(888) 312-8812 Login SignupFRAM PH7309 Spin-on Oil Filter
Tap to view 1 more
No Stock Available
We cannot fulfill orders for this part at this time. Please check back later or request a stock notification to receive an email.
We may have similar parts for sale. Search Alternatives >
FRAM PH7309 Part Description
FRAM PH7309 Specifications
Product Attributes
| Height | 3.703 IN |
| Gasket Or Seal Included | Yes |
| Anti-Drain Back Valve | Yes |
| Bypass Relief Valve Setting | 29 PS |
| Bypass Relief Valve | Yes |
| Filter Type | Spin-On Canister |
| Gasket Thickness | 0.078 IN |
| Housing Color | Orange |
| Non Slip Grip | No |
| Torque Nut | No |
| Gasket Inside Diameter | 2.500 IN |
| Gasket Outside Diameter | 2.859 IN |
| Drain Plug Included | No |
| Gasket Type | Base |
| Grade Type | Regular |
| Inlet Type | Threaded |
| Inside Thread Diameter | 1-12 IN |
| New Or Remanufactured | New |
| Outside Diameter | 3.703 IN |
| Reusable | No |
| Thread Size | Standard |
| Universal Or Specific Fit | Specific |
| Universal Or Specific Fit | Specific |
| Inner Thread Diameter | 1-12 IN |
Additional Information
| Country of Origin (Primary) | MX |
| Harmonized Tariff Code (HTS) | 8421230000 |
| Warranty Special | See Rep |
| Warranty Special UOM | SR |
| Warranty Time | 30 |
| Warranty Time UOM | DA |
| UPC | 00009100402363 |
| UNSPSC | 15121501 |
FRAM PH7309 Cross References
| Brand | Part Number |
|---|---|
| AC-DELCO | PF2158 |
| ACDelco | PF2158 |
| ATLAS-COPCO | 2900535100 |
| BALDWIN | BT536 |
| BIG A | 92206 |
| CARQUEST | 85206 |
| FLEETGUARD | LF3415 |
| HASTINGS | LF363, LF414 |
| KOMATSU | 600-211-6240, 600-211-6241 |
| Komatsu | 600-211-6242, 600-211-6630 |
| LUBER-FINER | LFP6240 |
| NAPA | 1206 |
| Onan | 122-0743, 186-0843 |
| WIX FILTERS | WIX FILTERS, 51206, 51231 |
| Wix | 51206 |
FRAM PH7309 Customer Reviews
No reviews yet
Be the first to review this product!
FRAM PH7309 Questions & Answers
No questions yet
Be the first to ask a question about this product!
