CARTER FUEL PUMPS P76294M Part Description
Manufacturer
Product Description
Fuel Pump Module Assembly
Features & Benefits
- Carter Electric Fuel Pumps and Electric Fuel Pump Assemblies are made with all new materials under rigorous quality controlled manufacturing and testing procedures.
- Quality Carter Electric Fuel Pumps and Fuel Pump Assemblies deliver optimum performance while providing long life.
- Most applications include the necessary accessories such as tank seals, patented high-gradient density strainers and wiring harnesses.
- Fuel sensor design provides resistance to corrosive fuel blends and additives.
CARTER FUEL PUMPS P76294M Specifications
Product Attributes
| Fuel Sending Unit Included | Yes |
| Negative Ground | Yes |
| Outlet Outside Diameter | 9.49 MM |
| Voltage | 12 2H |
| Connector Color | White |
| Regulator Included | No |
| Terminal Type | Blade |
| Mounting Hardware Included | No |
| Universal Or Specific Fit | Specific |
| Grade Type | Regular |
| Connector Shape | Oval |
| Gasket Or Seal Included | Yes |
| Terminal Quantity | 4 |
| Lock Ring Included | No |
| Connector Gender | Male |
| Terminal Gender | Male |
| Strainer Included | Yes |
| Inlet Type | Port |
| Outlet Type | Quick Connect |
| Fuel Filter Included | No |
| Inlet Fitting Thread Size | 3/8 IN |
| Minimum Pressure | 50.0 PS |
| Internal Or External Strainer | Internal |
| Wire Harness Included | No |
| Outlet Fitting Thread Size | 5/16 IN |
| Fuel Tank Pressure Sensor Included | Yes |
| Minimum Flow Rating | 53 GPH |
| Pump Type | Electric |
| 65000 | No Proposition 65 warning is required with this product. |
| Average Current Draw | 11 68 |
| Connector Quantity | 2 |
| Fuel Type | Gas |
| Gasket Or Seal Material | Rubber |
| Height | 367 MM |
| Height | 14.45 IN |
| Inlet Fitting Thread Size | 3/8 |
| Installation Warnings | No |
| Internal or External | Internal |
| Maximum Pressure | 104.4 PSI |
| Minimum Pressure | 98.6 PSI |
| Outlet Fitting Thread Size | 5/16 IN |
| Outlet Outside Diameter | 0.37 IN |
| Outlet Quantity | 1 |
Additional Information
| Country of Origin (Primary) | CN |
| Country of Origin 2 | MX |
| EAR99 | |
| Harmonized Tariff Code (HTS) | 8413309030 |
| Warranty Special | Limited Lifetime Warranty |
| Warranty Special UOM | TX |
| UPC | 00614046954441 |
| VMRS Code | 044003258 |
| UNSPSC | 40151532 |
CARTER FUEL PUMPS P76294M Cross References
| Brand | Part Number |
|---|---|
| 1-800-Radiator | 2920696 |
| ACDelco | MU1856 |
| AIRTEX | E3834M |
| AUTOBEST | F2845A |
| Airtex Fuel Pumps | E3834M |
| Bosch Fuel Pumps | 69965 |
| Canadian Tire | 1234787 |
| Carquest Premium Fuel Pumps | M3496248 |
| DELPHI | FG0908 |
| Delphi Fuel Pumps | FG0908 |
| GMB | 5302595 |
| General Motors | 19168881, 19152607, 19368784 |
| N/A | FG0908, 19206584, 19206583, E3834M, 19152607, 19168881, 2920696, 69965, A31008, C0319M, M3496248, MU1856, SP6629M |
| NAPA Fuel Pumps | C0319M |
| Precision Fuel | A31008 |
| SPECTRA PREMIUM | SP6699M |
| Spectra Premium | SP6629M |
| TruGrade | B11111807TG |
CARTER FUEL PUMPS P76294M Fits Vehicles
- GMC Sierra 1500 (2007-2008)
- Chevrolet Silverado 1500 (2007-2008)
