(888) 312-8812 Login SignupLELAND L3116 CAM RH ROCKWELL "Q" (LARGE "S"
No Stock Available
We cannot fulfill orders for this part at this time. Please check back later or request a stock notification to receive an email.
We may have similar parts for sale. Search Alternatives >
LELAND L3116 Part Description
Manufacturer
Features:
- Dim "A": Under Head to Beginning of Lock Ring Groove at Spline End
- Dim "B": & "C": Under Head to Beginning of Lock Ring Groove on Bearing Surface
- Brake: Type 12, 1-1/2-28 Spline “Q Plus” S-Head Profile Types. 1.187"
- Rockwell 16-1/2" Cam Repair Kits: Using Non-Rebushable L3033 Type "Bolt On" Spider Bracket: K363 - Axle, Includes L2854 K313 - Wheel, Includes L2854 K490 - Axle, Includes 2854, also services H.D. Forged Spiders K491 - Wheel, Excludes L2854
- Using Rebushable L3525 Type "Bolt On" Spider Bracket with L2942 Type Bushing: K511 - Axle, Includes L2854 K512 - Wheel, Includes L2854 K510 - Wheel, Excludes L2854
- Using L2942 Sintered Metal Spider Bushing: K489 - Axle, Includes L2854 K289 - Wheel, Includes L2854 K290 - Wheel, Excludes L2854 K319 - Wheel, Excludes L2854
- "Q Plus" type cams can be used on Standard 16-1/2" "P" & "Q" brakes in pairs, (LH & RH) on an axle. For converting Standard 16-1/2" brakes with either narrow or wide boss spiders to "Q Plus" brakes or cams, see K319, or L2944 Spacer Adapter.
| Position | Right Hand |
| Dimension A | 24-1/16" |
| Dimension B | 1-11/16" |
| Dimension C | 2" |
| Replaces | Rockwell 2210-D-6868, 2210-U-8159 |
| Notes | Double Grooved For Narrow & Wide Boss Spiders Cam Locks: Use L397 for "A"Groove. Use L897 or L3364 for "B" & "C" Grooves |
| Body Diameter | 1-5/8" |
| Shoulder Diameter | 1-1/2" |
LELAND L3116 Cross References
LELAND L3116 Customer Reviews
No reviews yet
Be the first to review this product!
LELAND L3116 Manufacturer Information
Despite its humble beginnings in 1984 as a manufacturer of cold-headed bolts for agricultural use, Leland Industries® has managed to become today's leading Canadian manufacturer of domestic fasteners for OEM, construction, industrial, and agricultural applications. For more than 35 years, this brand has set the benchmark for high-quality fasteners and cold-headed bolts for grain storage construction. At present, Leland provides a wide range of domestic fasteners, such as A325 structural bolts, roll threading, thread cutting, forging, bent bolt, and other custom fastener solutions. All these Leland fasteners are protected with patented electro-zinc coating, making them up to 25% more corrosion-resistant than similar products. They are made in compliance with A2LA and ISO / IEC-17025 standards.
