RAYBESTOS 580763R2 Part Description
Manufacturer
Product Description
Raybestos R-Line+ Brake Rotor
Features & Benefits
- Painted Hat and Edges
- Top-Notch Surface Finish
- Superior surface finish for consistent braking.
- OE Vane Design
- OE vane design and plate thickness for heat capacity and strength.
- Advanced Metallurgy
- Advanced metallurgy for structural strength and heat transfer.
- Low Initial Lateral Run-out
- Low initial lateral run-out and disc thickness variation for smooth, vibration free braking.
- Precision Balance
- Precision balance for vibration free performance.
Raybestos R-Line+ Brake Rotor
RAYBESTOS 580763R2 Specifications
Product Attributes
| ABS Tone Ring Included | No |
| Center Hole Diameter | 2.65 IN |
| Conventional Or Drum-In-Hat Type Rotor | Drum-In-Hat |
| Directional or Non-Directional Brake Surface | Non-Directional |
| Discard Thickness | 0.724 IN |
| Inside Diameter | 8.49 IN |
| Material | Cast Iron |
| Mounting Bolt Hole Circle Diameter | 4.72 IN |
| Mounting Bolt Hole Diameter | 0.632 IN |
| Mounting Bolt Hole Quantity | 5 |
| Nominal Thickness | 0.79 IN |
| Outside Diameter | 11.926 IN |
| Overall Height | 2.822 IN |
| Solid Or Vented Type Rotor | Vented |
| Stud/Lug Hole Quantity | 5 |
| Surface Type | Smooth |
| Harmonize Code | 8708.30.5030 |
| Salability Restrictions | No |
| UNSPSC Code | 25171715 |
| Center Hole Diameter | 67.3 MM |
| Discard Thickness | 18.4 MM |
| Inside Diameter | 215.65 MM |
| Mounting Bolt Hole Circle Diameter | 119.9 MM |
| Mounting Bolt Hole Diameter | 16.05 MM |
| Nominal Thickness | 20.05 MM |
| Outside Diameter | 302.9 MM |
| Overall Height | 71.7 MM |
Additional Information
| Country of Origin (Primary) | CN |
| Canadian Harmonizing Tariff Code | 8708309990 |
| Harmonized Tariff Code (HTS) | 8708305030 |
| UPC | 00887213445992 |
RAYBESTOS 580763R2 Cross References
| Brand | Part Number |
|---|---|
| Advance Auto Parts | 290958, YH290958, YH290958C, YH290958P |
| AutoZone | 72010, 72010DG |
| Autopartsource | 593119 |
| Autoxtra | AX900824, AX900824P |
| Bendix | PRT5973, PRT5996 |
| Bosch | 25011463 |
| BrakeBest | 25011463, 580763, 580763R, 580763RGS |
| Brembo | 09.A629.21 |
| Centric Parts | 120.66073, 121.66073, 126.66073CSL, 126.66073CSR, 126.66073SL, 126.66073SR, 127.66073L, 127.66073R, 128.66073CL, 128.66073CR, 128.66073L, 128.66073R, 320.66073, 321.66073 |
| Dura Corp | BR55178, BR900824, BR90082402 |
| DuraGo | 900824, BR900824, BR90082402, BR900824-02 |
| Dynamic Friction Company | 604-48058 |
| General Motors | 20792027, 25810586 |
| Monroe Brakes | BD180358 |
| Newtek Automotive USA | 55178 |
| Omnicraft | QBRR113 |
| Parts Master | 900824 |
| PowerStop | AR82152EVC |
| Promax | 14-55178 |
| Qualis | 41262 |
| TopNotch | TN580763GEO |
| UAP | 2055178, 55178 |
| Ultra Brake | 55996 |
| WORLDPAC | 1407-290958, 1427-596302 |
| Wagner Brake | BD180358, BD180358E |
| Winhere | 6621222 |
| Worldparts | WS1-155178 |
RAYBESTOS 580763R2 Fits Vehicles
- Chevrolet Equinox (2010-2017)
- GMC Terrain (2010-2017)
