RAYBESTOS 980818 Raybestos Specialty - Street Performance Brake Rotor

$151.49

Limited availability at this price!

1 Day Lead Time

Get it by Thursday, Mar 5
No Hassle Return Policy Details
Free Economy shipping on orders over $499 details
This item will ship about 1 day after the date of purchase

RAYBESTOS 980818 Part Description

Manufacturer

RAYBESTOS

Product Description

Raybestos Specialty - Street Performance Brake Rotor

Application Summary

2015-2012 Mercedes-Benz C250 Front, 2017-2013 Mercedes-Benz E400 Front, 2017-2015,2011-2010 Mercedes-Benz E550 Front

Features & Benefits

  • Application Specific Enhanced Iron
  • Raybestos® Performance Rotors are made with enhanced iron which suppresses noise and keeps brakes running cool, quiet and vibration free.
  • Raybestos(R) Performance Rotors are made with enhanced iron which suppresses noise and keeps brakes running cool, quiet and vibration free.
  • Cooling Vanes
  • The cooling vanes match OE configurations and provide optimal cooling and reduced fade.
  • Application Specific Coating
  • Depending on the application, Performance Rotors will have one of the following finishes: Black fusion coating on the rotor hat Grey Fusion 4.0® coating on the entire rotor
  • Depending on the application, Performance Rotors will have one of the following finishes: Black fusion coating on the rotor hat Grey Fusion 4.0(R) coating on the entire rotor
  • Black fusion coating on the rotor hat and Grey Fusion 4.0® coating on the rotor inboard surface and cooling vanes
  • Black fusion coating on the rotor hat and Grey Fusion 4.0(R) coating on the rotor inboard surface and cooling vanes
  • Turned Finish
  • Turned finish minimizes noise and improves responsiveness for smoother stops.
  • S-Groove Slot
  • Depending on the application, some Raybestos® Performance Rotors are designed with a patented S-Groove Slot.
  • Depending on the application, some Raybestos(R) Performance Rotors are designed with a patented S-Groove Slot.

RAYBESTOS 980818 Specifications

Product Attributes

ABS Tone Ring Included No
Center Hole Diameter 2.634 IN
Center Hole Diameter 66.9 MM
Conventional Or Drum-In-Hat Type Rotor Conventional
Discard Thickness 1.181 IN
Discard Thickness 30 MM
Harmonize Code 8708.30.5030
Inside Diameter 8.602 IN
Inside Diameter 218.5 MM
Mounting Bolt Hole Circle Diameter 4.409 IN
Mounting Bolt Hole Circle Diameter 112 MM
Mounting Bolt Hole Diameter 0.595 IN
Mounting Bolt Hole Diameter 15.1 MM
Mounting Bolt Hole Quantity 5
Nominal Thickness 1.26 IN
Nominal Thickness 32 MM
Outside Diameter 13.543 IN
Outside Diameter 344 MM
Overall Height 2.535 IN
Overall Height 64.4 MM
Salability Restrictions No
Solid Or Vented Type Rotor Vented
Stud/Lug Hole Quantity 5
Surface Type Smooth
UNSPSC Code 25171715

Additional Information

Country of Origin (Primary) CN
Canadian Harmonizing Tariff Code 8708309990
Harmonized Tariff Code (HTS) 8708305030
UPC 00829352838259

RAYBESTOS 980818 Cross References

BrandPart Number
ADVANCE AUTO PARTSYH290797, YH290797C, YH290797P
ATE BRAKE PRODUCTS432168, SP32168
AUTOZONE76615, 76615DG
BENDIXPRT6029
BOSCH36010980
BRAKEBEST36010980, 980818, 980818RGS
Brembo09.B746.51, 09.B746.61
CENTRIC121.35120, 128.35120, 228.35120, 320.35120
Centric Parts121.35120, 128.35120, 228.35120, 320.35120
DURA CORPBR34444
MERCEDES-BENZ0004211412, 000421141207, 2044211112
NEOTEK1065522GF
POWERSTOPEBR1451EVC
PROMAX14-34444
Qualis45472
WINHERE6621231DR
WORLDPAC1407-290797

RAYBESTOS 980818 Fits Vehicles

  • Mercedes-Benz E400 (2013-2017)
  • Mercedes-Benz C250 (2012-2015)
  • Mercedes-Benz E550 (2010-2011, 2015-2017)
