(888) 312-8812 Login SignupWEATHERHEAD 06U508 HOSE END
Tap to view 3 more
$390
Limited availability at this price!
In Stock
Get it by Wednesday, Mar 11
WEATHERHEAD 06U508 Part Description
Manufacturer
Product Specifications
| End Size | 8 |
| End Type | SAE 37 Degree |
| Hose Family | DIN 1S/SAE R1 |
| Hose Size | 6 |
| Material | Carbon Steel |
| Product Line | Industrial |
| Shape | Straight |
| Style | Permanent |
| A | 2.67 |
| Application | General purpose low, medium, and high pressure hydraulic. |
| Assembly Style | U Series |
| Description | SAE 37 Male Rigid |
| Family | Coll-o-Crimp |
| Hex "E" | 0.81 |
| Hole Dia | 0.25 |
| Hole Dia. | 0.25 |
| Hose Cut-Off Factor "D" | 1.24 |
| Hose Cutt off Factor | 1.24 |
| Hose I.D. | 0.38 |
| Hose ID | 0.38 |
| Overall Length "A" | 2.67 |
| Plating | Zinc; yellow dichromate finish |
| Product Type | Fitting |
| Series | U? Series |
| Thread Size | 42433 |
| Tube Size | 8 |
WEATHERHEAD 06U508 Cross References
| Brand | Part Number |
|---|---|
| WH06U508 | |
| GATES | G25165-0608 |
WEATHERHEAD 06U508 Customer Reviews
No reviews yet
Be the first to review this product!
WEATHERHEAD 06U508 Manufacturer Information
Officially acquired by Eaton in 2002, Weatherhead® is one of the industry’s biggest suppliers of hydraulic hose, hose ends, tube fittings, couplings, assembly equipment, and support accessories. Weatherhead crafts top-products that are widely used in mining, agriculture, construction, truck, and bus applications. Eaton delivers Weatherhead thermoplastic tubing in different sizes—from 1/8 to 1 inch—designed for use in air tools, robotics, beverage dispensing as well as air and water supply. Driven by the company’s goal to offer unique solutions to a wide range of markets that enable businesses to be at the forefront of change, Weatherhead remains the truck industry’s leading source of premium-quality hoses, fittings, and adapters for your fleet’s hose and fittings needs
WEATHERHEAD 06U508 Questions & Answers
No questions yet
Be the first to ask a question about this product!
