CENTRIC 125.33090 Part Description
Manufacturer
Product Description
Centric Premium High Carbon Alloy Brake Rotor
Features & Benefits
- Centric Premium Rotor with advanced metallurgy that greatly reduces pad squeal. Especially effective with higher friction; European style brake pad compounds. Added Molybdenum and Chromium to resist rotor cracking
- Painted hat and outer edge for corrosion resistance
- Painted Hat and Outer Edge
- Optimal Surface Finish
- Optimal surface finish for consistent stopping feel from the first stop
- Advanced Metallurgy
- Advanced metallurgy for optimal heat transfer and structural strength
- OE Vane Design and Plate Thickness
- OE vane design and plate thickness for heat capacity and strength
- Low Initial Lateral Run-Out
- Low initial lateral run-out and disc thickness variation for smooth, vibration free stopping
- Precision Balance
- Precision balance for vibration free performance
CENTRIC 125.33090 Specifications
Product Attributes
| Misc Holes [cntrc] | 1 |
| Vane Style [cntrc] | Curved |
| California Proposition 65 Text [cntrc] | WARNING: Cancer and Reproductive Harm |
| Product Grade [cntrc] | Premium |
| Weight [cntrc] Lbs | 26.500 |
| Disc Mounting [cntrc] | Floating |
| Weight [cntrc] Kgs | 12.050 |
| Discard Thickness | 1.260 IN |
| Discard Thickness | 32.000 MM |
| Nominal Thickness | 33.900 MM |
| Nominal Thickness | 1.335 IN |
| Hat Finish | Painted |
| Overall Height | 68.800 MM |
| Overall Height | 2.709 IN |
| Outside Diameter | 350.000 MM |
| Outside Diameter | 13.780 IN |
| ABS Tone Ring Included | No |
| Surface Type | Smooth |
| Solid Or Vented Type Rotor | Vented |
| Bearings Included | No |
| Center Hole Diameter | 85.100 MM |
| Center Hole Diameter | 3.350 IN |
| Mounting Bolt Hole Circle Diameter | 5.118 IN |
| Mounting Bolt Hole Circle Diameter | 130.000 MM |
| Stud/Lug Hole Quantity | 5 |
| Stud/Lug Hole Diameter | 15.500 MM |
| Stud/Lug Hole Diameter | 0.610 IN |
Additional Information
| Harmonized Tariff Code (Schedule B) | 8708300050 |
| Harmonized Tariff Code (HTS) | 8708305030 |
| NAFTA Preference Criterion Code | B |
| Country of Origin (Primary) | CN |
| UPC | 00805890729211 |
CENTRIC 125.33090 Cross References
| Brand | Part Number |
|---|---|
| ATE BRAKE PRODUCTS | 434123, SP34123 |
| N/A | 125.33090, BD126342, BD126342E, E125-38-095, E130-38-095, 434123, YH145590, 1407-77178, 34265, 25727, 34265G, 7L5615301E, 7L6615301E, 7L6615301K, 7L8615301, 95535140150, 95535140151, 980311P, 880311, DDF1408LC-1, DF4304S, DF4764S, 90074051D, E12538095 |
| RAYBESTOS | 980311 |
| Raybestos Brakes | 980311 |
CENTRIC 125.33090 Fits Vehicles
- Porsche Cayenne (2003-2006, 2008-2018)
- Audi Q7 (2007-2015)
- Volkswagen Touareg (2004-2010)
