REACH COOLING 41-839 Radiator

41-839 by REACH COOLING - Radiator
REACH COOLING
Tap to view 1 more

No Stock Available

We cannot fulfill orders for this part at this time. Please check back later or request a stock notification to receive an email.

We may have similar parts for sale. Search Alternatives >

REACH COOLING 41-839 Part Description

Manufacturer

REACH COOLING

Product Description

Radiator

Features & Benefits

  • Our deep extrusion header provides a stronger tube to header joint which is more resistant to the effects of vibration and thermal tube expansion, virtually eliminating tube to header leaks.
  • Our B-Type tubes feature central reinforcement to provide greater tolerance to pressure. Stronger tube design means drastically reduced probability of tube failure.
  • Thermal expansion reduce failure rates by allowing improved core expansion and contraction.
  • Folded fin edges increase stability and heat disbursement properties.
  • We use longer header tabs for increased pressure resistance. This reduces the potential for tank to header leaks.
  • Our included "multi-fit" attachments allow one radiator to cover multiple vehicle applications without sacrificing OE fit. This results in wider vehicle coverage with substantially less inventory.
  • Reach B-Type tubes feature central reinforcement to provide greater tolerance to pressure reducing the probability of tube failure.
  • Thermal expansion cuts allow for longer life and reduce failure rates by allowing improved core expansion and contraction during normal heat cycles.
  • We design and manufacture all our radiators to meet or even exceed Original Equipment specifications. We take pride in producing the most reliable replacement parts in the market.
  • Our fin edges are folded for increased stability and heat disbursement properties.
  • Reach utilizes longer header tabs for increased pressure resistance, this reduces the potential for tank-to-header leaks.
  • Deep extrusion headers provide a stronger tube-to-header joint that is more resistant to the effects of vibration and thermal tube expansion.
  • Radiators are the foundation of any engine cooling system. Tasked with preventing the vehicle from overheating, the radiator is vital to keeping vehicles up and running.
  • Our B-Type tubes feature central reinforcement to provide greater tolerance to pressure. Stronger tube design means drastically reduced probability of tube failure.
Radiator

REACH COOLING 41-839 Specifications

Product Attributes

Core Thickness 1.25 IN
Core Width 17 IN
Core Width 431.80 MM
Inlet Header Length 473.08 MM
Inlet Diameter 33.324 mm
Core Material Aluminum
Transmission Oil Cooler Included No
Inlet Header Length 473.075 mm
Outlet Header Width 60.325 mm
Inlet Header Length 18.625 IN
Tank Material Plastic
Outlet Diameter 39.7 MM
Inlet Header Width 60.325 mm
Core Height 28.25 IN
Core Height 717.55 MM
Inlet Header Width 60.3 MM
Outlet Header Width 2 3/8 IN
Outlet Diameter 1 9/16 IN
Outlet Header Length 476.3 MM
Inlet Header Width 2 3/8 IN
Radiator Cap Included No
Core Thickness 31.75 MM
Core Width 431.8 MM
Outlet Diameter 39.674 MM
Engine Oil Cooler Included No
Core Height 717.55 MM
Outlet Header Length 476.25 mm
Outlet Header Width 60.3 MM
Inlet Diameter 1 5/16 IN
Core Row Quantity 1
Core Thickness 31.75 MM
Outlet Header Length 18 3/4 IN
Inlet Diameter 33.3 MM

REACH COOLING 41-839 Cross References

BrandPart Number
APDI8010709
Autokool840
DPI (DataPoint Inc)839, 711
General Motors3057965, WS8680, 3046785, 3057983, LT8680, WR8680, 3043867, 3057964, 3057979, WN8681, 3055200, WF8681, 3043865, 3043873, 3057963, 20228, 20229, 3046786, 3057982, WH8680, 20092, 20094, 3043866, 3043872, 3057981, WM8681
Modine3533, 839, 3523, 711
NAPACU839
OSC711, 839, 709
Performance Radiator840
Proliance433711, 433839
Spectra PremiumCU839
Thermal Solutions Manufacturing40242
Vista Pro709, 8839, 433711, 433839

REACH COOLING 41-839 Customer Reviews

No reviews yet

Be the first to review this product!

REACH COOLING 41-839 Manufacturer Information

Founded in 1999, Reach Cooling® is a worldwide leader in the manufacture and distribution of aftermarket cooling products for light, medium, and heavy duty truck applications. Its fasting-growing division is within its medium and heavy duty truck part sector, offering more than 30 HD condensers, more than 50 HD charge air coolers, and more than 100 HD radiators. All these products are manufactured to meet the highest OE standards to fit some of the most popular US truck makes, including Peterbilt, Mack, International, Isuzu, GMC, Ford, and Freightliner. Headquartered in Miami, Florida, Reach Cooling is fully committed to providing customers with only the best products, most competitive prices, and exceptional service.
