MONROE 65439 Monroe Shocks & Struts Magnum 65439 Shock Absorber

No Stock Available

We cannot fulfill orders for this part at this time. Please check back later or request a stock notification to receive an email.

We may have similar parts for sale. Search Alternatives >

MONROE 65439 Part Description

Manufacturer

MONROE

Product Description

Magnum Suspension Shock Absorber

Features & Benefits

  • FOR HARDWORKING COMMERCIAL VEHICLES -- Designed to handle the demands of high mileage and severe use class 6-8 trucks and buses
  • CONSISTENT RIDE -- All-weather fluid contains special additives to assist with extreme temperatures and help reduce oil breakdown while larger 2-3/8-in. reserve tube holds more fluid to improve performance (most applications)
  • EXCEPTIONAL HANDLING -- 10-Stage valving, tuned specifically to each vehicle, adjusts to road extremes while the larger 1-3/4-in. bore provides more efficient damping control to provide consistency and a smooth ride (most applications)
  • STRONG AND DURABLE -- Shouldered bushing and bonded bushing with sleeve protects from bushing walkout for improved quality; arc welds up to 360° for durability
  • BUILT TO LAST -- Robust hydraulic lock-out prevents over extension of air bags, top-out of the piston and averts damage to seal assembly (most applications)
  • LONGER SERVICE LIFE -- Bearing with PTFE coating reduces friction between rod and rod guide combined with nitrocarburized piston rod provides durability and longer service life (most applications)
  • REDUCED NOISE, VIBRATION AND HARSHNESS -- Delivers exceptional control and isolates impact-related noise, vibration and harshness under most driving conditions
  • IMPROVES PERFORMANCE -- Nitrogen gas-charge maintains tire-to-road contact for improved ride and handling by reducing aeration and shock fade
  • BUY WITH CONFIDENCE -- Comes with Monroe’s 90-day Risk Free Ride Offer and Limited Commercial Warranty

MONROE 65439 Specifications

Product Attributes

Lower Mount Code L4
Upper Mount Code L4
Dust Shield Included Yes
Includes Bump Stop No
Internal Rebound Bumper No
Hydraulic Lockout Yes
Part Description Shock Absorber
Compressed Length 15.125 IN
Dust Shield Material Metal
Extended Length 21.5 in
Gas Charged Yes
Lower Mount Type Loop Bushing Mount - 1" Bushing ID X 1.3/4" Bushing OAL
Parts Pack(s) None
Travel Length 6.375 in
Upper Mount Type Loop Bushing Mount - 1" Bushing ID X 1.3/4" Bushing OAL

Additional Information

MSDS Sheet Number 1164
Country of Origin (Primary) US
Canadian Harmonizing Tariff Code 8708803000
Harmonized Tariff Code (Schedule B) 8708801600
Harmonized Tariff Code (HTS) 8708801600
UPC 00048598173393
VMRS Code 016008003
UNSPSC 25172011

MONROE 65439 Cross References

BrandPart Number
65439MM
FLXIBLE TRANSIT BUS97999902635
FORDD2HA18045E2A
Flagg Suspension Parts80370
GABRIEL85716, 680347, 85732, 85718
Gold Shock Absorber8190101
HALDEXSA65439
KIMBLE MIXERS902256SP1
KONI902256SP1
KYBKG6001A, 345613, 345030
MERITORM85718
MONROE VINTAGE70162
Monroe Shocks & Struts70162
NAPA Shocks65439
PARTS ENROUTEE010032
VOLVO / WHITE / GMC3919964
Volvo GM Heavy Truck3919964
WESTERN STAR359013409
WESTERN UNIT80370

MONROE 65439 Fits Vehicles

  • Diamond Reo C116 (1990-1993)
  • Crane Carrier Century II (1987-1999)
  • Crane Carrier Centurion (1987, 1989-2009)
  • Chevrolet C70 (1979-1986)
  • Chevrolet C60 (1966-1986)
  • Chevrolet C50 (1973-1986)
