CENTRIC 125.35051 Part Description
Manufacturer
Product Description
Centric Premium High Carbon Alloy Brake Rotor
Features & Benefits
- Centric Premium Rotor with advanced metallurgy that greatly reduces pad squeal. Especially effective with higher friction; European style brake pad compounds. Added Molybdenum and Chromium to resist rotor cracking
- Painted hat and outer edge for corrosion resistance
- Painted Hat and Outer Edge
- Optimal Surface Finish
- Optimal surface finish for consistent stopping feel from the first stop
- Advanced Metallurgy
- Advanced metallurgy for optimal heat transfer and structural strength
- OE Vane Design and Plate Thickness
- OE vane design and plate thickness for heat capacity and strength
- Low Initial Lateral Run-Out
- Low initial lateral run-out and disc thickness variation for smooth, vibration free stopping
- Precision Balance
- Precision balance for vibration free performance
CENTRIC 125.35051 Specifications
Product Attributes
| Disc Mounting [cntrc] | Floating / DIH |
| Weight [cntrc] Lbs | 11.320 |
| Product Grade [cntrc] | Premium |
| Weight [cntrc] Kgs | 5.150 |
| Vane Style [cntrc] | Straight |
| Misc Holes [cntrc] | 2 |
| California Proposition 65 Text [cntrc] | WARNING: Cancer and Reproductive Harm |
| Discard Thickness | 17.400 MM |
| Discard Thickness | 0.685 IN |
| Nominal Thickness | 0.787 IN |
| Nominal Thickness | 20.000 MM |
| Hat Finish | Painted |
| Overall Height | 55.200 MM |
| Overall Height | 2.173 IN |
| Outside Diameter | 278.000 MM |
| Outside Diameter | 10.945 IN |
| ABS Tone Ring Included | No |
| Surface Type | Smooth |
| Solid Or Vented Type Rotor | Vented |
| Nominal Drum Diameter | 164.000 MM |
| Nominal Drum Diameter | 6.457 IN |
| Bearings Included | No |
| Center Hole Diameter | 67.000 MM |
| Center Hole Diameter | 2.638 IN |
| Mounting Bolt Hole Circle Diameter | 112.000 MM |
| Mounting Bolt Hole Circle Diameter | 4.409 IN |
| Stud/Lug Hole Quantity | 5 |
| Stud/Lug Hole Diameter | 0.587 IN |
| Stud/Lug Hole Diameter | 14.900 MM |
Additional Information
| Harmonized Tariff Code (HTS) | 8708305030 |
| NAFTA Preference Criterion Code | B |
| Country of Origin (Primary) | IT |
| Harmonized Tariff Code (Schedule B) | 8708300050 |
| UPC | 00805890765837 |
CENTRIC 125.35051 Cross References
| Brand | Part Number |
|---|---|
| N/A | 45675, 125.35051, 25765, 90063043, 1244230612, 1244231012, 96666P |
| RAYBESTOS | 96666R |
| Raybestos Brakes | 96666R |
CENTRIC 125.35051 Fits Vehicles
- Mercedes-Benz E320 (1994-1995)
- Mercedes-Benz 300TE (1993)
