(888) 312-8812 Login SignupCENTRIC 120.3504 Centric Premium Brake Rotor
Tap to view 4 more
No Stock Available
We cannot fulfill orders for this part at this time. Please check back later or request a stock notification to receive an email.
We may have similar parts for sale. Search Alternatives >
CENTRIC 120.3504 Part Description
Manufacturer
Product Description
Centric Premium Brake Rotor
Application Summary
Mercedes-Benz SL320 1997-1996, SL500 1998-1996
Features & Benefits
- Symmetric vane; split-core castings for uniform heat distribution. Black E-Coat anti-corrosive coating protects much better than competitors spray paint. Double disc ground friction surface for optimal performance and serviced life
Premium rotor; rotors; Centric; brake rotor; break; brake disc; disc brake
CENTRIC 120.3504 Specifications
Product Attributes
| Discard Thickness | 0.327 IN |
| Nominal Thickness | 0.394 IN |
| Hat Finish | Coated |
| Overall Height | 2.236 IN |
| Outside Diameter | 11.417 IN |
| ABS Tone Ring Included | No |
| Surface Type | Smooth |
| Solid Or Vented Type Rotor | Solid |
| Nominal Drum Diameter | 164.000 MM |
| Bearings Included | No |
| Center Hole Diameter | 67.000 MM |
| Mounting Bolt Hole Circle Diameter | 4.409 IN |
| Stud/Lug Hole Quantity | 5 |
| Stud/Lug Hole Diameter | 0.512 IN |
| California Proposition 65 Text [basic] | WARNING: Cancer and Reproductive Harm |
| Disc Mounting [cntrc] | Floating / DIH |
| Max Pb Drum Dia [cntrc] In | 6.449 |
| Max Pb Drum Dia [cntrc] Mm | 163.800 |
| Misc Holes [cntrc] | 2 |
| Vane Style [cntrc] | Curved |
| Weight [cntrc] Kgs | 5.010 |
| Weight [cntrc] Lbs | 11.020 |
| Discard Thickness | 8.300 MM |
| Outside Diameter | 290.000 MM |
| Center Hole Diameter | 2.638 IN |
| Disc Mounting | Floating / DIH |
| Maximum Drum Diameter | 6.449 |
| Misc Holes | 2 |
| Vane Style | Curved |
| Weight | 5.010 |
Additional Information
| Country of Origin (Primary) | DE |
| Harmonized Tariff Code (Schedule B) | 8708300050 |
| Harmonized Tariff Code (HTS) | 8708305030 |
| NAFTA Preference Criterion Code | B |
| UPC | 00805890068808 |
CENTRIC 120.3504 Cross References
CENTRIC 120.3504 Fits Vehicles
- Mercedes-Benz SL500 (1996-1998)
- Mercedes-Benz SL320 (1996-1997)
