GATES TR30428 Part Description
Manufacturer
Product Description
Green Stripe Truck & Bus Series V-Belt
Application Summary
Baker, FG60, Hercules QXD3, Fan & Gen.
Features & Benefits
- Molded notches reduce bending stress, especially on small diameter pulleys, while dissipating heat
- High modulus, high strength tensile cord
- Oil and heat-resistant construction throughout
- Meets SAE J636b and SAE J637 specifications
- Meets RMA oil and heat resistant standards and static conductivity requirements
- NOTE: Some sizes available as Gates PowerBand joined V-belts
GATES TR30428 Specifications
Product Attributes
| Type | Truck & Bus V-Belt |
| Cross Section Designation | W |
| Angle | 36 |
| Strand Quantity | 1 |
| Top Width | .875 in |
| Outside Circumference | 43.48 in |
| Effective Length | 42.9 in |
| Construction | Notched |
| Notched | Yes |
| Belt Material | EPDM |
| Cord Material | Polyester |
| Top Width | 22 mm |
| Outside Circumference | 1104 mm |
| Effective Length | 1090 mm |
Additional Information
| Country of Origin (Primary) | US |
| Harmonized Tariff Code (Schedule B) | 4010323000 |
| Stock Status | S |
| UPC | 00072053275445 |
| VMRS Code | 065005003 |
| UNSPSC | 26111801 |
GATES TR30428 Cross References
| Brand | Part Number |
|---|---|
| 86200386 | |
| <Unknown> | 104448H, 11894, 1C10674, 32440, 58166H |
| ACDelco | T30428 |
| Allis Chalmers | 4613868, ASE498 |
| BF Goodrich | 30432 |
| Bendix-Westinghouse | 237425 |
| British Leyland | 1B1280 |
| Brockway | 207812 |
| CONTINENTAL AG | 28423 |
| Carquest | TR30428 |
| Caterpillar | 617148 |
| Chrysler | C102608 |
| Dayco | 904M |
| Divco Trucks | 4359 |
| Dresser | 20011, 51277 |
| Durkee-Atwood | 28-423 |
| Galion | RD37724 |
| Gardner Denver | 13C68 |
| General Motors | 2194218, 839368 |
| Goodyear | 32434, 28429 |
| Grumman Flxible | 17R07, 25BR41 |
| Huber | B762 |
| Hyster | 12553 |
| Koehring | 12192 |
| Lincoln Electric | S8640 |
| MBL Three Stars | 30430 |
| Mack | 88GB330P33, 88GB330P9 |
| Metric | 22A1090 |
| Mopar | BH-264, BH-89, BH-94 |
| NAPA | 25-10880 |
| NAPA Belts/Hose | 25-30428 |
| Otis | 14Y9031 |
| Service King | 130BP |
| Waukesha | 116397, 61203, A61203 |
| White | 141103, 141106, 438928, 62691, CO5578, 204126A |
| Yale | 564251, 6070G4016 |
GATES TR30428 Fits Vehicles
- Ford Super Deluxe (1948)
- GMC 370 (1956-1959)
- GMC S370 (1956-1958)
- GMC F350 (1956-1959)
- GMC F370 (1956-1959)
- Ford Deluxe (1948)
