(888) 312-8812 Login SignupWABCO 4005000810 ABS Control Module - VCS II, 24 Volts, 223mm x 131mm x 152mm
Tap to view 7 more
$2,31099
98 Day Lead Time
Due to limited availability, we will confirm your order and notify you within 1 business day.
WABCO 4005000810 Part Description
WABCO 4005000810 Specifications
Product Attributes
| Port thread 1 | 2x M26 x 1.5 |
| Port thread 21 | 3x M16 x 1.5 |
| Port thread 22 | 3x M16 x 1.5 |
| Maximum System | 4S/3M ... 2S/2M |
| Temperature Range | -40°C to +65°C |
| Port thread 3 | Flap Exhaust |
| Protection class | IP 66 |
| Port thread 4 | M16 x 1.5 |
| Size | 223 x 131 x 152 |
| Max. operating pressure | 13.0 bar |
| Voltage | 24 V |
| Calculated Volume (dm³) | 4.44 |
| Weight | 5.258 |
| Type | Premium |
| Version | VCS II |
| Electrical connection | X1 = 8-Pole. X6 = 8-Pole. 4x Sensor Connector |
WABCO 4005000810 Cross References
| Brand | Part Number |
|---|---|
| BENALU | C00203201 |
| DAF | 1519383 |
| DOLL | 7099724 |
| FELDBINDER | 1036692 |
| FRUEHAUF | C00203201 |
| GOLDHOFER | 168382 |
| KENWORTH | S400-500-081-0 |
| KRONE | 5818930, 5058189300, 505818930 |
| LANGENDORF | 1245711 |
| MEILLER | 79701370115373 |
| MERITOR | S4005000810 |
| NIPPON TREX | 924301-00101 |
| NOOTEBOOM | 4015470, 2110866 |
| PACCAR | 1519383 |
| PETERBILT | S400-500-081-0 |
| SCANIA | 1932575 |
| SCHMITZ | INS0160138, INSO160138 |
| SCHWARZMÜLLER | 77085 |
| SHOWA AIRCRAFT | A8188-009200 |
| TIRSAN | 21150110163 |
| TOHO CAR | B3225-6799-0A |
| VANGUARD NATIONAL | 1ABS00042 |
| VOLVO | WA4005000810 |
| WILSON | APP04558K |
WABCO 4005000810 Customer Reviews
No reviews yet
Be the first to review this product!
WABCO 4005000810 Manufacturer Information
Whether it’s for cars, buses, trucks, or trailers, WABCO® is at the frontline at developing and providing products and systems to make vehicles safer and easier to control. Founded in 1869, WABCO is a major supplier of braking, stability, suspension and transmissions in the Americas and beyond. The company is recognized as introducing the modern air brake system in 1869, and continues to lead the industry in air brake design and production for the heavy duty and commercial vehicle sectors. Today, WABCO operates as a division of the German auto parts maker ZF and employs 16,000 employees in facilities in 36 countries worldwide.
