NATIONAL SEALS 710329 Part Description
Manufacturer
Product Description
Multi-Purpose Seal
Application Summary
1999-2005 Suzuki Grand Vitara (Transmission Base Gear: 4 & Transmission Control Type: Automatic & Drive: RWD / Qualifier: with Aisin 03-72LE Transmission); 1992-1998 Suzuki Sidekick (Transmission Base Gear: 4 & Transmission Control Type: Automatic & Drive: RWD / Qualifier: with Aisin 03-72LE Transmission); 1999-2004 Suzuki Vitara (Transmission Base Gear: 4 & Transmission Control Type: Automatic & Drive: RWD / Qualifier: with Aisin 03-72LE Transmission); 1996-1998 Suzuki X-90 (Transmission Base Gear: 4 & Transmission Control Type: Automatic & Drive: RWD / Qualifier: with Aisin 03-72LE Transmission); 2002-2003 Suzuki XL-7 (Transmission Base Gear: 4 & Transmission Control Type: Automatic & Drive: RWD / Qualifier: with Aisin 03-72LE Transmission); 1998-2004 Chevrolet Tracker (Transmission Base Gear: 4 & Transmission Control Type: Automatic & Drive: RWD / Qualifier: with Aisin 03-72LE Transmission); 1996-1997 Geo Tracker (Transmission Base Gear: 4 & Transmission Control Type: Automatic & Drive: RWD / Qualifier: with Aisin 03-72LE Transmission); 1976-1983 Honda Accord (Front) (Liter: 1.6, 1.8 & Engine(cc): 1599, 1751 & Cylinder: 4 & Block: L & Bore(in): 2.95, 3.03 & Bore(mm): 75.0, 77.0 & Stroke(in): 3.54, 3.70 & Stroke(mm): 90.0, 94.0); 1973-1983 Honda Civic (Front) (Liter: 1.2, 1.3 & Engine(cc): 1169, 1237, 1335 & Engine(ci): 71 & Cylinder: 4 & Block: L & Bore(in): 2.76, 2.84 & Bore(mm): 70.0, 72.0 & Stroke(in): 2.99, 3.23 & Stroke(mm): 76.0, 82.0); 1979-1982 Honda Prelude (Front) (Liter: 1.8 & Engine(cc): 1751 & Cylinder: 4 & Block: L & Bore(in): 3.03 & Bore(mm): 77.0 & Stroke(in): 3.70 & Stroke(mm): 94.0)
Features & Benefits
- Design type: spring loaded; multi-lip
- Temperature range: -80°F to 350°F / -62°C to 176°C
- Temperature range: -80degF to 350degF / -62degC to 176degC
- Good dry heat resistance
- Excellent low temperature capability
- Delivers quality and reliable performance for every type of repair
NATIONAL SEALS 710329 Specifications
Product Attributes
| Inside Diameter | 1.378 IN |
| Inside Diameter | 35.000 MM |
| Outside Diameter | 1.976 IN |
| Outside Diameter | 50.200 MM |
| Width | 0.315 IN |
| Width | 8.000 MM |
| Material | Silicone |
| Helix Type | Counter-Clockwise-Spiral Lip Design |
| Part Description | Oil Seal |
| Sealing Material | Silicone |
| Series | 710300 |
| Thickness | 0.315 IN |
| Thickness | 8.000 MM |
| Type | 32 |
| Unit of Dimension | Metric |
| Housing Bore | 1.969 IN |
| Housing Bore | 50.000 MM |
| Shaft Diameter | 1.378 IN |
| Shaft Diameter | 35.000 MM |
| Grade Type | Premium |
Additional Information
| Country of Origin (Primary) | MX |
| Harmonized Tariff Code (Schedule B) | 4016931020 |
| Harmonized Tariff Code (HTS) | 4016931020 |
| Canadian Harmonizing Tariff Code | 4016930000 |
| UPC | 00724956723324 |
| VMRS Code | 053019003 |
NATIONAL SEALS 710329 Cross References
| Brand | Part Number |
|---|---|
| ATP | RO-49 |
| Beck/Arnley | 052-3331, 052-3466 |
| Chicago Rawhide | 13907 |
| Corteco | 19016483, 19016483B |
| Elring | 580.988 |
| Ford | E7TZ7052B |
| Gates | KS13907 |
| General Motors | 22533550 |
| Honda | 91212-PA5-004, 91212-611-003, 91212-611-004, 91212-611-010, 91213-PH7-003, 91213-PH7-013, 91213-PL2-003, 91213-PH7-004 |
| ITM Engine Components | 15-30503 |
| Kia | 22144-3B000 |
| Payen | NJ072 |
| Renault | 7700859691 |
| SKF | 13907 |
| Sterling Trucks | 12112130014, 12112130017 |
| Suzuki | 29792-57B01 |
| Timken | 710329 |
| TransTec | B29026 |
| Volvo | 30874307-9, 30874307, 3103838-1, 3103838 |
NATIONAL SEALS 710329 Fits Vehicles
- Geo Tracker (1996-1997)
- Suzuki XL-7 (2002-2003)
- Suzuki X-90 (1996-1998)
- Suzuki Sidekick (1992-1998)
- Suzuki Vitara (1999-2004)
- Suzuki Grand Vitara (1999-2005)
- Chevrolet Tracker (1998-2004)
- Honda Prelude (1979-1982)
- Honda Civic (1973-1983)
- Honda Accord (1976-1983)
