(888) 312-8812 Login SignupTRUCK-LITE 81814 Flood Light - 81 Series 7 In. Round LED, Chrome, 10 Diode, 500 Lumen, Blunt Cut, 24V
No Stock Available
We cannot fulfill orders for this part at this time. Please check back later or request a stock notification to receive an email.
We may have similar parts for sale. Search Alternatives >
TRUCK-LITE 81814 Part Description
Manufacturer
Features and Benefits
- Provides a robust, LED, solid-state solution to applications in need of additional lighting
- Popular among utility / construction applications and more
- Displays a very wide light output pattern, ideal for illuminating areas directly in front of the vehicle
- Advanced white LED technology eliminates EMI and offers substantially longer life than comparable incandescent lamps
- Provides a brighter, crisper and whiter light output closer to the color temperature of daylight, dramatically improving light projection distance and increasing visibility
- Metalized reflector redirects light output effectively for a more exact light pattern
- Hard wired design and fully encapsulated electronics protect from damage caused by corrosive elements
- Corrosion resistant E-Coat aluminum housing dissipates heat efficiently
- Impact resistant, non-yellowing polycarbonate lens protects against damage caused by debris and other hazards
Technical Specifications
| Product Type | Flood Light |
| Packaging Type | Standard |
| KIT (Y/N) | No |
| Series | 81 Series |
| VMRS | 034-001-108 |
| Warranty | 1-Year |
| Total Height_INH | 6.98 |
| Total Height_MMT | 177.29 |
| Total Depth_INH | 3.6 |
| Total Depth_MMT | 91.44 |
| Total Width_INH | 6.98 |
| Total Width_MMT | 177.29 |
| Lumens_LM | 1500 |
| Plug Side One | Hardwired |
| Number of Wires | 2 |
| Lens Shape | Round |
| Lens Material | Polycarbonate |
| Lens Color | Clear |
| Sealed/Bulb Replaceable | Sealed |
| Voltage_VLT | 24 |
| Number of Diodes/Bulbs | 10 |
| Mounting Connector Diameter_INH | 0.5 |
| Lighting Technology | LED |
| Housing Color | Black |
| Plug Side Two | Blunt Cut |
| Mount Material | Steel |
| Beam Pattern | Flood |
| Common Size | 7" |
| Mount Type | Bracket Mount |
| Lamp Connection | Hardwired |
| Wire Gauge | 10 |
| Current_AMP | 1.5 |
| Housing Material | Aluminum |
TRUCK-LITE 81814 Cross References
| Brand | Part Number |
|---|---|
| GROTE | 63871 |
TRUCK-LITE 81814 Customer Reviews
No reviews yet
Be the first to review this product!
TRUCK-LITE 81814 Manufacturer Information
Truck-Lite® is a world-renowned manufacturer of mirrors, heavy-duty forward and signal lighting, trailer harnesses, and other safety and visibility-enhancing products. Its main headquarters is located in Falconer, NY, and it maintains ten more facilities across North America and Europe. The company may have started small as a sealed lighting manufacturer in 1955. But it has grown tremendously over the years—in fact, it introduced a series of firsts including the first sealed lighting products, first LED S/T/T lamps, and first forward lighting. Being first in product development has sure paved the way for Truck-Lite to become a successful business today.
