GATES 21829 Part Description
Manufacturer
Product Description
Premium Modular Coolant Hose
Application Summary
1991-1989 Pontiac, Grand Am, 4-Cyl. 2.3 L, Lower
Features & Benefits
- Specifically-engineered materials resist collapse under vacuum
- Specifically-engineered materials resist collapse under vacuum
- Engineered to resist electrochemical degradation - the leading cause of hose failure
- Engineered to resist electrochemical degradation – the leading cause of hose failure
- EPDM tube; synthetic fiber knit reinforcement, heat-, ozone- and chemical coolant-resistant EPDM cover
- Manufactured with OEM-exact hose components (quick connects, branch connectors/tees, sensors, etc.)
- Meets SAE 20R3 EC Class D1 under 25mm (1 in.) ID, SAE 20R4 EC Class D1 for 25mm (1 in.) ID and over
- Temperature Range: -40 Deg. F to +257 Deg. F (-40 Deg. C to +125 Deg. C)
- Note: Gates recommends replacing clamps each time a new coolant hose is installed
- Caution: Do not use for fuel or oil transfer applications
GATES 21829 Specifications
Product Attributes
| Centerline Length | 24.5 IN |
| Modular | Yes |
| Modular Components Included | Branch |
| Branch Quantity | 1 |
| Quick Connect Fitting Quantity | 0 |
| End 1 Inside Diameter | 1.25 in |
| End 2 Inside Diameter | 1.31 in |
| End 3 Inside Diameter | .72 in |
| Contains Spring | No |
| Material | EPDM, Plastic |
| Molded | Yes |
| Centerline Length | 18 MM |
| End 1 Inside Diameter | 32 MM |
| End 2 Inside Diameter | 33 MM |
Additional Information
| Country of Origin (Primary) | US |
| Harmonized Tariff Code (Schedule B) | 4009310000 |
| Stock Status | N |
| UPC | 00072053132915 |
| VMRS Code | 042004014 |
| UNSPSC | 40142000 |
GATES 21829 Cross References
| Brand | Part Number |
|---|---|
| 42940010 | |
| ACDelco | 26183X |
| CONTINENTAL AG | 61498, 61512, 61643 |
| Canadian Tire | 14-2602-4 |
| Carquest | 21829 |
| Continental Belt | 61643 |
| Dayco | 71453, E71453 |
| Durkee-Atwood | 41498 |
| General Motors | 22540210, 22540211, 22545364, 22545580 |
| Goodyear | 556, 61643, 543, 61498 |
| Motorcraft | KM-2325 |
| NAPA | 8477 |
| NAPA Belts/Hose | 8519 |
| Ultralast | C1829 |
GATES 21829 Fits Vehicles
- Pontiac Grand Am (1989-1991)
- Oldsmobile Cutlass Calais (1989-1991)
- Buick Skylark (1989-1991)
