RAYBESTOS 96801 Raybestos Specialty - Street Performance Brake Rotor

$92.49

Limited availability at this price!

1 Day Lead Time

Get it by Monday, Mar 16
No Hassle Return Policy Details
Free Economy shipping on orders over $499 details
This item will ship about 1 day after the date of purchase.

RAYBESTOS 96801 Part Description

Manufacturer

RAYBESTOS

Product Description

Raybestos Specialty - Street Performance Brake Rotor

Application Summary

2000-1996 BMW 528i Front, 2003-2001 BMW 525i Front

Features & Benefits

  • Application Specific Enhanced Iron
  • Raybestos® Performance Rotors are made with enhanced iron which suppresses noise and keeps brakes running cool, quiet and vibration free.
  • Raybestos(R) Performance Rotors are made with enhanced iron which suppresses noise and keeps brakes running cool, quiet and vibration free.
  • Cooling Vanes
  • The cooling vanes match OE configurations and provide optimal cooling and reduced fade.
  • Application Specific Coating
  • Depending on the application, Performance Rotors will have one of the following finishes: Black fusion coating on the rotor hat Grey Fusion 4.0® coating on the entire rotor
  • Depending on the application, Performance Rotors will have one of the following finishes: Black fusion coating on the rotor hat Grey Fusion 4.0(R) coating on the entire rotor
  • Black fusion coating on the rotor hat and Grey Fusion 4.0® coating on the rotor inboard surface and cooling vanes
  • Black fusion coating on the rotor hat and Grey Fusion 4.0(R) coating on the rotor inboard surface and cooling vanes
  • Turned Finish
  • Turned finish minimizes noise and improves responsiveness for smoother stops.
  • S-Groove Slot
  • Depending on the application, some Raybestos® Performance Rotors are designed with a patented S-Groove Slot.
  • Depending on the application, some Raybestos(R) Performance Rotors are designed with a patented S-Groove Slot.

RAYBESTOS 96801 Specifications

Product Attributes

ABS Tone Ring Included No
Center Hole Diameter 3.11 IN
Center Hole Diameter 79 MM
Conventional Or Drum-In-Hat Type Rotor Conventional
Discard Thickness 0.803 IN
Discard Thickness 20.4 MM
Harmonize Code 8708.30.5030
Mounting Bolt Hole Circle Diameter 4.724 IN
Mounting Bolt Hole Circle Diameter 120 MM
Mounting Bolt Hole Diameter 0.575 IN
Mounting Bolt Hole Diameter 14.6 MM
Mounting Bolt Hole Quantity 5
Nominal Thickness 0.866 IN
Nominal Thickness 22 MM
Outside Diameter 11.654 IN
Outside Diameter 296 MM
Overall Height 2.992 IN
Overall Height 76 MM
Salability Restrictions No
Solid Or Vented Type Rotor Solid
Stud/Lug Hole Quantity 5
UNSPSC Code 25171715

Additional Information

Country of Origin (Primary) DE
Canadian Harmonizing Tariff Code 8708309990
Harmonized Tariff Code (HTS) 8708305030
UPC 00753497986493

RAYBESTOS 96801 Cross References

BrandPart Number
753497986493, 120.34045
ADVANCE AUTO PARTSYH145371, YH145371C
ATE BRAKE PRODUCTS422159, SP22159
AUTOSPECIALTYEBR496, EBR496E
AUTOZONE34161, 34161DG
BECK/ARNLEY083-2706
BENDIX145371
BMW34111163013, 34111164839, 3411116839, 34116767061, 34244463081
BRAKEBEST15010121, 96801, 96801FZN, 96801R, 96801RGS
BREMBO09.6924.10, 09.6924.11, 25473
Brembo09.6924.1X
CALIFORNIA DRUM & ROTOR125575
CENTRIC120.34045, 121.34045, 125.34045, 125.34045CRY, 126.34045CSL, 126.34045CSR, 126.34045SL, 126.34045SR, 127.34045L, 127.34045R, 128.34045CL, 128.34045CR, 128.34045L, 128.34045R, 320.34045C, 320.34045H
CONTINENTAL-CONTITECHCW22159
Centric Parts120.34045, 121.34045, 125.34045, 125.34045CRY, 126.34045CSL, 126.34045CSR, 126.34045SL, 126.34045SR, 127.34045L, 127.34045R, 128.34045CL, 128.34045CR, 128.34045L, 128.34045R, 320.34045C, 320.34045H
DURA CORPBR34161
DuraGoBR34161
MAGMA PRODUCTSPSR123046
MIGHTY DISTRIBUTING SYSTEM34161
MONROE BRAKESBD125575
NAPA BRAKESSDK6190, TSR7076, TSR7078
NEOTEK106686GF
NEWTEK AUTOMOTIVE34121, 34161
Newtek Automotive USA34121, 34161
PAGID355122112
PAGID Racing355122112
PILENGAV124
POWERSTOPEBR496EVC
PROMAX14-34121, 14-34161
PRONTOBR34161
QUALIS34161
QUINTON HAZELLBDC4623
Qualis34121
STANDARD ROTORS AND DRUMSGP34161
TRW2769, DF2769S
UAP34161
VAICOV2080025
VIPAR - VEHICLE INDUSRTY PARTS & MANUFACTURINGX51444
WABCOPS125575
WABCO - ArchivedPS125575
WAGNERBD125277, BD125575, BD125575E
WAGNER BRAKEBD125575
WINHERE442496
WORLDPAC1407-78319

RAYBESTOS 96801 Fits Vehicles

  • BMW 528i (1996-2000)
  • BMW 525i (2001-2003)

RAYBESTOS 96801 Customer Reviews

No reviews yet

Be the first to review this product!

RAYBESTOS 96801 Questions & Answers

No questions yet

Be the first to ask a question about this product!
