(888) 312-8812 Login SignupNATIONAL SEALS 710676 National 710676 Engine Crankshaft Seal
Tap to view 1 more
MSRP: $34.34
$2749
Save $6.85
Limited availability at this price!
In Stock
Get it by Thursday, Mar 19
NATIONAL SEALS 710676 Part Description
Manufacturer
Product Description
Engine Crankshaft Seal
Application Summary
2000-2005 Toyota Echo (Rear) (Liter: 1.5 & Engine(cc): 1497 & Cylinder: 4 & Block: L & Bore(in): 2.95 & Bore(mm): 75.0 & Stroke(in): 3.33 & Stroke(mm): 84.8); 2001-2009 Toyota Prius (Rear) (Liter: 1.5 & Engine(cc): 1497 & Cylinder: 4 & Block: L & Bore(in): 2.95 & Bore(mm): 75.0 & Stroke(in): 3.33 & Stroke(mm): 84.7); 2012-2019 Toyota Prius C (Rear) (Engine Designation: 1NZ-FXE & Liter: 1.5 & Engine(cc): 1497 & Engine(ci): 91 & Cylinder: 4 & Block: L & Bore(in): 2.95 & Bore(mm): 75.0 & Stroke(in): 3.33 & Stroke(mm): 84.7); 2017-2018 Toyota Yaris iA (Rear) (Liter: 1.5 & Engine(cc): 1496 & Engine(ci): 91 & Cylinder: 4 & Block: L & Bore(in): 2.93 & Bore(mm): 74.5 & Stroke(in): 3.38 & Stroke(mm): 85.8); 2006-2019 Toyota Yaris (Rear) (Liter: 1.5 & Engine(cc): 1497, 1496 & Engine(ci): 91 & Cylinder: 4 & Block: L & Bore(in): 2.95, 2.93 & Bore(mm): 75.0, 74.5 & Stroke(in): 3.33, 3.38 & Stroke(mm): 84.8, 85.8); 2004-2006 Scion xA (Rear) (Liter: 1.5 & Engine(cc): 1497 & Cylinder: 4 & Block: L & Bore(in): 2.95 & Bore(mm): 75.0 & Stroke(in): 3.33 & Stroke(mm): 84.8); 2004-2006 Scion xB (Rear) (Liter: 1.5 & Engine(cc): 1497 & Cylinder: 4 & Block: L & Bore(in): 2.95 & Bore(mm): 75.0 & Stroke(in): 3.33 & Stroke(mm): 84.8); 2016 Scion iA (Rear) (Liter: 1.5 & Engine(cc): 1496 & Engine(ci): 91 & Cylinder: 4 & Block: L & Bore(in): 2.93 & Bore(mm): 74.5 & Stroke(in): 3.38 & Stroke(mm): 85.8)
Features & Benefits
- Design type: spring loaded; multi-lip
- Temperature range: -40°F to 400°F / -40°C to 204°C
- Temperature range: -40degF to 400degF / -40degC to 204degC
- Excellent high temperature capabilities
- Compatible with wide range of fluids
- Delivers quality and reliable performance for every type of repair
NATIONAL SEALS 710676 Specifications
Product Attributes
| Inside Diameter | 2.953 IN |
| Inside Diameter | 75.000 MM |
| Outside Diameter | 4.220 IN |
| Outside Diameter | 107.200 MM |
| Width | 0.315 IN |
| Width | 8.000 MM |
| Material | Fluoro-Elastomer |
| Helix Type | Counter-Clockwise-Spiral Lip Design |
| Part Description | Oil Seal |
| Series | 710600 |
| Thickness | 0.315 IN |
| Thickness | 8.000 MM |
| Type | 32 |
| Unit of Dimension | Metric |
| Housing Bore | 4.213 in |
| Housing Bore | 107.000 MM |
| Shaft Diameter | 2.953 IN |
| Shaft Diameter | 75.000 MM |
| Shaft Diameter | 75.000 MM |
| Housing Bore | 4.213 IN |
| Grade Type | Premium |
| Housing Bore | 107.000 MM |
| Shaft Diameter | 2.953 IN |
| Grade Type | Premium |
Additional Information
| Country of Origin (Primary) | TW |
| Harmonized Tariff Code (Schedule B) | 4016931020 |
| Harmonized Tariff Code (HTS) | 4016931020 |
| Canadian Harmonizing Tariff Code | 4016930000 |
| UPC | 00019826109057 |
| VMRS Code | 045003004 |
NATIONAL SEALS 710676 Cross References
| Brand | Part Number |
|---|---|
| Beck/Arnley | 052-3910 |
| Chicago Rawhide | 29918 |
| Corteco | 19026734, 19026734B |
| Elring | 575.450 |
| Goetze | 50-319498-00 |
| Payen | NA5088 |
| SKF | 29918 |
| Timken | 710676 |
| Toyota | 90311-75016, 90311-75015, 90080-31094, 90311-75019, 90311-75018 |
| Victor Reinz | JV1678 |
NATIONAL SEALS 710676 Fits Vehicles
- Toyota Yaris iA (2017-2018)
- Scion iA (2016)
- Toyota Prius C (2012-2019)
- Toyota Yaris (2006-2019)
- Scion xB (2004-2006)
- Scion xA (2004-2006)
- Toyota Prius (2001-2009)
- Toyota Echo (2000-2005)
