(888) 312-8812 Login SignupMONROE 66464 Magnum Suspension Shock Absorber
Tap to view 5 more
$7749
Limited availability at this price!
In Stock
Get it by Thursday, Feb 12
MONROE 66464 Part Description
Manufacturer
Product Description
Magnum Suspension Shock Absorber
Features & Benefits
- FOR HARDWORKING COMMERCIAL VEHICLES -- Designed to handle the demands of high mileage and severe use class 6-8 trucks and buses
- CONSISTENT RIDE -- All-weather fluid contains special additives to assist with extreme temperatures and help reduce oil breakdown
- EXCEPTIONAL HANDLING -- 10-Stage valving, tuned specifically to each vehicle, adjusts to road extremes
- STRONG AND DURABLE -- Shouldered bushing and bonded bushing with sleeve protects from bushing walkout for improved quality; arc welds up to 360° for durability
- STRONG AND DURABLE -- Shouldered bushing and bonded bushing with sleeve protects from bushing walkout for improved quality; arc welds up to 360deg for durability
- BUILT TO LAST -- Robust hydraulic lock-out prevents over extension of air bags, top-out of the piston and averts damage to seal assembly
- LONGER SERVICE LIFE -- Nitrocarburized piston rod provides durability and longer service life
- REDUCED NOISE, VIBRATION AND HARSHNESS -- Delivers exceptional control and isolates impact-related noise, vibration and harshness under most driving conditions
- IMPROVES PERFORMANCE -- Nitrogen gas-charge maintains tire-to-road contact for improved ride and handling by reducing aeration and shock fade
- BUY WITH CONFIDENCE -- Comes with Monroe’s 90-day Risk Free Ride Offer and Limited Commercial Warranty
- BUY WITH CONFIDENCE -- Comes with Monroe's 90-day Risk Free Ride Offer and Limited Commercial Warranty
SHOCK
MONROE 66464 Specifications
Product Attributes
| Lower Mount Code | S6 |
| Upper Mount Code | LS65 |
| Compressed Bumper Stop | No |
| Dust Shield | Yes |
| Extended Bumper Stop | No |
| Extended Hydraulic Lockout | Yes |
| Body Diameter | 2 IN |
| Compressed Length | 13.78 IN |
| Extended Length | 21.42 in |
| Lower Mount Type | Stem Mount - 3 5/16" Stem Length X 5/8"-11 Thread Pitch |
| Parts Pack(s) | P01482 |
| Shock Absorber Body End Measuring Point | Base of Stem |
| Shock Absorber Rod End Measuring Point | Center of Loop |
| Travel Length | 7.63 in |
| Upper Mount Type | Loop Bushing and Sleeve Mount - 1" Sleeve ID X 2" Sleeve OAL |
| Compressed Length | 350 MM |
| Extended Length | 544.1 MM |
| Travel Length | 193.8 MM |
| Body Diameter | 50.8 MM |
| Dust Shield Included | Yes |
| Lower Mount Type | Stem |
| Lower Mount Code | S6 |
| Upper Mount Code | LS65 |
| Mounting Hardware Included | Yes |
| Grade Type | Premium |
| Active or Passive Suspension | Passive |
| Adjustable Compression | No |
| Adjustable Rebound | No |
| Adjustable Ride Height | No |
Additional Information
| MSDS Sheet Number | 01164 |
| Country of Origin (Primary) | US |
| Canadian Harmonizing Tariff Code | 8708803000 |
| Harmonized Tariff Code (Schedule B) | 8708800050 |
| Harmonized Tariff Code (HTS) | 8708801600 |
| UPC | 00048598245182 |
| VMRS Code | 016008003 |
| UNSPSC | 25172011 |
MONROE 66464 Cross References
MONROE 66464 Fits Vehicles
- Kenworth W990 (2019-2024)
- Mack LR (2019-2024)
- Mack TerraPro (2022-2025)
- Western Star 47X (2022-2024)
- Western Star 49X (2021-2024)
- International HV507 (2019-2025)
- International HV513 (2019-2025)
- International HV613 (2019-2025)
- International HV607 (2019-2025)
- International HX520 (2018-2022)
- International HX620 (2017-2026)
- International HX615 (2017-2022)
- International HX515 (2017-2022)
- International 5600i (2004-2014)
- International 7500 (2002-2020)
- International 7400 (2002-2020)
- International 7300 (2002-2020)
- Peterbilt 548 (2022-2025)
- Peterbilt 520 (2017-2024)
- Peterbilt 389 (2008-2024)
- Peterbilt 388 (2008-2015)
- Peterbilt 367 (2008-2024)
- Peterbilt 567 (2014-2024)
- Peterbilt 365 (2008-2023)
- Peterbilt 320 (2001-2018)
- Peterbilt 348 (2010-2023)
- Peterbilt 357 (2002-2008)
- Kenworth T480 (2022-2024)
- Kenworth T880 (2014-2024)
- Kenworth T680 (2013-2024)
- Kenworth T400 (2010-2022)
- Kenworth W900 (2001-2024)
- Kenworth T800 (2001-2024)
- Kenworth T370 (2008-2023)
- Kenworth T270 (2008-2023)
- Freightliner 122SD (2013-2023)
- Freightliner M2 (2005-2021)
- Freightliner 114SD (2012-2023)
- Freightliner 108SD (2012-2023)
- Freightliner Condor (2001-2007)
- Freightliner M2 112 (2003-2021)
- Freightliner M2 106 (2002-2025)
- Mack Anthem (2018-2024)
- Mack Granite (2015-2024)
- Mack GU8 (2008-2019)
- Mack GU7 (2008-2019)
- Mack GU5 (2012-2018)
- Mack GU4 (2012-2019)
- Volvo VHD (2001-2024)
- Western Star 4800SF (2013-2022)
- Western Star 4800SB (2012-2022)
- Western Star 4700SF (2012-2021)
- Western Star 4700SB (2012-2021)
- Western Star 4900FA (2002-2023)
- Western Star 4900EX (2002-2022)
- Western Star 4900E (2001-2002)
- Western Star 4900SA (2002-2023)
- Autocar LLC. DC-64 (2020-2023)
- Autocar LLC. Xpeditor (2008-2022)
- Autocar LLC. Xpert (2012, 2014-2021)
- Caterpillar CT660 (2012-2017)
MONROE 66464 Customer Reviews
No reviews yet
Be the first to review this product!
MONROE 66464 Manufacturer Information
Monroe products are built for the road ahead. Since its founding in 1916, Monroe® has been known for its world-class solutions that are precision-engineered and meticulously tested with the specific vehicle's ride and handling profile in mind. As the leading supplier of Original Equipment ride control products to global automotive manufacturers, Monroe helped establish the benchmarks of handling and ride excellence in every stage of a vehicle's life. Whether you're upgrading your truck, converting its suspension, or restoring its original state, Monroe has got you covered. It offers the best-in-class shocks, strut assemblies, steering stabilizers, conversion kits, lift support, and many other suspension components that will help enhance your safety and driving experience.
