GATES TR30448 Part Description
Manufacturer
Product Description
Green Stripe Truck & Bus Series V-Belt
Application Summary
Allis-Chalmers, 6MO672, , Starter
Features & Benefits
- Molded notches reduce bending stress, especially on small diameter pulleys, while dissipating heat
- High modulus, high strength tensile cord
- Oil and heat-resistant construction throughout
- Meets SAE J636b and SAE J637 specifications
- Meets RMA oil and heat resistant standards and static conductivity requirements
- NOTE: Some sizes available as Gates PowerBand joined V-belts
GATES TR30448 Specifications
Product Attributes
| Type | Truck & Bus V-Belt |
| Cross Section Designation | W |
| Angle | 36 |
| Strand Quantity | 1 |
| Top Width | .875 in |
| Outside Circumference | 45.37 in |
| Effective Length | 44.79 in |
| Construction | Notched |
| Notched | Yes |
| Belt Material | EPDM |
| Cord Material | Polyester |
| Top Width | 22 mm |
| Outside Circumference | 1152 mm |
| Effective Length | 1138 mm |
Additional Information
| Harmonized Tariff Code (Schedule B) | 4010323000 |
| Country of Origin (Primary) | US |
| Stock Status | N |
| UPC | 00072053274592 |
| VMRS Code | 065005003 |
| UNSPSC | 26111801 |
GATES TR30448 Cross References
| Brand | Part Number |
|---|---|
| 86200168 | |
| <Unknown> | 10A25, 28446, GSE381, T7334 |
| ACDelco | T30448 |
| Allis Chalmers | 2624, 4002624, 4662778, GSE387 |
| British Leyland | 1B8580, 1B8748 |
| Carquest | TR30448 |
| Clark Equipment | 5204704, 5204704A, PGF12161, PGF13488 |
| Dayco | 953, 30445 |
| Euclid | 142803 |
| FWD Truck | 1A9344 |
| GOODYEAR BELTS | 30448 |
| Gardner Denver | 13C67 |
| General Motors | 2057336, 2190660, 2409675, 5809225 |
| Grumman Flxible | Z3172 |
| Hall Scott | 310619 |
| Hyster | 180303, 40573B |
| Ingersoll/Rand | 31003C |
| International Harvester (IHC) | 109849, 117327H, 117327HA |
| Mack | 89GB25 |
| Metric | 22A1140 |
| Mopar | BH-112 |
| Motor Coach Industries | 8B271 |
| NAPA | 25-11380 |
| Oshkosh | 3392F |
| Pettibone- Mulliken | 200220 |
| Service King | 134P |
| Teledyne Continental | A600K202 |
| Thew | 31003 |
| Towmotor | C629029C19 |
| U.S. Government | 507281 |
| Waukesha | 310036, 31006, 32003 |
| White | 17290A, 40348A, 44314B, 45468A, 466935, 6310619, 66861A, 90022 |
