NGK SPARK PLUGS BKR5E11 Part Description
Manufacturer
Product Description
NGK V-Power Spark Plug
Features & Benefits
- ACTUAL OE or EQUIVALENT DESIGN: OEM quality construction nickel alloy center electrode with V-groove provides consistent performance
- RECOMMENDED USAGE: Best for vehicles with OE nickel alloy plugs, not recommended on vehicles with factory precious metal plugs
- NGK's OE CERAMIC TECHNOLOGY: High grade alumina silicate ceramic creates a stronger insulator for optimal dielectric performance
- SOLID COPPER CORE: 98% pure copper core offers superior heat dissipation, conductivity and ultra wide heat ranges
- COLD-ROLLED THREADS: Prevents cross-threading and damage to cylinder heads
- TRIVALENT METAL PLATING: Delivers superior anti-corrosion and anti-seizing properties, ensuring ease of installation and removal
NGK SPARK PLUGS BKR5E11 Specifications
Product Attributes
| Stock Number | 6953 |
| Part Number | BKR5E-11 |
| Short Style Spark Plug | No |
| Service Number | BKR5E-11 |
| Resistance | 5000.0 82 |
| Ground Electrode Tip Design | Standard |
| Ground Configuration | J-Gap |
| Ground Electrode Core Material | Nickel |
| Washer(s) Included | Yes |
| Grade Type | Standard Replacement |
| Electrical Terminal Type | Non-Removable Nut |
| Center Electrode Core Material | Copper |
| Center Electrode Tip Material | Nickel |
| Pre-Gap Size | .044 IN |
| Ground Electrode Quantity | 1 |
| Hex Size | 5/8" (16mm) |
| Insulator Height | 1.99 IN |
| Manufacturer Heat Range | 5 |
| Seat Type | Flat |
| Reach | 0.750 IN |
| Thread Diameter | 0.551 IN |
| Insulator Material | Ceramic |
| Resistor Type | Yes |
| Skirt Length | 0.0 IN |
| Ground Electrode Tip Material | Nickel |
| Skirt | No |
| Center Electrode Insulator Tip Projection | 0.12 IN |
| Center Electrode Design | Standard |
| Washer Type | Crush |
| Center Electrode Projection | Mid Projection |
| Thread Size | M14 - 1.25 |
| Metallurgy | Copper |
| Thread Type Standard | Metric |
| Pre-Gap Size | 1.1 MM |
| Insulator Height | 50.5 MM |
| Reach | 19.0 MM |
| 6648 | 0.0 MM |
| Center Electrode Insulator Tip Projection | 3.0 MM |
Additional Information
| Warranty Time UOM | MO |
| Warranty Time | 2 |
| Country of Origin (Primary) | US |
| Harmonized Tariff Code (HTS) | 8511100000 |
| UPC | 00087295169537 |
| VMRS Code | 033003005 |
| UNSPSC | 26101732 |
NGK SPARK PLUGS BKR5E11 Cross References
| Brand | Part Number |
|---|---|
| ACDelco | 1835270T, 2FR3LS6, FR3CLS6, 1844168T, 41-627, 21025103 |
| Autolite | 3924 |
| Beck/Arnley | 1765234 |
| Bosch | FR8DPX, FR8DX, 4002, 7957, 4202, 7557, FR8DCX |
| CHAMPION | 71, 71ECO |
| Champion Spark Plug | RC12YC5, RC14YC4, 89, RC10YCC4, 985, 471, 2430, RC12YV5 |
| DENSO Auto Parts | K16PR-U11, 3130, K16P-U11 |
| Daihatsu | 90048-51158-008, 90048-51158-000 |
| E3 SPARK PLUGS | E348 |
| E3 Spark Plugs | E3.64 |
| Ford | PBP0118110AA |
| Honda | 980795514E02, 98079-5514E, 980795514EA0 |
| Isuzu | 5-86007635, 5-86007635-0, 5-86123951, 5-86123951-0 |
| Kubota | 12599-6771-6 |
| Mazda | 0000-18-BP01, BP01-18-110, BPY1-18-110 |
| Mitsubishi | MS851357 |
| Motorcraft | SP424, 1Y09, AGSP52C |
| N/A | BKR5E-11, DM652567, 2240150Y05, 1P09-18-110 |
| NGK | 6953 |
| Nissan | 22401 55Y15, 22401-50Y05, 2240155Y75 |
| SYM | 98079-5514E |
| Subaru | 22401KA210 |
| Suzuki | 09482-00566, 99000-79C42-007 |
| Torch | K5RF-11, K5RF11 |
| Toyota | 90048-51158 |
NGK SPARK PLUGS BKR5E11 Fits Vehicles
- Honda TRX520FA7 FourTrax Foreman Rubicon Auto DCT EPS DL (2023-2024)
- Honda SXS520M2 Pioneer 520 (2021-2023)
- Honda TRX520FE EPS (2020-2023)
- Honda TRX520 Auto DCT+EPS (2020, 2022)
- Honda TRX520 4x4 (2020-2022)
- Honda TRX500FE 4x4 ESP (2017)
- Honda TRX420TM 4x4 (2017)
- Honda TRX420TM (2020-2023)
- Honda TRX420FM 4x4 (2017-2018)
- Honda TRX420FM (2020-2023)
- Honda TRX420FE 4x4 ESP (2017, 2021-2023)
- Honda TRX520FM2 FourTrax Foreman 4x4 EPS (2020-2024)
- Honda TRX520FE2 FourTrax Foreman 4x4 ES EPS (2020-2024)
- Honda TRX520FA6 FourTrax Foreman Rubicon Auto DCT EPS (2020-2024)
- Honda TRX520FM6 FourTrax Foreman Rubicon EPS (2020-2024)
- Honda TRX520FM1 FourTrax Foreman 4x4 (2020-2024)
- Honda TRX520FA7 FourTrax Foreman Rubicon Auto DCT EPS DLX (2020-2022)
- Honda TRX520FA5 FourTrax Foreman Rubicon Auto DCT (2020-2024)
- Honda TRX420FE1 FourTrax Rancher 4x4 ES (2015-2024)
- Honda TRX420FA5 FourTrax Rancher 4x4 Auto DCT IRS (2015-2024)
- Honda GL1800B Gold Wing F6B Deluxe (2017)
- Honda TRX500FM7 FourTrax Foreman Rubicon EPS DLX (2016)
- Honda TRX500FA7 FourTrax Foreman Rubicon Auto DCT EPS DLX (2016-2019)
- Honda TRX500FA6D FourTrax Foreman Rubicon Auto DCT EPS DLX (2015)
- Honda TRX500FA5 FourTrax Foreman Rubicon Auto DCT (2015-2019)
- Honda TRX500FM6 FourTrax Foreman Rubicon EPS (2015-2019)
- Honda TRX420FA6 FourTrax Rancher 4x4 Auto DCT IRS EPS (2015-2024)
- Honda TRX500FA6 FourTrax Foreman Rubicon Auto DCT EPS (2015-2019)
- Honda TRX500FM6D FourTrax Foreman Rubicon EPS DLX (2015)
- Honda TRX500FM5 FourTrax Foreman Rubicon (2015-2016)
- Honda SXS500M2 Pioneer 500 (2015-2020, 2022-2023)
- Honda GL1800 Valkyrie (2014-2015)
- Honda GL1800 Valkyrie ABS (2014)
- Honda TRX500FM1 FourTrax Foreman 4x4 (2014-2019)
- Honda TRX500FE1 FourTrax Foreman 4x4 ES (2014-2016)
- Honda TRX420TM1 FourTrax Rancher (2014-2024)
- Honda TRX420FM1 FourTrax Rancher 4x4 (2014-2024)
- Honda TRX500FM2 FourTrax Foreman 4x4 with EPS (2014-2016)
- Honda TRX500FE2 FourTrax Foreman 4x4 ES with EPS (2014-2019)
- Honda TRX420TE1 FourTrax Rancher ES (2014-2016, 2020-2024)
- Honda TRX420FM2 FourTrax Rancher 4x4 with EPS (2014-2016, 2020-2024)
- Honda TRX420FA2 FourTrax Rancher 4x4 Auto DCT with EPS (2014-2024)
- Honda TRX420FA1 FourTrax Rancher 4x4 Auto DCT (2014-2016)
- Honda SXS700M4 Pioneer 700-4 (2014)
- Honda SXS700M2 Pioneer 700 (2014)
- Honda GL1800B Gold Wing F6B (2013-2016)
- Scion xB (2012-2013)
- Honda GL1800HP Gold Wing Audio/Comfort (2010)
- Honda TRX420FPM Rancher 4x4 w/ Power Steering (2009-2013)
- Honda TRX420FPA Rancher AT 4x4 w/ Power Steering (2009-2014)
- Honda TRX420FPE Rancher ES 4x4 w/ Power Steering (2009-2013)
- Honda TRX420FA Rancher AT (2009-2014)
- Honda MUV700 Big Red (2009-2013)
- Honda TRX500FPM FourTrax Foreman 4x4 w/ Power Steering (2008-2009, 2011-2013)
- Honda TRX500FPE FourTrax Foreman 4x4 ES w/ Power Steering (2007-2009, 2011-2013)
- Honda TRX420TE FourTrax Rancher ES (2007-2013)
- Honda TRX420FE FourTrax Rancher 4X4 ES (2007-2013)
- Honda TRX420TM FourTrax Rancher (2007-2013)
- Honda TRX420FM FourTrax Rancher 4X4 (2007-2013)
- Honda GL1800 Gold Wing Airbag (2007-2010, 2012-2016)
- Honda TRX500FE FourTrax Foreman 4x4 ES (2005-2009, 2011-2013)
- Honda TRX500TM FourTrax Foreman (2005-2006)
- Honda TRX500FM FourTrax Foreman 4x4 (2005-2009, 2011-2013)
- Honda NRX1800 Rune (2004-2005)
- Honda GL1800A Gold Wing ABS (2001-2005, 2010, 2012)
- Honda GL1800 Gold Wing (2001-2005)
- Mazda 2 (2011-2014)
- Hyundai Veracruz (2007-2012)
- Kia Rondo (2007-2008)
- Suzuki SX4 (2007-2009)
- Hyundai Entourage (2007-2010)
- Toyota Yaris (2006-2009, 2011-2014)
- Hyundai Azera (2006-2011)
- Saab 9-2X (2006)
- Kia Rio5 (2006-2011)
- Kia Spectra5 (2005-2007)
- Kia Rio (2006-2011)
- Mercedes-Benz ML320 (2003)
- Mercedes-Benz R500 (2006-2007)
- Mercedes-Benz CLS500 (2006)
- Kia Sportage (2005-2010)
- Jaguar Super V8 (2005-2009)
- Hyundai Tucson (2005-2009)
- Kia Magentis (2001-2006)
- Volkswagen Beetle (2004)
- Subaru Outback (2004-2009)
- Subaru Baja (2004-2006)
- Kia Spectra (2004-2007)
- Kia Amanti (2004-2006)
- Chrysler Crossfire (2004-2008)
- Mazda MPV (1996-1998)
- Mazda 626 (1993-2002)
- Mazda Protege5 (2002-2003)
- Mazda Protege (1990-2003)
- Mazda 323 (1990-1991, 1993-1994)
- Mazda 929 (1992-1995)
- Mazda MX-6 (1993-1997)
- Mazda Miata (1994-1997, 1999-2005)
- Mazda MX-3 (1992-1996)
- Nissan NX (1991-1993)
- Toyota Tacoma (1995-2004)
- Toyota T100 (1995-1998)
- Toyota Tundra (2000-2004)
- Toyota Tercel (1995-1999)
- Toyota Supra (1998)
- Toyota Prius (2001-2009)
- Toyota Paseo (1995-1999)
- Toyota MR2 Spyder (2000-2005)
- Toyota Matrix (2003, 2005-2008, 2012-2013)
- Toyota Echo (2000)
- Toyota Corolla (1998-2008, 2012)
- Toyota Celica (2000-2003)
- Toyota 4Runner (1996-2002)
- Mitsubishi Outlander (2003)
- Mitsubishi Lancer (2002-2007)
- Mitsubishi Montero Sport (1997-2004)
- Mitsubishi Diamante (1997-2004)
- Mitsubishi Eclipse (1996-2005)
- Mitsubishi Montero (1994-2002)
- Mitsubishi Expo (1993-1995)
- Mitsubishi Mirage (1993-2002)
- Mitsubishi Expo LRV (1992-1994)
- Mitsubishi Galant (1992-2003)
- Nissan Xterra (2000-2004)
- Nissan Sentra (1991-2001)
- INFINITI QX4 (1997-2000)
- Nissan Quest (1999-2002)
- INFINITI Q45 (1990-2001)
- Nissan Pathfinder (1996-2000)
- Nissan Maxima (1992-2001)
- INFINITI J30 (1993-1997)
- INFINITI I30 (1996-2001)
- INFINITI G20 (1999-2002)
- Nissan Frontier (1998-2004)
- Nissan Altima (1993-2001)
- Nissan 300ZX (1990-1996)
- Nissan 240SX (1991-1998)
- Mercedes-Benz SLK320 (2003-2004)
- Mercedes-Benz SL500 (1999-2000, 2003-2006)
- Mercedes-Benz S500 (2000-2006)
- Mercedes-Benz S430 (2003-2006)
- Mercedes-Benz ML350 (2003-2005)
- Mercedes-Benz ML55 AMG (2003)
- Mercedes-Benz ML500 (2003-2007)
- Mercedes-Benz G500 (2003-2008)
- Mercedes-Benz G55 AMG (2003-2004)
- Mercedes-Benz E500 (2003-2006)
- Mercedes-Benz E320 (2003-2005)
- Mercedes-Benz CLK430 (2003)
- Mercedes-Benz CLK500 (2003-2006)
- Mercedes-Benz CLK320 (2003-2005)
- Mercedes-Benz CL500 (2003-2006)
- Mercedes-Benz C280 (1998)
- Mercedes-Benz C320 (2003-2005)
- Mercedes-Benz C240 (2003-2005)
- Honda Civic (2003-2005)
- Acura RL (2003-2004)
- Mercury Villager (1999-2002)
- Lincoln LS (2000-2006)
- Ford Thunderbird (2002-2005)
- Saturn SW2 (1993-2001)
- Saturn SL2 (1991-2002)
- Saturn SC2 (1993-2002)
- Saturn SC (1991-1992)
- Pontiac Vibe (2003-2008)
- Geo Storm (1992-1993)
- Chevrolet Tracker (2001-2004)
- Chevrolet Prizm (1998-2002)
- Chevrolet Corvette (1990-1992)
- Plymouth Colt (1993-1994)
- Eagle Summit (1992-1996)
- Dodge Stratus (1995-2005)
- Dodge Colt (1993-1994)
- Dodge Avenger (1995-2000)
- Chrysler Sebring (1995-2005)
- Chrysler Cirrus (1995-2000)
- Isuzu Rodeo Sport (2003)
- Isuzu Rodeo (2003-2004)
- Kia Sorento (2003-2009)
- Kia Sedona (2002-2012, 2014)
- Kia Sephia (1995-1997)
- Jaguar XKR (2003-2006)
- Kia Optima (2001-2006)
- Jaguar XK8 (1997-1999, 2003-2006)
- Jaguar XJR (2000-2006)
- Jaguar XJ8 (1998-2007)
- Jaguar Vanden Plas (1998-1999, 2003-2005)
- Jaguar S-Type (2000-2007)
- Subaru Legacy (1996-1999, 2005-2009)
- Subaru Impreza (1998, 2005-2011)
- Subaru Forester (1998, 2005-2010)
- Hyundai XG350 (2002-2005)
- Hyundai XG300 (2001)
- Hyundai Santa Fe (2001-2009)
- Hyundai Sonata (1999-2010)
- Hyundai Elantra (1996-2007)
- Hyundai Tiburon (1997-2001, 2003-2008)
- Hyundai Accent (1995-2011)
- Hyundai Scoupe (1993-1995)
- Suzuki XL-7 (2002-2003)
- Suzuki Vitara (2000-2004)
- Suzuki Grand Vitara (2000-2005)
- Suzuki Aerio (2002-2007)
NGK SPARK PLUGS BKR5E11 Customer Reviews
No reviews yet
Be the first to review this product!
NGK SPARK PLUGS BKR5E11 Questions & Answers
No questions yet
Be the first to ask a question about this product!
California residents see
