(888) 312-8812 Login SignupLELAND L3287 CAMSHAFT, LEFT HAND
No Stock Available
We cannot fulfill orders for this part at this time. Please check back later or request a stock notification to receive an email.
We may have similar parts for sale. Search Alternatives >
LELAND L3287 Part Description
Manufacturer
Features:
- Dim "A": Under Head to Beginning of Lock Ring Groove at Spline End
- Dim "B": Under Head to Beginning of Lock Ring Groove on Bearing Surface
- Brake: Type 8, "XLII" 16-1/2" Brakes 1.094"
- Cam Repair Kits: With L2382 nylatron spider bushing: Using L3146 type fluted cam bracket bushing: K543 - Axle K514 - Wheel End
- Using L3484 and L3485 type with smooth surface cam bracket bushing: K507 - Axle K508 - RH (Curbside) Wheel End K509 - LH (Roadside) Wheel End
- Using L3484 and L3485 type with smooth surface cam bracket bushing: K494 - Axle K482 - RH (Curbside) Wheel End K483 - LH (Roadside) Wheel End
- Heavy Duty Cam Repair Kits with L3127 bronze spider bushing: Using L3146 type fluted cam bracket bushing: K505 - Axle K355 - Wheel End
| Position | Left Hand |
| Dimension A | 20-7/16" |
| Dimension B | 2-7/32" |
| Replaces | Dana M16WKL25-205 |
| Notes | Uses the Same S-head Profile as Post 90 XL Type But Has a Revised 1-5/8" Diameter Spider Bearing Surface |
| Diameter | 1-5/8" |
| Shoulder Diameter | 1-1/2" |
LELAND L3287 Cross References
LELAND L3287 Customer Reviews
No reviews yet
Be the first to review this product!
LELAND L3287 Manufacturer Information
Despite its humble beginnings in 1984 as a manufacturer of cold-headed bolts for agricultural use, Leland Industries® has managed to become today's leading Canadian manufacturer of domestic fasteners for OEM, construction, industrial, and agricultural applications. For more than 35 years, this brand has set the benchmark for high-quality fasteners and cold-headed bolts for grain storage construction. At present, Leland provides a wide range of domestic fasteners, such as A325 structural bolts, roll threading, thread cutting, forging, bent bolt, and other custom fastener solutions. All these Leland fasteners are protected with patented electro-zinc coating, making them up to 25% more corrosion-resistant than similar products. They are made in compliance with A2LA and ISO / IEC-17025 standards.
