RAYBESTOS 980398 Part Description
Manufacturer
Product Description
Raybestos Specialty - Street Performance Brake Rotor
Application Summary
2007-2004 BMW 525i Front
Features & Benefits
- Application Specific Enhanced Iron
- Raybestos® Performance Rotors are made with enhanced iron which suppresses noise and keeps brakes running cool, quiet and vibration free.
- Raybestos(R) Performance Rotors are made with enhanced iron which suppresses noise and keeps brakes running cool, quiet and vibration free.
- Cooling Vanes
- The cooling vanes match OE configurations and provide optimal cooling and reduced fade.
- Application Specific Coating
- Depending on the application, Performance Rotors will have one of the following finishes: Black fusion coating on the rotor hat Grey Fusion 4.0® coating on the entire rotor
- Depending on the application, Performance Rotors will have one of the following finishes: Black fusion coating on the rotor hat Grey Fusion 4.0(R) coating on the entire rotor
- Black fusion coating on the rotor hat and Grey Fusion 4.0® coating on the rotor inboard surface and cooling vanes
- Black fusion coating on the rotor hat and Grey Fusion 4.0(R) coating on the rotor inboard surface and cooling vanes
- Turned Finish
- Turned finish minimizes noise and improves responsiveness for smoother stops.
- S-Groove Slot
- Depending on the application, some Raybestos® Performance Rotors are designed with a patented S-Groove Slot.
- Depending on the application, some Raybestos(R) Performance Rotors are designed with a patented S-Groove Slot.
RAYBESTOS 980398 Specifications
Product Attributes
| ABS Tone Ring Included | No |
| Center Hole Diameter | 3.113 IN |
| Center Hole Diameter | 79.05 MM |
| Conventional Or Drum-In-Hat Type Rotor | Conventional |
| Discard Thickness | 0.882 IN |
| Discard Thickness | 22.4 MM |
| Harmonize Code | 8708.30.5030 |
| Mounting Bolt Hole Circle Diameter | 4.724 IN |
| Mounting Bolt Hole Circle Diameter | 120 MM |
| Mounting Bolt Hole Diameter | 0.57 IN |
| Mounting Bolt Hole Diameter | 14.5 MM |
| Mounting Bolt Hole Quantity | 5 |
| Nominal Thickness | 0.945 IN |
| Nominal Thickness | 24 MM |
| Outside Diameter | 12.205 IN |
| Outside Diameter | 310 MM |
| Overall Height | 3.035 IN |
| Overall Height | 77.1 MM |
| Salability Restrictions | No |
| Solid Or Vented Type Rotor | Vented |
| Stud/Lug Hole Quantity | 5 |
| UNSPSC Code | 25171715 |
Additional Information
| Country of Origin (Primary) | DE |
| Canadian Harmonizing Tariff Code | 8708309990 |
| Harmonized Tariff Code (HTS) | 8708305030 |
| UPC | 00829352359716 |
RAYBESTOS 980398 Cross References
| Brand | Part Number |
|---|---|
| 829352359716, 120.34073 | |
| ADVANCE AUTO PARTS | YH200357, YH200357C, YH200357P |
| ATE BRAKE PRODUCTS | 424181, SP24181 |
| AUTOXTRA | AX900732 |
| AUTOZONE | 73001, 73001DG |
| BENDIX | PRT6012 |
| BMW | 34116764021 |
| BRAKEBEST | 15010119, 980398, 980398R, 980398RGS |
| BREMBO | 09.9173.11, 25747 |
| Brembo | 09.C894.11 |
| CENTRIC | 120.34073, 121.34073, 125.34073, 126.34073SL, 126.34073SR, 127.34073L, 127.34073R, 128.34073CL, 128.34073L, 128.34073R |
| Centric Parts | 120.34073, 121.34073, 125.34073, 126.34073SL, 126.34073SR, 127.34073L, 127.34073R, 128.34073CL, 128.34073L, 128.34073R |
| DURA CORP | BR34285, BR900732 |
| DuraGo | 900732, BR900732 |
| Dynamic Friction Company | 604-31065 |
| NAPA BRAKES | SDK6260, TSR802 |
| NEWTEK AUTOMOTIVE | 34285 |
| Newtek Automotive USA | 34285 |
| PILENGA | V819 |
| PROMAX | 14-34285 |
| PRONTO | BR900732 |
| QUINTON HAZELL | BDC5457 |
| Qualis | 45505 |
| TRW | 4359, DF4027S |
| UAP | 34285 |
| VAICO | V2080052 |
| VIPAR - VEHICLE INDUSRTY PARTS & MANUFACTURING | X51739 |
| WAGNER | BD180115 |
| WAGNER BRAKE | BD180115 |
| WINHERE | 6620212 |
| WORLDPAC | 1427-732131 |
RAYBESTOS 980398 Fits Vehicles
- BMW 525i (2004-2007)
