RAYBESTOS 980426 Part Description
Manufacturer
Product Description
Raybestos Specialty - Truck Brake Rotor
Application Summary
2012-2007 Mercedes-Benz GL450 Front, 2012-2008 Mercedes-Benz GL550 Front, 2012-2010,2006 Mercedes-Benz R350 Front, 2012-2010 Mercedes-Benz GL350 Front, 2011-2008 Mercedes-Benz ML550 Front, 2009-2007 Mercedes-Benz GL320 Front
Features & Benefits
- OE Fit, Form, and Function
- Our vehicle-specific design matches OE fit, form and function, providing ultimate strength and performance
- Cooling Vanes
- We dedicate time to match the cooling vanes on our Specialty rotors to OE designs, ensuring: Optimal cooling Reduced fade Less noise Increased pad life
- Coating
- All Specialty rotors are protected against the elements. All new Specialty rotors come fully coated with Grey Fusion 4.0® rated at 300 hrs. salt spray or a Black Fusion painted hat and edge for rust protection.
- All Specialty rotors are protected against the elements. All new Specialty rotors come fully coated with Grey Fusion 4.0(R) rated at 300 hrs. salt spray or a Black Fusion painted hat and edge for rust protection.
- SAE Standard for Tensile Strength
- Our rotors follow SAE standards for tensile strength, hardness, and iron grade, providing structural integrity and maximum service life
- Turned Finish
- A turned finish provides an excellent surface for the pads to engage with to ensure a smooth and effective stop right out of the box
RAYBESTOS 980426 Specifications
Product Attributes
| ABS Tone Ring Included | No |
| Center Hole Diameter | 2.638 IN |
| Center Hole Diameter | 67 MM |
| Conventional Or Drum-In-Hat Type Rotor | Conventional |
| Discard Thickness | 1.157 IN |
| Discard Thickness | 29.4 MM |
| Harmonize Code | 8708.30.5030 |
| Mounting Bolt Hole Circle Diameter | 4.409 IN |
| Mounting Bolt Hole Circle Diameter | 112 MM |
| Mounting Bolt Hole Quantity | 5 |
| Nominal Thickness | 1.26 IN |
| Nominal Thickness | 32 MM |
| Outside Diameter | 13.78 IN |
| Outside Diameter | 350 MM |
| Overall Height | 2.146 IN |
| Overall Height | 54.5 MM |
| Salability Restrictions | No |
| Solid Or Vented Type Rotor | Vented |
| Stud/Lug Hole Quantity | 5 |
| UNSPSC Code | 25171715 |
Additional Information
| Country of Origin (Primary) | CN |
| Canadian Harmonizing Tariff Code | 8708309990 |
| Harmonized Tariff Code (HTS) | 8708305030 |
| UPC | 00829352378106 |
RAYBESTOS 980426 Cross References
RAYBESTOS 980426 Fits Vehicles
- Mercedes-Benz R500 (2006-2007)
- Mercedes-Benz R320 (2007-2009)
- Mercedes-Benz ML500 (2006-2007)
- Mercedes-Benz ML450 (2010-2011)
- Mercedes-Benz ML350 (2008-2011)
- Mercedes-Benz G55 AMG (2005-2011)
- Mercedes-Benz GL350 (2010-2012)
- Mercedes-Benz GL550 (2008-2012)
- Mercedes-Benz ML550 (2008-2011)
- Mercedes-Benz GL320 (2007-2009)
- Mercedes-Benz ML320 (2007-2009)
- Mercedes-Benz GL450 (2007-2012)
- Mercedes-Benz R350 (2006-2012)
