(888) 312-8812 Login SignupGATES TR32513 Green Stripe Truck & Bus Series V-Belt
Tap to view 1 more
No Stock Available
We cannot fulfill orders for this part at this time. Please check back later or request a stock notification to receive an email.
We may have similar parts for sale. Search Alternatives >
GATES TR32513 Part Description
Manufacturer
Product Description
Green Stripe Truck & Bus Series V-Belt
Application Summary
1942-1940 Buick, Century, 8-Cyl. 320, Fan & Gen.
Features & Benefits
- Molded notches reduce bending stress, especially on small diameter pulleys, while dissipating heat
- High modulus, high strength tensile cord
- Oil and heat-resistant construction throughout
- Meets SAE J636b and SAE J637 specifications
- Meets RMA oil and heat resistant standards and static conductivity requirements
- NOTE: Some sizes available as Gates PowerBand joined V-belts
GATES TR32513 Specifications
Product Attributes
| Type | Truck & Bus V-Belt |
| Cross Section Designation | XA |
| Angle | 36 |
| Strand Quantity | 1 |
| Top Width | .905 in |
| Outside Circumference | 51.83 in |
| Effective Length | 51.25 in |
| Construction | Notched |
| Notched | Yes |
| Belt Material | EPDM |
| Cord Material | Polyester |
| Top Width | 23 mm |
| Outside Circumference | 1317 mm |
| Effective Length | 1302 mm |
Additional Information
| Harmonized Tariff Code (Schedule B) | 4010323000 |
| Country of Origin (Primary) | US |
| Stock Status | N |
| UPC | 00072053277043 |
| VMRS Code | 065005003 |
| UNSPSC | 26111801 |
GATES TR32513 Cross References
| Brand | Part Number |
|---|---|
| 86200625 | |
| <Unknown> | 112003, 35525 |
| ACDelco | T32513 |
| Albin | 5133123 |
| BF Goodrich | 32517 |
| Carquest | TR32513 |
| Caterpillar | 5H9857 |
| Cummins | 178586, 70174 |
| FWD Truck | 28A29R53 |
| General Motors | 1319975, 2071175, 2103345, 2103347, 2103348, 2103794, 2136715, 2136722, 2190726, 2190952 |
| Globe Lifeline | 1625 |
| Goodyear | 32520 |
| Grumman Flxible | 127094 |
| MBL Three Stars | 34515 |
| Mack | 88GB330P118 |
| Massey Ferguson | 34366A |
| Metric | 23A1300 |
| Mopar | BH-167 |
| NAPA | 25-13070 |
| Teledyne Continental | K600K623, M330K251 |
| U.S. Government | 7324535, MS5107051, S20438 |
| Waukesha | 119031, 119031A, 80281 |
| White | 15538A, 4594873, C12245 |
GATES TR32513 Fits Vehicles
- Buick Roadmaster Series 80 (1940)
- Buick Limited Series 80 (1940)
- Buick Century Series 60 (1940-1942)
- Buick Limited Series 90 (1941-1942)
- Buick Roadmaster Series 70 (1940-1942, 1946-1949)
