(888) 312-8812 Login SignupCENTRIC 400.33000 Centric Premium Hub and Bearing Assembly; With ABS
Tap to view 3 more
No Stock Available
We cannot fulfill orders for this part at this time. Please check back later or request a stock notification to receive an email.
We may have similar parts for sale. Search Alternatives >
CENTRIC 400.33000 Part Description
Manufacturer
Product Description
Centric Premium Hub and Bearing Assembly; With ABS
Features & Benefits
- 100% O.E. Quality Components. Premium seals protect internal components. Exacting Fit and Function. Complete cataloging; featuring the latest applications and covering from 1940 to 2017
- Double Row Ball or Taper Roller Bearings include integral encoder for ABS and TCS where applicable
- Gen 1
- Gen 2
- Double Row Ball or Taper Roller Bearing Assemblies include one mounting flange - includes integral encoder for ABS, TCS where applicable
- Gen 3
- Double Row Ball or Taper Roller Bearing Assemblies include 2 mounting flanges - includes integral ABS sensor where applicable
CENTRIC 400.33000 Specifications
Product Attributes
| Bolt Circle Diameter [cntrc] In | 4.409 |
| Spline Bore Dia [cntrc] Mm | 29.000 |
| Notes [cntrc] | Magnetic ABS Encoder; 1 Rotor Retaining Hole M6-1.0 |
| Product Grade [cntrc] | Premium |
| Inner Mount Pilot [cntrc] Mm | 84.840 |
| Inner Mount Pilot [cntrc] In | 3.340 |
| Mouting Thread Size [cntrc] Mm | 12.000 |
| Bolt Circle Diameter [cntrc] Mm | 111.990 |
| Off-set [cntrc] Mm | 1.890 |
| Mounting Thread Pitch [cntrc] Mm | 1.500 |
| Thread Pitch To Wheel Mounting [cntrc] Mm | 1.500 |
| Off-set [cntrc] In | 48.010 |
| Mounting Hole Qty [cntrc] | 4 |
| Spline Quantity | 36 |
| Wheel Stud Size | 14.000 MM |
| Wheel Pilot Diameter | 57.150 MM |
| Wheel Pilot Diameter | 2.250 IN |
| Brake Pilot Diameter | 64.970 MM |
| Brake Pilot Diameter | 2.558 IN |
| Wheel Stud Quantity | 5 |
| Wheel Studs Included | Yes |
| Flange Diameter | 5.370 IN |
| Flange Diameter | 136.400 MM |
Additional Information
| NAFTA Preference Criterion Code | B |
| Country of Origin (Primary) | JP |
| Harmonized Tariff Code (HTS) | 8482105016 |
| UPC | 00805890562764 |
CENTRIC 400.33000 Cross References
| Brand | Part Number |
|---|---|
| BCA | WE60756 |
| GMB | 780-0327 |
| MEVOTECH | H513253 |
| N/A | 60BWKH07RY5CP01, HA590106, H513253, 513253, BR930623, 805657A, 805657B, WE60756, 3C0 498 621, 3C0498621, 5K0 498 621, 5K0498621, 1K0 407 621C, 1K0 407 621D, 1K0 407 621F, 1K0 407 621G, 1K0407621C, 1K0407621D, 1K0407621F, 1K0407621G, 1T0 498 621, 1T0498621, 8J0 498 625, 8J0 498 625 A, 8J0 598 625, 8J0498625, 8J0498625A, 8J0598625, 8J0598625A |
| NTN | WE60756 |
CENTRIC 400.33000 Fits Vehicles
- Audi TT RS Quattro (2012-2013)
- Volkswagen Golf SportWagen (2015-2016)
- Volkswagen Caddy (2015, 2017-2019)
- Audi Q3 Quattro (2015-2018)
- Audi Q3 (2015-2019)
- Audi A3 Quattro (2006-2013)
- Volkswagen Beetle (2012-2019)
- Volkswagen Golf (2011-2017)
- Volkswagen Passat CC (2009-2010)
- Audi S3 (2008-2012)
- Volkswagen CC (2009-2017)
- Volkswagen GTI (2006-2014)
- Volkswagen Tiguan (2009-2020)
- Volkswagen R32 (2008)
- Audi A3 (2006-2013)
- Audi TT Quattro (2008-2015)
- Audi TT (2008-2009)
- Volkswagen Eos (2007-2016)
- Volkswagen Rabbit (2006-2009)
- Volkswagen Passat (2006-2010, 2012-2021)
- Volkswagen Jetta (2005-2018)
