CENTRIC 123.65001 Part Description
Manufacturer
Product Description
C-Tek Standard Brake Drum
Features & Benefits
- Non-Directional Finishes. Machined non-friction surfaces. Widest application coverage in the aftermarket
- For best operation and ultimate strength
- OE-Matched Fit, Form, and Function
- 100% Mill Balanced
- For vibration free performance
- Meets SAE Standard for Tensile Strength
- For maximum service life and structural integrity
CENTRIC 123.65001 Specifications
Product Attributes
| Misc Holes [cntrc] | 5 |
| Weight [cntrc] Kgs | 5.682 |
| Weight [cntrc] Lbs | 12.500 |
| Mounting Type [cntrc] | Floating |
| Bolt Circle Diameter [cntrc] Mm | 139.700 |
| Bolt Circle Diameter [cntrc] In | 5.500 |
| Hub Hole / Register [cntrc] Mm | 80.264 |
| Hub Hole / Register [cntrc] In | 3.160 |
| Height [cntrc] Mm | 77.216 |
| Height [cntrc] In | 3.040 |
| Friction Surface Width [cntrc] Mm | 61.468 |
| Friction Surface Width [cntrc] In | 2.420 |
| Product Grade [cntrc] | Standard |
| Maximum Brake Diameter (Discard) | 281.700 MM |
| Maximum Brake Diameter (Discard) | 11.090 IN |
| Bolt Hole Quantity | 5 |
| Outside Diameter | 315.976 MM |
| Outside Diameter | 12.440 IN |
| Outer Cooling Fins | No |
| Mounting Hole Diameter | 15.494 MM |
| Mounting Hole Diameter | 0.610 IN |
| Nominal Drum Diameter | 279.400 MM |
| Nominal Drum Diameter | 11.000 IN |
Additional Information
| Harmonized Tariff Code (HTS) | 8708305030 |
| NAFTA Preference Criterion Code | B |
| Country of Origin (Primary) | CN |
| Harmonized Tariff Code (Schedule B) | 8708300050 |
| UPC | 00805890915195 |
CENTRIC 123.65001 Cross References
| Brand | Part Number |
|---|---|
| N/A | BD60050, E128-70-006, E127-70-006, 8163, 123.65001, 8163G, B9TT1102G, A8TZ1125A, B7TZ1102A, TAAA1125A, TAAA1125B, PDR0112, 140112, 202630, 6401070, 779, AD8501, D2600, E12770006, 87155, X21016, BD1217, 2600, 2600R, 2600DGS, 78842001, 8842001, 177 10, 17710, 36554044 |
| RAYBESTOS | 2600, 2600R |
CENTRIC 123.65001 Fits Vehicles
- Ford F-100 (1953-1963)
- Ford P-100 (1961-1963)
