DAYCO 24505 Part Description
DAYCO 24505 Specifications
Product Attributes
| Top Width | .75 in |
| Effective Length | 50.50 in |
| Effective Length | 1282.70 mm |
| Outside Circumference | 51.14 in |
| Outside Circumference | 1298.96 mm |
| Angle | 38 Degrees |
| Material | Synthetic Rubber Compound |
| Belt Construction | Double Cog |
| Banded Belt | N |
| Color | Black |
| Standards | SAE J636, SAE J637 |
| Minimum Operating Temperature | -37.2 C |
| Maximum Operating Temperature | 79.4 C |
| Minimum Operating Temperature | -35 F |
| Maximum Operating Temperature | 175 F |
Additional Information
| Country of Origin (Primary) | CN |
| Harmonized Tariff Code (Schedule B) | 4010323000 |
| UPC | 00038244121274 |
DAYCO 24505 Cross References
| Brand | Part Number |
|---|---|
| AC DELCO | NA |
| BWP-NSI | CT24503 |
| CARQUEST | NA |
| CATERPILLAR | 5UBB455A |
| CONTINENTAL AG | 24503 |
| CUMMINS | 177748, 178641, 183939 |
| DYNACRAFT | D1102-5471 |
| GATES | 650, NA, TR24500 |
| GATES (Canada) | 17A1275 |
| GOODRICH | 24515 |
| GOODYEAR | 24500, 24503 |
| GOODYEAR BELTS | 24500 |
| General Motors | 15550906, 15557815, 15557816, 15573435 |
| HOUGH | 188762, 188762H1 |
| INTERNATIONAL/NAVISTAR | 601684-C1 |
| JOHN DEERE | T5402 |
| KOMATSU | 04120-31950, 600-736-5810, 6676-83-6160 |
| MBL THREE STAR | 24505 |
| MILITARY | MW1626 |
| MOPAR | B24503A, B24504, B24504A, B24512A, BH159, BH164 |
| NAPA | NA |
| Navistar | 601684-C1 |
| UNIROYAL | 24508 |
DAYCO 24505 Fits Vehicles
- Chrysler New York Special (1938)
- Chrysler Airstream Series C-7 (1936)
- GMC Brigadier (1987-1988)
- GMC General (1988)
- Chrysler C19 (1938)
- Cadillac Series 90 (1939)
