CENTRIC 123.61016 Part Description
Manufacturer
Product Description
C-Tek Standard Brake Drum
Features & Benefits
- Non-Directional Finishes. Machined non-friction surfaces. Widest application coverage in the aftermarket
- For best operation and ultimate strength
- OE-Matched Fit, Form, and Function
- 100% Mill Balanced
- For vibration free performance
- Meets SAE Standard for Tensile Strength
- For maximum service life and structural integrity
CENTRIC 123.61016 Specifications
Product Attributes
| Weight [cntrc] Kgs | 5.591 |
| Weight [cntrc] Lbs | 12.300 |
| Mounting Type [cntrc] | Floating |
| Bolt Circle Diameter [cntrc] Mm | 114.300 |
| Bolt Circle Diameter [cntrc] In | 4.500 |
| Hub Hole / Register [cntrc] Mm | 70.612 |
| Hub Hole / Register [cntrc] In | 2.780 |
| Height [cntrc] Mm | 84.582 |
| Height [cntrc] In | 3.330 |
| Friction Surface Width [cntrc] Mm | 51.816 |
| Friction Surface Width [cntrc] In | 2.040 |
| Product Grade [cntrc] | Standard |
| Maximum Brake Diameter (Discard) | 256.300 MM |
| Maximum Brake Diameter (Discard) | 10.090 IN |
| Bolt Hole Quantity | 5 |
| Outside Diameter | 295.910 MM |
| Outside Diameter | 11.650 IN |
| Outer Cooling Fins | No |
| Mounting Hole Diameter | 14.224 MM |
| Mounting Hole Diameter | 0.560 IN |
| Nominal Drum Diameter | 254.000 MM |
| Nominal Drum Diameter | 10.000 IN |
Additional Information
| Harmonized Tariff Code (Schedule B) | 8708300050 |
| Harmonized Tariff Code (HTS) | 8708305030 |
| NAFTA Preference Criterion Code | B |
| Country of Origin (Primary) | CN |
| UPC | 00805890977766 |
CENTRIC 123.61016 Cross References
CENTRIC 123.61016 Fits Vehicles
- Mercury Comet (1974-1977)
- Ford Maverick (1974-1977)
