RAYBESTOS 96956 Part Description
Manufacturer
Product Description
Raybestos Specialty - Street Performance Brake Rotor
Application Summary
1998 Mercedes-Benz C230 Front
Features & Benefits
- Application Specific Enhanced Iron
- Raybestos® Performance Rotors are made with enhanced iron which suppresses noise and keeps brakes running cool, quiet and vibration free.
- Raybestos(R) Performance Rotors are made with enhanced iron which suppresses noise and keeps brakes running cool, quiet and vibration free.
- Cooling Vanes
- The cooling vanes match OE configurations and provide optimal cooling and reduced fade.
- Application Specific Coating
- Depending on the application, Performance Rotors will have one of the following finishes: Black fusion coating on the rotor hat Grey Fusion 4.0® coating on the entire rotor
- Depending on the application, Performance Rotors will have one of the following finishes: Black fusion coating on the rotor hat Grey Fusion 4.0(R) coating on the entire rotor
- Black fusion coating on the rotor hat and Grey Fusion 4.0® coating on the rotor inboard surface and cooling vanes
- Black fusion coating on the rotor hat and Grey Fusion 4.0(R) coating on the rotor inboard surface and cooling vanes
- Turned Finish
- Turned finish minimizes noise and improves responsiveness for smoother stops.
- S-Groove Slot
- Depending on the application, some Raybestos® Performance Rotors are designed with a patented S-Groove Slot.
- Depending on the application, some Raybestos(R) Performance Rotors are designed with a patented S-Groove Slot.
RAYBESTOS 96956 Specifications
Product Attributes
| ABS Tone Ring Included | No |
| Center Hole Diameter | 2.64 IN |
| Center Hole Diameter | 67.05 MM |
| Conventional Or Drum-In-Hat Type Rotor | Conventional |
| Discard Thickness | 0.394 IN |
| Discard Thickness | 10 MM |
| Harmonize Code | 8708.30.5030 |
| Mounting Bolt Hole Circle Diameter | 4.409 IN |
| Mounting Bolt Hole Circle Diameter | 112 MM |
| Mounting Bolt Hole Diameter | 0.525 IN |
| Mounting Bolt Hole Diameter | 13.35 MM |
| Mounting Bolt Hole Quantity | 5 |
| Nominal Thickness | 0.472 IN |
| Nominal Thickness | 12 MM |
| Outside Diameter | 11.185 IN |
| Outside Diameter | 284.1 MM |
| Overall Height | 1.715 IN |
| Overall Height | 43.55 MM |
| Salability Restrictions | No |
| Solid Or Vented Type Rotor | Solid |
| Stud/Lug Hole Quantity | 5 |
| UNSPSC Code | 25171715 |
Additional Information
| Country of Origin (Primary) | CN |
| Canadian Harmonizing Tariff Code | 8708309990 |
| Harmonized Tariff Code (HTS) | 8708305030 |
| UPC | 00747730722504 |
RAYBESTOS 96956 Cross References
| Brand | Part Number |
|---|---|
| 747730722504, 120.35041 | |
| ADVANCE AUTO PARTS | YH145512, YH145512C, YH145512P |
| ALTROM IMPORTS | 2024210212 |
| AMERICAN REMANUFACTURED | 89-74041 |
| ATE BRAKE PRODUCTS | 412128 |
| AUTOXTRA | AX34216 |
| AUTOZONE | 34171, 34171DG |
| BENDIX | 145512 |
| BOSCH | 36010974 |
| BRAKEBEST | 36010974, 96956, 96956R, 96956RGS |
| BREMBO | 25758, 08.4750.41 |
| CENTRIC | 120.35032, 120.35041, 121.35041, 126.35041SL, 126.35041SR, 127.35041L, 127.35041R |
| CONTINENTAL-CONTITECH | CW25110 |
| Casting Numbers | 211304-C, 326195 |
| Centric Parts | 120.35032, 120.35041, 121.35041, 126.35041SL, 126.35041SR, 127.35041L, 127.35041R |
| DURA CORP | BR34171 |
| DuraGo | BR34171 |
| MERCEDES-BENZ | 2024210212 |
| MIGHTY DISTRIBUTING SYSTEM | 34171 |
| NEWTEK AUTOMOTIVE | 34171 |
| Newtek Automotive USA | 34171 |
| QUALIS | 34171 |
| QUINTON HAZELL | BDC3838 |
| TRW | 2654, DF2654S |
| VAICO | V3040011 |
| VIPAR - VEHICLE INDUSRTY PARTS & MANUFACTURING | X51447 |
RAYBESTOS 96956 Fits Vehicles
- Mercedes-Benz C230 (1997-1998)
