RAYBESTOS 680982R2 Part Description
Manufacturer
Product Description
Raybestos R-Line+ Brake Rotor
Features & Benefits
- Painted Hat and Edges
- Top-Notch Surface Finish
- Superior surface finish for consistent braking.
- OE Vane Design
- OE vane design and plate thickness for heat capacity and strength.
- Advanced Metallurgy
- Advanced metallurgy for structural strength and heat transfer.
- Low Initial Lateral Run-out
- Low initial lateral run-out and disc thickness variation for smooth, vibration free braking.
- Precision Balance
- Precision balance for vibration free performance.
Raybestos R-Line+ Brake Rotor
RAYBESTOS 680982R2 Specifications
Product Attributes
| ABS Tone Ring Included | No |
| Center Hole Diameter | 2.68 IN |
| Conventional Or Drum-In-Hat Type Rotor | Conventional |
| Directional or Non-Directional Brake Surface | Non-Directional |
| Discard Thickness | 1.181 IN |
| Inside Diameter | 9.476 IN |
| Material | Cast Iron |
| Mounting Bolt Hole Circle Diameter | 4.5 IN |
| Mounting Bolt Hole Diameter | 0.61 IN |
| Mounting Bolt Hole Quantity | 5 |
| Nominal Thickness | 1.26 IN |
| Outside Diameter | 13.858 IN |
| Overall Height | 1.85 IN |
| Solid Or Vented Type Rotor | Vented |
| Stud/Lug Hole Quantity | 5 |
| Surface Type | Smooth |
| Harmonize Code | 8708.30.5030 |
| Salability Restrictions | No |
| UNSPSC Code | 25171715 |
| Center Hole Diameter | 68.05 MM |
| Discard Thickness | 30 MM |
| Inside Diameter | 240.7 MM |
| Mounting Bolt Hole Circle Diameter | 114.3 MM |
| Mounting Bolt Hole Diameter | 15.5 MM |
| Nominal Thickness | 32 MM |
| Outside Diameter | 352 MM |
| Overall Height | 47 MM |
Additional Information
| Country of Origin (Primary) | CN |
| Canadian Harmonizing Tariff Code | 8708309990 |
| Harmonized Tariff Code (HTS) | 8708305030 |
| UPC | 00887213446524 |
RAYBESTOS 680982R2 Cross References
| Brand | Part Number |
|---|---|
| Advance Auto Parts | G15590SD, YH477752C, YH477752P |
| AutoZone | 75010DG, 75010DL, 75010 |
| Autopartsource | 492128 |
| Autoxtra | AX901158, AX901158P |
| Bendix | PRT6201, SDR6124 |
| BrakeBest | 680982, 680982FZN, 680982P, 680982R, 680982RGS |
| Centric Parts | 120.65136, 120.65136CRY, 121.65136, 125.65136, 126.65136CSL, 126.65136CSR, 126.65136SL, 126.65136SR, 126.65154CSL, 126.65154CSR, 127.65136L, 127.65136R, 128.65136L, 128.65136R, 227.65136L, 227.65136R, 320.65136, 321.65136 |
| Dura Corp | BR54188, BR901158 |
| DuraGo | BR901158, BR901158-03 |
| Eurorotor | 54195 |
| Ford | DG1Z1125B, DG1Z1125C, EU2Z1V125B |
| Motorcraft | BRRF112, BRRF202 |
| Newtek Automotive USA | 54188 |
| Parts Master | 901158 |
| PowerStop | AR85141EVC |
| Promax | 14-54188 |
| Qualis | 42284 |
| TopNotch | TN680982GEO |
| Ultra Brake | 54195 |
| WABCO - Archived | PS901158 |
| WORLDPAC | 1407-477752, 1427-731818 |
| Wagner Brake | BD180535, BD180535E |
| Winhere | 6621453, 6622104 |
| Worldparts | WS1-154188 |
RAYBESTOS 680982R2 Fits Vehicles
- Ford Police Responder Hybrid (2019-2020)
- Lincoln MKT (2013-2019)
- Ford Special Service Police Sedan (2014-2018)
- Ford Police Interceptor Utility (2013-2019)
- Ford Police Interceptor Sedan (2013-2019)
- Ford Taurus (2013-2019)
- Ford Flex (2012-2019)
- Lincoln MKS (2012-2016)
- Ford Explorer (2013-2019)
