MONROE 65510 Monroe Shocks & Struts Magnum 65510 Shock Absorber

$96.49

Limited availability at this price!

In Stock

Get it by Thursday, Feb 12
No Hassle Return Policy Details
Free Economy shipping on orders over $499 details
Orders placed over the weekend will ship the following business day

MONROE 65510 Part Description

Manufacturer

MONROE

Product Description

Magnum Suspension Shock Absorber

Features & Benefits

  • FOR HARDWORKING COMMERCIAL VEHICLES -- Designed to handle the demands of high mileage and severe use class 6-8 trucks and buses
  • CONSISTENT RIDE -- All-weather fluid contains special additives to assist with extreme temperatures and help reduce oil breakdown while larger 2-3/8-in. reserve tube holds more fluid to improve performance (most applications)
  • EXCEPTIONAL HANDLING -- 10-Stage valving, tuned specifically to each vehicle, adjusts to road extremes while the larger 1-3/4-in. bore provides more efficient damping control to provide consistency and a smooth ride (most applications)
  • STRONG AND DURABLE -- Shouldered bushing and bonded bushing with sleeve protects from bushing walkout for improved quality; arc welds up to 360° for durability
  • STRONG AND DURABLE -- Shouldered bushing and bonded bushing with sleeve protects from bushing walkout for improved quality; arc welds up to 360deg for durability
  • BUILT TO LAST -- Robust hydraulic lock-out prevents over extension of air bags, top-out of the piston and averts damage to seal assembly (most applications)
  • LONGER SERVICE LIFE -- Bearing with PTFE coating reduces friction between rod and rod guide combined with nitrocarburized piston rod provides durability and longer service life (most applications)
  • REDUCED NOISE, VIBRATION AND HARSHNESS -- Delivers exceptional control and isolates impact-related noise, vibration and harshness under most driving conditions
  • IMPROVES PERFORMANCE -- Nitrogen gas-charge maintains tire-to-road contact for improved ride and handling by reducing aeration and shock fade
  • BUY WITH CONFIDENCE -- Comes with Monroe’s 90-day Risk Free Ride Offer and Limited Commercial Warranty
  • BUY WITH CONFIDENCE -- Comes with Monroe's 90-day Risk Free Ride Offer and Limited Commercial Warranty

MONROE 65510 Specifications

Product Attributes

Lower Mount Code LS54
Upper Mount Code LS54
Dust Shield Included Yes
Includes Bump Stop No
Internal Rebound Bumper No
Hydraulic Lockout Yes
Part Description Shock Absorber
Compressed Length 9.75 IN
Dust Shield Material Metal
Extended Length 13.25 in
Gas Charged Yes
Lower Mount Type Loop Bushing and Sleeve Mount - 3/4" Sleeve ID X 1.3/4" Sleeve OAL
Parts Pack(s) None
Travel Length 3.5 in
Upper Mount Type Loop Bushing and Sleeve Mount - 3/4" Sleeve ID X 1.3/4" Sleeve OAL
Compressed Length 247.6 MM
Extended Length 336.5 MM
Travel Length 88.9 MM
Shock Absorber Rod End Measuring Point Center of Loop
Shock Absorber Body End Measuring Point Center of Loop
Lower Mount Type Loop (Eyelet) Bushing and Sleeve
Lower Mount Code LS54
Upper Mount Code LS54
Mounting Hardware Included No
Grade Type Premium
Active or Passive Suspension Passive
Adjustable Compression No
Adjustable Rebound No
Adjustable Ride Height No

Additional Information

MSDS Sheet Number 01164
Country of Origin (Primary) US
Canadian Harmonizing Tariff Code 8708803000
Harmonized Tariff Code (Schedule B) 8708800050
Harmonized Tariff Code (HTS) 8708801600
UPC 00048598174109
VMRS Code 016008003
UNSPSC 25172011

MONROE 65510 Cross References

BrandPart Number
65510MM, MAE65510
BLUE BIRD1526417
BULLDOG HD SHOCKSHD1215-0075
Bulldog HDHD12150075
CHEVROLET3919569
Dayton Parts441850525510
FCSF347196
GABRIEL85052, 665759
GM3919569
General Motors3919569
Gold Shock Absorber8160100
HALDEXSA65510
HENDRICKSONA21292, S23744, B21947, B23744
HendricksonS21292, S23650
INTERNATIONALAMS600166
MACK600166MT
MERITORM85052, 665769
MONROE VINTAGE600166, 6607
Monroe Shocks & Struts600166, 6607
NAPA Shocks65510
NEWAY90044833, 90044834, 57306607
NavistarAMS600166
OEMS23650, S23744, S21292
POWER10 PARTSSSA-85052, HT-S21292, HT-S23650
Road ChoiceSA5052
SACHS NORTH AMERICA315541, 317533
Sachs315541, 317533
VOLVO / WHITE / GMC3919569, RCSA5052, SA5052
Volvo GM Heavy Truck3919569, RCSA5052, SA5052
WATSON & CHALIN17300
WORLD AMERICANWA01-85052
