(888) 312-8812 Login SignupCENTRIC 130.33400 Centric Premium Brake Master Cylinder
Tap to view 6 more
$6749
Limited availability at this price!
1 Day Lead Time
Get it by Thursday, Mar 19
CENTRIC 130.33400 Part Description
Manufacturer
Product Description
Centric Premium Brake Master Cylinder
Features & Benefits
- Match O.E. parts in quality; configuration and fitment. Complete with reservoirs; switches and floats. Original aluminum casting body design where applicable. Manufactured under the highest quality standards by OEM and OES manufacturers
CENTRIC 130.33400 Specifications
Product Attributes
| Product Grade [cntrc] | Premium |
| Publication Bore [cntrc] | 17mm |
| Boss, Nipple Or Port: Rear: #a [cntrc] | M10-1.00 bbl |
| Secondary Outlet Flare Type [cntrc] | Bubble |
| Boss, Nipple Or Port: Rear: #b [cntrc] | M10-1.00 bbl |
| Primary Outlet Flare Type [cntrc] | Bubble |
| Boss, Nipple Or Port: Front, Left: #b [cntrc] | M10-1.00 bbl |
| Boss, Nipple Or Port: Front, Left: #a [cntrc] | M10-1.00 bbl |
| Weight [cntrc] Kgs | 1.05 |
| Weight [cntrc] Lbs | 2.3 |
| Push Rod: Length / Depth [cntrc] In | 1.14 |
| Boss, Nipple Or Port: Bottom [cntrc] | M10-1.00 bbl |
| Reservoir Material | Plastic |
| Dust Boot Included | Yes |
| Mounting Hardware Included | No |
| Gasket Or Seal Included | Yes |
| Mounting Hole Quantity | 2 |
| Master Cylinder Bore Diameter | 17.000 MM |
| Master Cylinder Bore Diameter | 0.669 IN |
| Brake Booster Included | No |
| Master Cylinder Cap Included | No |
| Master Cylinder Material | Cast Iron |
| Push Rod Included | No |
| Reservoir Included | No |
| Primary Outlet Thread Diameter | 10.000 MM |
| Secondary Outlet Thread Diameter | 10.000 MM |
| Bleeder Hoses Included | No |
| Port Quantity | 4 |
| Mounting Bracket Included | No |
| Secondary Outlet Thread Pitch | 1.00 MM |
| Primary Outlet Thread Pitch | 1.00 MM |
| Bore Type | Straight |
| Bore Size | 17.000 MM |
| Bore Size | 0.669 IN |
| Secondary Outlet Thread Size | M10-1.00 |
| Primary Outlet Thread Size | M10-1.00 |
| Brake Pressure Switch Required | Yes |
| Brake Pressure Switch Quantity | 2 |
| Brake Pressure Switch(s) Included | No |
| Primary Outlet Flare Type | Bubble |
| Secondary Outlet Flare Type | Bubble |
| Primary Bore Diameter | 17.000 MM |
| Primary Bore Diameter | 0.669 IN |
| Reservoir Style | Removable |
Additional Information
| Harmonized Tariff Code (HTS) | 8413919050 |
| NAFTA Preference Criterion Code | B |
| Country of Origin (Primary) | CN |
| UPC | 00805890000693 |
CENTRIC 130.33400 Cross References
| Brand | Part Number |
|---|---|
| DORMAN | M39377 |
| N/A | 0728017, F96431, 010042, 6616200, M900399, 171611015A, 171611015AA, 171611015AF, 171611015C, 171611015J, 171611015S, CM1228, CM1417, 65-M39377, MC39377, 11826, 39377, 230233400, 2302-33400, 1802, 111826, M02400, E96431, 18M199, 18030441, 35574027 |
| RAYBESTOS | MC39377 |
CENTRIC 130.33400 Fits Vehicles
- Volkswagen Rabbit (1975-1978, 1983)
