GATES BX78 Tri-Power Classical Section Molded Notch V-Belt

Name: Gates BX78 Tri-Power Classical Section Molded Notch V-Belt
SKU: bx78
Price: 27.99 USD
Availability: InStock

Tap to view 2 more

MSRP: $32.16

$27.99

Save $4.17

Limited availability at this price!

In Stock

Get it by Friday, Mar 20

No Hassle Return Policy Details

Free Economy shipping on orders over $499 details

Orders placed over the weekend will be processed the next business day.

GATES BX78 Part Description

Tri-Power Classical Section Molded Notch V-Belt

Caterpillar, 615 (46Z), Caterpillar 3306 Diesel, Fan & Alt.

Belt edge is machined for even pulley groove contact, resulting in less slippage and wear for smoother running
Flex-bonded cords strongly adhere to the body of the belt, resulting in equal load distribution and absorption of bending stress, fatigue and shock loads without cord deterioration
Cross-oriented, fiber-loaded rubber compound for flexibility and stability
Notches molded into the belt during manufacturing make this belt well suited for drives with smaller diameter pulleys
Meets RMA oil and heat resistant standards and static conductivity requirements
Temperature Range: -58 Deg. F to +248 Deg. F (-50 Deg. C to +120 Deg. C)
Note: Available in AX, BX, and CX cross-sections as well as Tri-Power PowerBand joined V-belts

Type	Classical Section Molded Notch V-Belt
Cross Section Designation	BX
Strand Quantity	1
Top Width	.66 in
Outside Circumference	81 in
Construction	Notched
Notched	Yes
Belt Material	EPDM
Cord Material	Polyester
Top Width	17 mm
Outside Circumference	2057 mm

Harmonized Tariff Code (Schedule B)	4010343000
Country of Origin (Primary)	US
Stock Status	S
UPC	00072053015355
VMRS Code	065005003
UNSPSC	26111801
