(888) 312-8812 Login SignupCENTRIC 120.58009 Centric Premium Brake Rotor
Tap to view 4 more
$9549
Limited availability at this price!
1 Day Lead Time
Get it by Wednesday, Mar 18
CENTRIC 120.58009 Part Description
Manufacturer
Product Description
Centric Premium Brake Rotor
Features & Benefits
- Symmetric vane; split-core castings for uniform heat distribution. Black E-Coat anti-corrosive coating protects much better than competitors spray paint. Double disc ground friction surface for optimal performance and serviced life
- Painted hat and outer edge for corrosion resistance
- Symmetric vane; split-core castings for uniform heat distribution. Anti-corrosive paint protects much better than competitors spray paint. Double disc ground friction surface for optimal performance and serviced life.
- Painted Hat and Outer Edge
- Optimal Surface Finish
- Optimal surface finish for consistent stopping feel from the first stop
- Advanced Metallurgy
- Advanced metallurgy for optimal heat transfer and structural strength
- OE Vane Design and Plate Thickness
- OE vane design and plate thickness for heat capacity and strength
- Low Initial Lateral Run-Out
- Low initial lateral run-out and disc thickness variation for smooth, vibration free stopping
- Precision Balance
- Precision balance for vibration free performance
CENTRIC 120.58009 Specifications
Product Attributes
| Vane Style [cntrc] | Pillar |
| Hat Id [cntrc] In | 8.098 |
| Product Grade [cntrc] | Premium |
| California Proposition 65 Text [cntrc] | WARNING: Cancer and Reproductive Harm |
| Weight [cntrc] Kgs | 11.220 |
| Misc Holes [cntrc] | 0 |
| Weight [cntrc] Lbs | 24.750 |
| Disc Mounting [cntrc] | Floating |
| Hat Id [cntrc] Mm | 205.700 |
| Discard Thickness | 26.000 MM |
| Discard Thickness | 1.024 IN |
| Nominal Thickness | 1.102 IN |
| Nominal Thickness | 28.000 MM |
| Hat Finish | Painted |
| Overall Height | 63.700 MM |
| Overall Height | 2.508 IN |
| Outside Diameter | 350.000 MM |
| Outside Diameter | 13.780 IN |
| ABS Tone Ring Included | No |
| Surface Type | Smooth |
| Solid Or Vented Type Rotor | Vented |
| Nominal Drum Diameter | 206.000 MM |
| Nominal Drum Diameter | 8.110 IN |
| Bearings Included | No |
| Center Hole Diameter | 72.000 MM |
| Center Hole Diameter | 2.835 IN |
| Mounting Bolt Hole Circle Diameter | 127.000 MM |
| Mounting Bolt Hole Circle Diameter | 5.000 IN |
| Stud/Lug Hole Quantity | 5 |
| Stud/Lug Hole Diameter | 16.900 MM |
| Stud/Lug Hole Diameter | 0.665 IN |
Additional Information
| Harmonized Tariff Code (Schedule B) | 8708300050 |
| Harmonized Tariff Code (HTS) | 8708305030 |
| NAFTA Preference Criterion Code | B |
| Country of Origin (Primary) | CN |
| UPC | 00805890853145 |
CENTRIC 120.58009 Cross References
| Brand | Part Number |
|---|---|
| N/A | 850326, 43182, 512AB, 63909L, N247, 90042008, 43182G, 0053404110, 68256680AC, 53404110, 5181512AA, 5181512AB, 5181512AC, 72212 |
| NEOTEK | 107332GF |
| Neotek Premium Drums and Rotors | 107332GF |
| RAYBESTOS | 780961, 780961FZN, 780961R, 780961R2 |
| Raybestos Brakes | 780961, 780961FZN, 780961R |
| WAGNER | BD180501, BD180501E |
CENTRIC 120.58009 Fits Vehicles
- Dodge Durango (2017-2023)
- Jeep Grand Cherokee (2012-2021)
