MONROE 65524 Magnum Shock Absorber - 17.85 in. Extended Length, Rear

65524 by MONROE - Magnum Shock Absorber - 17.85 in. Extended Length, Rear
MONROE
Tap to view 5 more

$72.99

Limited availability at this price!

In Stock

Get it by Thursday, Feb 12
No Hassle Return Policy Details
Free Economy shipping on orders over $499 details
Orders placed over the weekend will ship the following business day

MONROE 65524 Part Description

Manufacturer

MONROE

Product Description

Magnum Suspension Shock Absorber

Features & Benefits

  • FOR HARDWORKING COMMERCIAL VEHICLES -- Designed to handle the demands of high mileage and severe use class 6-8 trucks and buses
  • CONSISTENT RIDE -- All-weather fluid contains special additives to assist with extreme temperatures and help reduce oil breakdown while larger 2-3/8-in. reserve tube holds more fluid to improve performance (most applications)
  • EXCEPTIONAL HANDLING -- 10-Stage valving, tuned specifically to each vehicle, adjusts to road extremes while the larger 1-3/4-in. bore provides more efficient damping control to provide consistency and a smooth ride (most applications)
  • STRONG AND DURABLE -- Shouldered bushing and bonded bushing with sleeve protects from bushing walkout for improved quality; arc welds up to 360° for durability
  • STRONG AND DURABLE -- Shouldered bushing and bonded bushing with sleeve protects from bushing walkout for improved quality; arc welds up to 360deg for durability
  • BUILT TO LAST -- Robust hydraulic lock-out prevents over extension of air bags, top-out of the piston and averts damage to seal assembly (most applications)
  • LONGER SERVICE LIFE -- Bearing with PTFE coating reduces friction between rod and rod guide combined with nitrocarburized piston rod provides durability and longer service life (most applications)
  • REDUCED NOISE, VIBRATION AND HARSHNESS -- Delivers exceptional control and isolates impact-related noise, vibration and harshness under most driving conditions
  • IMPROVES PERFORMANCE -- Nitrogen gas-charge maintains tire-to-road contact for improved ride and handling by reducing aeration and shock fade
  • BUY WITH CONFIDENCE -- Comes with Monroe’s 90-day Risk Free Ride Offer and Limited Commercial Warranty
  • BUY WITH CONFIDENCE -- Comes with Monroe's 90-day Risk Free Ride Offer and Limited Commercial Warranty

MONROE 65524 Specifications

Product Attributes

Lower Mount Code S6
Upper Mount Code LS87
Dust Shield Included Yes
Includes Bump Stop No
Internal Rebound Bumper No
Hydraulic Lockout Yes
Part Description Shock Absorber
Compressed Length 11.7969 IN
Dust Shield Material Metal
Extended Length 17.8594 in
Gas Charged Yes
Lower Mount Type Stem Mount - 3.5/16" Stem Length X 5/8"-11 Thread Pitch
Parts Pack(s) P01482
Travel Length 6.062 in
Upper Mount Type Loop Bushing and Sleeve Mount - 5/8" Sleeve ID X 3.9/16" Sleeve OAL
Compressed Length 299.6 MM
Extended Length 453.6 MM
Travel Length 154 MM
Shock Absorber Rod End Measuring Point Center of Loop
Shock Absorber Body End Measuring Point Base of Stem
Lower Mount Type Stem
Lower Mount Code S6
Upper Mount Code LS87
Mounting Hardware Included Yes
Grade Type Premium
Active or Passive Suspension Passive
Adjustable Compression No
Adjustable Rebound No
Adjustable Ride Height No

Additional Information

MSDS Sheet Number 01164
Country of Origin (Primary) US
Canadian Harmonizing Tariff Code 8708803000
Harmonized Tariff Code (Schedule B) 8708800050
Harmonized Tariff Code (HTS) 8708801600
UPC 00048598174246
VMRS Code 016008003
UNSPSC 25172011

MONROE 65524 Cross References

BrandPart Number
65524MM, MAE65524
Alliance PartsABPN32G900058, ABPN32O900058
BULLDOG HD SHOCKSHD1215-0086
Bulldog HDHD12150086
Dayton Parts44185936
FCSF344342, F347306, F343376, F343378, F343368, F344355, F344353, F347215, F344343, F347303, F343375
FOX COMMERCIAL TRUCK SHOCKS98031016
GABRIEL85936, 89456, 671962
HALDEXSA65524
KENWORTH671962
KYB441600
KenworthC711014
MERITORM89456, M85936
NAPA Shocks65524
OEMC711014, 671962
PETERBILTC711014
POWER10 PARTSSSA-85936
Paccar PartsC711014

MONROE 65524 Fits Vehicles

  • Kenworth W900 (2004-2024)
  • Kenworth T800 (2007-2022)
  • Kenworth W990 (2019-2024)
  • Kenworth T700 (2011-2016)
  • Kenworth T880 (2014-2024)
  • Kenworth T680 (2013-2024)
  • Kenworth T660 (2008-2019)
  • Kenworth T400 (2010-2020)
  • Kenworth T600A (1986-2008)
  • Kenworth T2000 (1997-2011)
