FRAM CH9690 Part Description
Manufacturer
Product Description
FRAM, CH9690, Oil Filter
Features & Benefits
- Proven protection for up to 10,000 miles (16,000 kilometers)
- Engineered for use with synthetic or conventional motor oils
- Filter media is a blend of fiber and resin that captures 95% of the dirt particles
- The perfect balance of dirt-trapping efficiency and dirt-holding capacity
- Includes gaskets and O-rings manufactured to endure the high pressures and high temperatures in today’s engines
- Includes gaskets and O-rings manufactured to endure the high pressures and high temperatures in today's engines
Cartridge Oil Filter
FRAM CH9690 Specifications
Product Attributes
| Filter Media Material | Cellulose/Synthetic Blend |
| Height | 5.644 IN |
| Grade Type | Regular |
| Filter Type | Cartridge |
| Non Slip Grip | No |
| Anti-Drain Back Valve | No |
| Bypass Relief Valve | No |
| Grade | Advanced |
| Housing Color | NA |
| Inside Diameter Bottom | 1.313 IN |
| Meets Or Exceeds Original Equipment Manufacturer Specifications | Yes |
| New Or Remanufactured | New |
| O-ring Inside Diameter | 3.441 IN |
| O-ring Outside Diameter | 3.585 IN |
| O-ring Thickness | 0.144 IN |
| O-Rings Included | Yes |
| Outer Diameter Bottom | 2.867 in |
| Outer Diameter Top | 2.867 in |
| Replacable Filter | Yes |
| Reusable | No |
| Top Inside Diameter | 0.360 in |
| Torque Nut | No |
| Washable | No |
| Washer Inside Diameter | 1.261 IN |
| Washer Outside Diameter | 1.810 IN |
| Washer Thickness | 0.080 IN |
| Bottom Inside Diameter | 1.313 IN |
| Outside Diameter Top | 2.867 in |
| Replaceable Filter | Yes |
Additional Information
| Country of Origin (Primary) | KR |
| Harmonized Tariff Code (HTS) | 8421230000 |
| Warranty Special | See Rep |
| Warranty Special UOM | SR |
| Warranty Time | 30 |
| Warranty Time UOM | DA |
| UPC | 00009100043207 |
| UNSPSC | 15121501 |
FRAM CH9690 Cross References
| Brand | Part Number |
|---|---|
| BALDWIN | P40095 |
| CHAMP | P961 |
| CHAMP FILTERS | P961 |
| Carquest Premium Filters | 84329 |
| ECOGUARD | X5579 |
| FVP | G7329 |
| Factory Motor Parts | G7329 |
| HENGST | E355H01 D58 |
| Hastings | LF566 |
| LUBER-FINER | P961 |
| MAHLE | OX358DECO, OX 358D ECO, OX 358D |
| MANN & HUMMEL | HU835/1X |
| MANN-HUMMEL FILTERS | HU835/1Z |
| Mann-Filter | HU835/1X |
| NAPA | 7329 |
| PREMIUM GUARD | PG5579EX |
| PUROLATOR | L45579 |
| Parts Master | 67330 |
| Pentius | PCB9690 |
| Premium Guard | PG5579 |
| SECURITY | CH-9690 |
| STP | P961 |
| STP Filters | P961, P961XL |
| VW-AUDI-PORSCHE | 079 115 561B |
| Valvoline | VO-94 |
| Volkswagen | 079 115 561B, 079 198 405, 079 198 405A, 07C 115 562A |
| WIX FILTERS | 57329 |
| Wix | 57329 |
FRAM CH9690 Fits Vehicles
- Suzuki Aerio (2002)
- Audi Q7 (2007)
- Audi A6 Quattro (2005-2006)
- Audi S4 (2004-2009)
- Audi A8 Quattro (2004-2006)
- Audi Allroad Quattro (2004-2005)
- Volkswagen Phaeton (2004-2006)
