CENTRIC 123.40017 Part Description
Manufacturer
Product Description
C-Tek Standard Brake Drum
Features & Benefits
- Non-Directional Finishes. Machined non-friction surfaces. Widest application coverage in the aftermarket
- For best operation and ultimate strength
- OE-Matched Fit, Form, and Function
- 100% Mill Balanced
- For vibration free performance
- Meets SAE Standard for Tensile Strength
- For maximum service life and structural integrity
CENTRIC 123.40017 Specifications
Product Attributes
| Misc Holes [cntrc] | 2 |
| Weight [cntrc] Kgs | 4.205 |
| Weight [cntrc] Lbs | 9.250 |
| Mounting Type [cntrc] | Floating |
| Bolt Circle Diameter [cntrc] Mm | 114.300 |
| Bolt Circle Diameter [cntrc] In | 4.500 |
| Hub Hole / Register [cntrc] Mm | 64.200 |
| Hub Hole / Register [cntrc] In | 2.528 |
| Height [cntrc] Mm | 54.800 |
| Height [cntrc] In | 2.157 |
| Friction Surface Width [cntrc] Mm | 39.400 |
| Friction Surface Width [cntrc] In | 1.551 |
| Product Grade [cntrc] | Standard |
| Maximum Brake Diameter (Discard) | 201.000 MM |
| Maximum Brake Diameter (Discard) | 7.913 IN |
| Bolt Hole Quantity | 5 |
| Outside Diameter | 249.800 MM |
| Outside Diameter | 9.835 IN |
| Outer Cooling Fins | No |
| Mounting Hole Diameter | 12.800 MM |
| Mounting Hole Diameter | 0.504 IN |
| Nominal Drum Diameter | 200.000 MM |
| Nominal Drum Diameter | 7.874 IN |
Additional Information
| Harmonized Tariff Code (Schedule B) | 8708300050 |
| Harmonized Tariff Code (HTS) | 8708305030 |
| NAFTA Preference Criterion Code | B |
| Country of Origin (Primary) | CN |
| UPC | 00805890914310 |
CENTRIC 123.40017 Cross References
CENTRIC 123.40017 Fits Vehicles
- Honda Civic (2006-2015)
