NGK SPARK PLUGS TR4 Part Description
Manufacturer
Product Description
NGK V-Power Spark Plug
Features & Benefits
- ACTUAL OE or EQUIVALENT DESIGN: OEM quality construction nickel alloy center electrode with V-groove provides consistent performance
- RECOMMENDED USAGE: Best for vehicles with OE nickel alloy plugs, not recommended on vehicles with factory precious metal plugs
- NGK's OE CERAMIC TECHNOLOGY: High grade alumina silicate ceramic creates a stronger insulator for optimal dielectric performance
- SOLID COPPER CORE: 98% pure copper core offers superior heat dissipation, conductivity and ultra wide heat ranges
- COLD-ROLLED THREADS: Prevents cross-threading and damage to cylinder heads
- TRIVALENT METAL PLATING: Delivers superior anti-corrosion and anti-seizing properties, ensuring ease of installation and removal
NGK SPARK PLUGS TR4 Specifications
Product Attributes
| Short Style Spark Plug | No |
| Service Number | TR4 |
| Stock Number | 3754 |
| Part Number | TR4 |
| Resistance | 5000.0 82 |
| Ground Electrode Tip Design | Standard |
| Ground Configuration | J-Gap |
| Ground Electrode Core Material | Nickel |
| Washer(s) Included | No |
| Grade Type | Standard Replacement |
| Electrical Terminal Type | Non-Removable Nut |
| Center Electrode Core Material | Copper |
| Center Electrode Tip Material | Nickel |
| Pre-Gap Size | .040 IN |
| Ground Electrode Quantity | 1 |
| Hex Size | 5/8" (16mm) |
| Insulator Height | 2.07 IN |
| Manufacturer Heat Range | 4 |
| Seat Type | Tapered |
| Reach | 0.689 IN |
| Thread Diameter | 0.551 IN |
| Insulator Material | Ceramic |
| Resistor Type | Yes |
| Skirt Length | 0.0 IN |
| Ground Electrode Tip Material | Nickel |
| Skirt | No |
| Center Electrode Insulator Tip Projection | 0.16 IN |
| Center Electrode Design | Standard |
| Center Electrode Projection | Mid Projection |
| Thread Size | M14 - 1.25 |
| Metallurgy | Copper |
| Thread Type Standard | Metric |
| Pre-Gap Size | 1.0 MM |
| Insulator Height | 52.5 MM |
| Reach | 17.5 MM |
| 6648 | 0.0 MM |
| Center Electrode Insulator Tip Projection | 4.0 MM |
Additional Information
| Harmonized Tariff Code (HTS) | 8511100000 |
| Warranty Time UOM | MO |
| Warranty Time | 2 |
| Country of Origin (Primary) | JP |
| UPC | 00087295137543 |
| VMRS Code | 033003005 |
| UNSPSC | 26101732 |
NGK SPARK PLUGS TR4 Cross References
| Brand | Part Number |
|---|---|
| ACDelco | R43LTSE, R44LTSM, 5613611, R44LTS, R45LTSM, R44LTSMA, 1835044T, R46LTS, 1835182T, 2R44LTSM |
| Autolite | 5245, 5245DP2, 5245BP |
| Bosch | 7989, HR10DCX, 7589 |
| CHAMPION | 15 |
| Champion Spark Plug | RS14YC, RS15LYC, 15S, RS12YC, 15C2, 401C2, 401, 15, 401S, RS17YX, RS13LYC, 408, 909, RS14LYC |
| Cummins | 167-0272 |
| E3 SPARK PLUGS | E354 |
| Motorcraft | SP419, SP442, AGSF33C, AGSF52C, AGSF52CF4, AWSF42, AWSF42C, AWSF42CF4, AWSF42CF6, AWSF52C, AWSF52CF4, AWSF52CF6 |
| N/A | TR4 |
| NGK | 3754 |
| Volvo Penta | 3851868 |
NGK SPARK PLUGS TR4 Fits Vehicles
- Saturn Relay (2006-2007)
- Buick Lucerne (2009-2011)
- Saturn Vue (2008-2010)
- Saturn Aura (2007-2008)
- Chevrolet Monte Carlo (2006-2007)
- Pontiac Montana (2006-2009)
- Chevrolet Uplander (2006-2009)
- Chevrolet Malibu (2006-2010)
- Buick Terraza (2006-2007)
- Chevrolet Impala (2006-2011)
- Pontiac G6 (2006-2010)
- Pontiac Tempest (1987-1991)
- Pontiac Sunbird (1991-1994)
- Pontiac Grand Prix (1988-1993)
- Pontiac 6000 (1987-1991)
- Oldsmobile Firenza (1987-1988)
- Oldsmobile Cutlass Supreme (1988-1993)
- Oldsmobile Cutlass Cruiser (1987-1989)
- Oldsmobile Cutlass Ciera (1987-1989, 1993)
- Chevrolet Lumina (1990-1994)
- Chevrolet Corsica (1987-1993)
- Chevrolet Celebrity (1987-1990)
- Chevrolet Cavalier (1987-1994)
- Chevrolet Beretta (1987-1993)
- Cadillac Cimarron (1987-1988)
- Buick Skyhawk (1987-1989)
- Buick Regal (1988-1993)
- Buick Century (1987-1989, 1993)
