GATES TR24638 Part Description
Manufacturer
Product Description
Green Stripe Truck & Bus Series V-Belt
Application Summary
Caterpillar, 112F (89J), Caterpillar D333 Diesel, Gen.
Features & Benefits
- Molded notches reduce bending stress, especially on small diameter pulleys, while dissipating heat
- High modulus, high strength tensile cord
- Oil and heat-resistant construction throughout
- Meets SAE J636b and SAE J637 specifications
- Meets RMA oil and heat resistant standards and static conductivity requirements
- NOTE: Some sizes available as Gates PowerBand joined V-belts
GATES TR24638 Specifications
Product Attributes
| Type | Truck & Bus V-Belt |
| Cross Section Designation | TA |
| Angle | 36 |
| Strand Quantity | 1 |
| Top Width | .656 in |
| Outside Circumference | 64.2 in |
| Effective Length | 63.62 in |
| Construction | Notched |
| Notched | Yes |
| Belt Material | EPDM |
| Cord Material | Polyester |
| Top Width | 17 mm |
| Outside Circumference | 1631 mm |
| Effective Length | 1616 mm |
Additional Information
| Country of Origin (Primary) | US |
| Harmonized Tariff Code (Schedule B) | 4010323000 |
| Stock Status | S |
| UPC | 00072053276404 |
| VMRS Code | 065005003 |
| UNSPSC | 26111801 |
GATES TR24638 Cross References
| Brand | Part Number |
|---|---|
| 86200498 | |
| <Unknown> | 24642, 32561B, 644571, 67743 |
| ACDelco | T24638 |
| Alliance Truck Parts | GT498 |
| Allis Chalmers | 4503187, B3187 |
| BF Goodrich | 22640 |
| Bando | 9635, 9630 |
| Bendix-Westinghouse | 213172 |
| Carquest | TR24638 |
| Caterpillar | 1P2421, 1P2423, 2M8502, 6L6842, 7M6100, 7M6105, 7S9857, 7S9858, 8B4881, 8H9832 |
| Clark Equipment | 2519247 |
| Cummins | 162854 |
| Dayco | 608M, 714M, 91, 24640 |
| Ford | C1TE 8620 E, C1TE 8A615 A, C2TE 8620 AB, C2TE 8A615 T, C2TZ 8620 E, C5TE 8620 S, CC3TZ 8620 F |
| GOODYEAR BELTS | 24638 |
| General Motors | 2193103, 2193104, 2193873, 2193874, 5131194, 6403028 |
| Goodyear | 24643 |
| Hall Scott | 403028 |
| International Harvester (IHC) | 798784C1 |
| Leroi | 4186 |
| MBL Three Stars | 24635 |
| Metric | 17A1615 |
| Mitsuboshi | RECMF3635, RECMF3640 |
| Mopar | BH-252 |
| NAPA | 25-16130, 25-16150 |
| NAPA Belts/Hose | 25-24638, TR24638 |
GATES TR24638 Fits Vehicles
- Peterbilt 282 (1978-1980)
