE PLATINUM TIP: Fine wire 0.6 millimeter platinum tip center electrode ensures improved durability and a consistently stable spark
- PLATINUM ALLOY: G-Power platinum provides exceptional value with increased performance and longer service intervals than factory nickel plugs
- TRAPEZOIDAL CUT GROUND ELECTRODE: Reduces quenching design produces improved ignitability and performance
- SOLID COPPER CORE: 98% pure copper core offers superior heat dissipation, conductivity and ultra wide heat ranges
- COLD-ROLLED THREADS: Prevents cross-threading and damage to cylinder heads
- RECOMMENDED USAGE: Lower cost alternative to double precious metal spark plugs or as an upgrade to OE nickel alloy spark plugs
NGK SPARK PLUGS GR45GP Specifications
Product Attributes
| Part Number | GR45GP |
| Stock Number | 3142 |
| Short Style Spark Plug | No |
| Service Number | GR45GP |
| Resistance | 5000.0 82 |
| Ground Electrode Tip Design | Trapezoid |
| Ground Configuration | J-Gap |
| Ground Electrode Core Material | Nickel |
| Washer(s) Included | Yes |
| Grade Type | Standard Replacement |
| Electrical Terminal Type | Non-Removable Nut |
| Center Electrode Core Material | Copper |
| Center Electrode Tip Material | Platinum |
| Pre-Gap Size | .060 IN |
| Ground Electrode Quantity | 1 |
| Hex Size | 13/16" |
| Insulator Height | 2.20 IN |
| Manufacturer Heat Range | 4 |
| Seat Type | Flat |
| Reach | 0.750 IN |
| Thread Diameter | 0.551 IN |
| Insulator Material | Ceramic |
| Resistor Type | Yes |
| Skirt Length | 0.0 IN |
| Ground Electrode Tip Material | Nickel |
| Skirt | No |
| Center Electrode Insulator Tip Projection | 0.16 IN |
| Center Electrode Design | Fine Wire |
| Washer Type | Crush |
| Center Electrode Projection | Mid Projection |
| Thread Size | M14 - 1.25 |
| Metallurgy | Single Platinum |
| Thread Type Standard | Metric |
| Pre-Gap Size | 1.5 MM |
| Insulator Height | 56.0 MM |
| Reach | 19.0 MM |
| 6648 | 0.0 MM |
| Center Electrode Insulator Tip Projection | 4.0 MM |
Additional Information
| Harmonized Tariff Code (HTS) | 8511100000 |
| Warranty Time UOM | MO |
| Warranty Time | 2 |
| Country of Origin (Primary) | JP |
| UPC | 00087295131428 |
| VMRS Code | 033003005 |
| UNSPSC | 26101732 |
NGK SPARK PLUGS GR45GP Cross References
NGK SPARK PLUGS GR45GP Fits Vehicles
- Asuna SE (1993)
- Asuna GT (1993)
- Pontiac Optima (1988-1991)
- Chrysler Intrepid (1993-1997)
- Chrysler Dynasty (1990-1993)
- Pontiac Sunbird (1987-1988)
- Pontiac LeMans (1988-1993)
- Oldsmobile Firenza (1987-1988)
- Cadillac Seville (1980-1981)
- Cadillac Fleetwood (1975-1984)
- Cadillac Eldorado (1975-1978, 1980-1981)
- Cadillac DeVille (1975-1981)
- Cadillac Commercial Chassis (1975-1984)
- Cadillac Calais (1975-1976)
- Buick Skyhawk (1987-1988)
- Plymouth Voyager (1991-2000)
- Plymouth Grand Voyager (1990-2000)
- Eagle Vision (1993-1997)
- Dodge Intrepid (1993-1997)
- Dodge Grand Caravan (1990-2000)
- Dodge Dynasty (1990-1993)
- Dodge Caravan (1990-2000)
- Chrysler Voyager (2000)
- Chrysler Town & Country (1990-2000)
- Chrysler New Yorker (1990-1993)
- Chrysler Grand Voyager (2000)
- Chrysler Imperial (1990-1993)
- Chrysler Concorde (1993-1996)
