FRAM CH11246 Part Description
Manufacturer
Product Description
FRAM, CH11246, Oil Filter
Features & Benefits
- Proven protection for up to 10,000 miles (16,000 kilometers)
- Engineered for use with synthetic or conventional motor oils
- Filter media is a blend of fiber and resin that captures 95% of the dirt particles
- The perfect balance of dirt-trapping efficiency and dirt-holding capacity
- Includes gaskets and O-rings manufactured to endure the high pressures and high temperatures in today’s engines
- Includes gaskets and O-rings manufactured to endure the high pressures and high temperatures in today's engines
Cartridge Oil Filter
FRAM CH11246 Specifications
Product Attributes
| Filter Media Material | Cellulose/Synthetic Blend |
| Height | 6.186 IN |
| Grade Type | Regular |
| Filter Type | Cartridge |
| Non Slip Grip | No |
| Anti-Drain Back Valve | No |
| Bypass Relief Valve | No |
| Grade | Advanced |
| Housing Color | NA |
| Inside Diameter Bottom | 0.709 IN |
| Meets Or Exceeds Original Equipment Manufacturer Specifications | Yes |
| New Or Remanufactured | New |
| O-ring (1) Inside Diameter | 0.630 IN |
| O-ring (1) Outside Diameter | 0.709 IN |
| O-ring (1) Thickness | 0.079 IN |
| O-ring (2) Inside Diameter | 0.552 IN |
| O-ring (2) Outside Diameter | 0.630 IN |
| O-ring (2) Thickness | 0.079 IN |
| O-ring Inside Diameter | 2.049 IN |
| O-ring Outside Diameter | 2.195 IN |
| O-ring Thickness | 0.146 IN |
| O-Rings Included | Yes |
| Outer Diameter Bottom | 1.852 in |
| Outer Diameter Top | 1.852 in |
| Replacable Filter | Yes |
| Reusable | No |
| Top Inside Diameter | 0.709 in |
| Torque Nut | No |
| Washable | No |
| Bottom Inside Diameter | 0.709 IN |
| Outside Diameter Top | 1.852 in |
| Replaceable Filter | Yes |
Additional Information
| Country of Origin (Primary) | KR |
| Harmonized Tariff Code (HTS) | 8421230000 |
| Warranty Special | See Rep |
| Warranty Special UOM | SR |
| Warranty Time | 30 |
| Warranty Time UOM | DA |
| UPC | 00009100550828 |
| UNSPSC | 15121501 |
FRAM CH11246 Cross References
| Brand | Part Number |
|---|---|
| BALDWIN | P40112 |
| Champ | P997 |
| Champion | COC36289 |
| Champion Filters | COC36289 |
| ECOGUARD | X10306 |
| FRAM Drive | FD11246 |
| FVP | G2711800309 |
| Factory Motor Parts | G2711800309 |
| Hengst | E207HD221 |
| LUBER-FINER | P997 |
| MAHLE | OX183/2D, OX183/2D ECO, OX183/5DECO, OX 183/5D ECO, OX 183/5D, OX1835D |
| MANN-HUMMEL FILTERS | HU514Y |
| Mann-Filter | HU514Y, HU 514 Y |
| Mercedes-Benz | 271 180 0309, 271 180 0409, 271 180 0509, 271 184 0425, A 271 180 0309, A 271 180 0409, A 271 184 0425 |
| MicroGard Select | MSL10059 |
| Performax | PO-187 |
| Premium Guard | PG6289, POF6288 |
| Purolator | L36289 |
| STP | S11246 |
| STP Filters | S11246, S11246XL |
| Valvoline | VO-151 |
| WIX FILTERS | WL10059 |
| Wix | 57009 |
FRAM CH11246 Fits Vehicles
- Suzuki Aerio (2002)
- Mercedes-Benz SLK250 (2012-2015)
- Mercedes-Benz C250 (2012-2015)
